Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. As a leading manufacturer established in 2015, we specialize in providing high-quality industrial wastewater treatment solutions. Our factory spans over 10,000 square meters and we have a dedicated team of 201-300 employees. With an annual export value exceeding US$10 million, we serve clients across North America, South America, Europe, Asia, and Africa. Our Industrial Wastewater Treatment Equipment for Pharmaceutical Factory (Model: SS304 500L/h) is designed to efficiently treat complex pharmaceutical effluents, ensuring compliance with environmental standards while minimizing operational costs.
This system is constructed with high-grade stainless steel SS304, offering excellent corrosion resistance and durability. It is capable of processing up to 500 liters per hour, making it ideal for small to medium-scale pharmaceutical production lines. The equipment integrates advanced physical, chemical, and biological treatment stages to remove organic pollutants, suspended solids, heavy metals, and other contaminants.
Key Features and Technical Specifications
- Material: All wetted parts are made of SS304 stainless steel, ensuring long service life and easy cleaning.
- Treatment Capacity: 500 L/h (expandable or reducible based on customer requirements).
- Multi-stage Treatment Process: Includes screening, coagulation, sedimentation, aeration, biological treatment (activated sludge or MBBR), and tertiary filtration.
- Automatic Control: PLC-based control system with touch screen interface for real-time monitoring and operation.
- Energy Efficient: Low power consumption design with high-efficiency pumps and blowers.
- Compact Footprint: Skid-mounted design saves space and simplifies installation.
- Customizable Options: Additional UV disinfection, reverse osmosis, or sludge dewatering units available.
The following table summarizes the main technical parameters:
| Parameter | Specification |
|---|---|
| Model | CQ-500-SS304 |
| Treatment Capacity | 500 L/h |
| Material | SS304 Stainless Steel |
| Power Supply | 380V/50Hz, 3-Phase (Customizable) |
| Installed Power | 5.5 kW |
| Overall Dimensions (L×W×H) | 1500×800×1800 mm (approx) |
| Weight | ~800 kg |
| Control System | PLC with HMI |
| Certification | ISO9001, ISO14001, OHSAS18001 |
Advantages for Your Pharmaceutical Factory:
- Compliance: Meets discharge standards for pharmaceutical wastewater (BOD, COD, TSS, pH).
- Reliability: Built with corrosion-resistant SS304 to withstand aggressive chemicals.
- Cost Savings: Reduces water consumption through recycling options; low energy and maintenance costs.
- Easy Operation: Fully automatic with alarm and remote monitoring capability.
- Scalability: Can be integrated into existing wastewater collection systems or expanded with additional modules.
At Qingdao Conqinphi Environmental Technology Group, we have delivered hundreds of wastewater treatment systems worldwide. Our factory is equipped with advanced manufacturing facilities and a professional R&D team. We have obtained multiple quality management certifications including ISO9001, ISO14001, and OHSAS18001, ensuring that every product meets rigorous international standards. With shipments departing from Qingdao Port, we provide efficient logistics to global customers. Our after-sales service includes installation guidance, commissioning support, and spare parts supply.
Frequently Asked Questions (FAQ):
-
Q: What types of pharmaceutical wastewater can this equipment treat?
A: It is suitable for wastewater from antibiotic production, chemical synthesis, fermentation, and formulation processes. The system effectively removes high COD, BOD, suspended solids, and residual solvents. -
Q: Is the equipment easy to install?
A: Yes, it comes as a skid-mounted, pre-assembled unit. Only basic piping and electrical connections are needed on-site. We provide detailed installation manuals and remote technical support. -
Q: What is the expected lifetime of the SS304 material?
A: SS304 is highly resistant to corrosion and can last 10-15 years with proper maintenance. Regular cleaning and passivation will extend its service life. -
Q: Can the capacity be customized?
A: Absolutely. While the standard model is 500L/h, we can design systems with capacities from 100L/h to 10,000L/h based on your specific flow rate requirements. -
Q: What after-sales support do you offer?
A: We provide 12-month warranty, lifetime technical support, and spare parts availability. Our engineers are available for on-site commissioning if needed. -
Q: What is the power consumption?
A: The installed power is approximately 5.5 kW. Actual consumption depends on the running load, typically around 4-5 kWh per hour. -
Q: Do you provide international certificates?
A: Yes, our products are manufactured under ISO9001 and ISO14001 certified processes. We can also provide inspection reports from third-party agencies upon request. -
Q: How long is the delivery time?
A: Standard delivery is 30-45 days after order confirmation. Urgent orders can be expedited with arrangement.
Contact us today to discuss your specific wastewater treatment needs. With our proven expertise and global service network, we are confident to be your reliable partner in environmental protection.
