220V Automatic Distillation Unit With Jacketed Condenser and Temperature Controller for Laboratory Use
Product Spotlights
This 220V Automatic Distillation Unit integrates a jacketed condenser for efficient cooling and a PID temperature controller for ±0.5°C accuracy. Ideal for solvent recovery, purity testing, and small-scale production. Corrosion-resistant materials, safety features, and customizable capacity make it a reliable choice for labs worldwide. Backed by ISO9001 certification and 8+ years of manufacturing expertise.
US$ 6450 - 954000
MOQ: 2 Combos
Key Specifications
Get Latest Price
Application:
Other, Laboratory distillation
Certification:
ISO9001, Other, HACCP
voltage:
220V
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
60 days
Related Products
-
Industrial Distillation Equipment 100L Capacity Electric Heating With Stainless Steel Column Packed TowerUS$ 6450 - 954000MOQ: 2 Combos -
Efficient Sludge Dehydrator Machine for MVR / Multi-Effect Sewage Treatment EquipmentUS$ 2140 - 7500MOQ: 1 Combo
-
Vacuum Wastewater Treatment Plant for Sewage TreatmentUS$ 400 - 14300MOQ: 1 Combo
-
Mee Vacuum Mvr Single Effect Evaporator for Sewage TreatmentUS$ 4520 - 95200MOQ: 1 Combo
-
Nitrogen Evaporator Mbbr Mbr SBR Mvr Wastewater or Sewage Treatment PlantUS$ 4520 - 95200MOQ: 1 Combo
Application
Other, Laboratory distillation
Certification
ISO9001, Other, HACCP
voltage
220V
condenser_type
Jacketed Condenser
temperature_control
Yes, built-in controller
material
Borosilicate Glass / Stainless Steel
capacity
500ml - 5000ml (customizable)
power
220V, 50/60Hz
Qingdao Conqinphi Environmental Technology Group Co., Ltd., a professional manufacturer established in 2015 with a factory spanning 10,000–30,000 square meters and an annual export value of US$10–50 million, proudly presents the 220V Automatic Distillation Unit with Jacketed Condenser and Temperature Controller. This laboratory-grade system is engineered to deliver precise, repeatable distillation results for R&D, quality control, and small-scale production. With its integrated temperature controller and jacketed condenser design, it ensures efficient heat exchange and stable operation, making it an essential tool for solvent purification, water distillation, and chemical separation in various labs. Built to meet international standards, this unit offers exceptional safety, durability, and ease of use.
Key Features & Technical Specifications
- Automatic Operation: The unit features an intelligent control system that automatically adjusts heating intensity and condensation rate based on preset parameters, reducing manual intervention and improving consistency.
- Jacketed Condenser: A double-layer glass condenser with water circulation jacket provides superior cooling efficiency, preventing vapor loss and ensuring high-purity distillate collection.
- Precise Temperature Controller: Digital PID controller with PT100 sensor maintains temperature accuracy within ±0.5°C, supporting a wide range of distillation tasks (from 20°C to 300°C).
- High Safety Standards: Over-temperature protection, automatic shut-off, and pressure relief valve are integrated to safeguard both user and equipment.
- Versatile Capacity: Available in 500ml, 1000ml, 2000ml, and 5000ml options (custom sizes upon request).
- Corrosion-Resistant Materials: Main body made of high borosilicate glass (GG-17) with PTFE seals, while the heating mantle is stainless steel for durability.
- Compact & Ergonomic Design: Space-saving footprint (40cm x 50cm x 80cm) with adjustable stand and integrated clamp holder for easy installation.
Technical Specifications
| Specification | Details |
| Power Supply | 220V AC, 50/60Hz (110V optional) |
| Heating Power | 500W – 1500W (adjustable) |
| Temperature Range | RT+10°C to 300°C |
| Temperature Accuracy | ±0.5°C |
| Condenser Type | Jacketed (water-cooled), length 200mm |
| Distillation Flask Capacity | 500ml / 1000ml / 2000ml / 5000ml (optional) |
| Materials | Borosilicate glass (GG-17), PTFE seals, stainless steel heating mantle |
| Safety Features | Overheat protection, auto shut-off, leak-proof design |
Detailed Product Advantages
- Enhanced Distillation Efficiency: The jacketed condenser provides a larger surface area for heat exchange, reducing distillation time by up to 30% compared to standard Liebig condensers.
- Consistent Results: Thanks to the PID temperature controller, the unit maintains a stable boiling point, preventing bumping and ensuring reproducible yields batch after batch.
- Operator Convenience: The front panel includes a digital display for real-time temperature and power monitoring, along with simple push-button controls for setting parameters.
- Flexible Configuration: Optional upgrades include a vacuum adapter for reduced-pressure distillation, a fractionating column for multi-component separation, and a receiving flask with a drain valve.
- Compliance & Quality: Manufactured under ISO9001-certified processes, with each unit individually tested before shipment. The company holds HACCP and OHSAS18001 certifications, reflecting commitment to food-grade safety and occupational health.
Why Choose Us
With over 8 years of manufacturing experience, Qingdao Conqinphi has supplied distillation units to more than 50 countries across North America, Europe, Southeast Asia, and the Middle East. Our factory employs 201-300 skilled workers and covers 10,000+ square meters of production space, enabling strict quality control and timely delivery. We have shipped products worth US$10–50 million annually, with a proven track record of reliability. Our technical team provides free consultation and after-sales support, including installation guidance and spare parts availability.
This 220V Automatic Distillation Unit is ideal for universities, pharmaceutical labs, chemical plants, and food testing centers. Whether you need to purify solvents, recover expensive chemicals, or conduct teaching experiments, our system delivers consistent performance. We invite you to contact us for a quotation or customization request – your satisfaction is our priority.
Frequently Asked Questions
- Q: What voltage options are available besides 220V? A: We can customize the unit for 110V or other voltages upon request. Please specify when ordering.
- Q: Can I use this unit for vacuum distillation? A: Yes, with an optional vacuum pump and adapter. The design supports reduced-pressure operation for heat-sensitive samples.
- Q: What maintenance is required? A: Regularly clean the condenser with diluted acid, check seals for wear, and replace PTFE gaskets if needed. Our manual provides detailed instructions.
- Q: Is the temperature controller calibrated before shipping? A: Yes, each unit undergoes factory calibration with a certified thermometer. Accuracy is verified at three points (50°C, 100°C, 200°C).
- Q: Can I connect the unit to a chiller? A: Absolutely. The water inlet and outlet are standard 8mm barbed connections compatible with most recirculating chillers.
- Q: How long is the warranty? A: Standard warranty is 12 months from the date of shipment, covering manufacturing defects. Extended warranty options are available.
- Q: What certificates do you provide? A: We provide CE (if required), ISO9001, and COA. Other documents like Fumigation certificate are available upon request.
- Q: What is the lead time for this product? A: Standard units (500ml-2000ml) ship within 7-10 working days after payment. Custom sizes may take 20-25 days.
