Hengshui City Yike Composite Materials Co., Ltd., established in 2009, is a professional manufacturer specializing in FRP water storage tanks. Our 10000 Liter FRP Vertical Horizontal Water Storage Tank is designed to provide a reliable and cost-effective solution for storing clean water in residential, commercial, and industrial applications. Combining advanced filament winding technology with rigorous quality control, this tank offers exceptional corrosion resistance, structural strength, and long service life—making it a trusted choice for global buyers.
With an annual export value of US$1.5 Million – US$2.5 Million and serving markets across North America, South America, Europe, Asia, Africa, and Oceania, we understand the diverse needs of our customers. This tank is engineered for easy installation and maintenance, available in both vertical and horizontal orientations to fit your space constraints. Below, we detail its key features, technical specifications, and advantages.
Key Features & Benefits
- Material Superiority: Made from high-quality fiberglass reinforced plastic (FRP) with isophthalic or vinyl ester resin for excellent chemical and corrosion resistance. No rust, no leakage, and minimal maintenance.
- Dual Orientation: Available in vertical or horizontal configurations, with customizable inlet/outlet positions. The tank includes a manhole for easy cleaning and inspection.
- Lightweight Strength: Weighs approximately 25-30% of an equivalent steel tank, reducing foundation costs and simplifying transportation and installation.
- Sanitary Design: Inner surface is smooth and non-toxic, meeting FDA and WHO standards for potable water storage (internal lining available upon request).
- UV & Weather Resistance: Outer gel coat with UV stabilizers prolongs outdoor life; suitable for above-ground or underground installation.
- Customization: Color, fittings (flanges, valves), insulation layers, and ladder/handrail options can be tailored to your project.
Technical Specifications
| Parameter | Value / Description |
|---|---|
| Nominal Capacity | 10,000 Liters (10 m³) |
| Working Pressure | Atmospheric (0.1 MPa standard; higher pressure optional) |
| Operating Temperature | -40°C to +80°C (with resin selection) |
| Wall Thickness | 5–12 mm (depending on design) |
| Orientations | Vertical or Horizontal |
| Typical Dimensions (Vertical) | Diameter approx. 2.0m, Height approx. 3.2m (customizable) |
| Typical Dimensions (Horizontal) | Diameter approx. 2.0m, Length approx. 3.5m (customizable) |
| Manhole | DN400 / DN500 with lid (standard) |
| Connections | Inlet, Outlet, Overflow, Drain (sizes customizable) |
| Compliance | Manufactured under ISO 9001 quality management system (factory certified); materials comply with relevant international standards. |
Advantages for Your Business
- Cost Efficiency: Lower lifetime cost compared to steel or concrete tanks due to zero corrosion maintenance and longer service life (20+ years typical).
- Fast Installation: Lightweight design reduces crane and labor requirements; can be assembled on site by a small crew.
- Versatility: Suitable for rainwater harvesting, irrigation, fire fighting reserves, municipal water supply, and industrial process water storage.
- Eco-Friendly: FRP is inert and can be recycled; tank production consumes less energy than metal alternatives.
At Hengshui City Yike Composite Materials Co., Ltd., we have been serving global customers since 2009 with reliable FRP solutions. Our factory is located in Hengshui, Hebei—China's composite material hub—ensuring high-quality raw materials and skilled craftsmanship. With an annual export value exceeding US$1.5 million and a presence in over 15 international markets, we have built a reputation for reliable delivery and responsive after-sales support.
Each tank undergoes rigorous quality checks including hydrostatic testing and dimensional inspection before shipment. We offer a warranty period of 1 year (extended available) and provide technical documentation (manual, installation guide, CAD drawings) upon request. Our team can also assist with logistics from Tianjin or Shanghai ports to ensure timely delivery worldwide.
Ready to upgrade your water storage system? Contact us today for a quotation or technical consultation. Discover why hundreds of clients trust Yike for their clean water storage needs.
Frequently Asked Questions (FAQ)
-
Q: Is this tank suitable for underground installation?
A: Yes, the tank can be designed for underground use with additional structural reinforcement and proper backfill procedures. Please specify your requirement when ordering. -
Q: What is the typical lifespan of these FRP tanks?
A: With correct installation and maintenance, a well-built FRP tank can last 20–30 years or more, depending on environmental conditions and water quality. -
Q: Can I get custom fittings (e.g., specific flange sizes or valve types)?
A: Absolutely. We offer custom nozzle positions, sizes, and connections to match your piping system. Just provide your project details. -
Q: How do I transport and install a 10,000L tank?
A: The tank is relatively lightweight (approx. 300-500 kg depending on thickness). It can be shipped in one piece by flatbed truck. Installation requires a flat concrete base and simple lifting equipment. A detailed manual is provided. -
Q: Is the tank FDA-approved for drinking water?
A: The resin and lining we use can meet potable water standards. We can supply tanks with food-grade inner liners that comply with FDA or equivalent regulations. Request certification if needed. -
Q: What colors are available?
A: Standard colors are blue, green, and white. Custom RAL colors are available with minimum quantity order. -
Q: Do you offer a warranty?
A: Yes, we provide a 1-year warranty against manufacturing defects. Extended warranty options are available upon negotiation. -
Q: Can I get a sample or visit your factory?
A: We welcome factory inspections and can arrange sample pieces (small sections) for material testing. Contact us to schedule a visit.
