Product Spotlights

100% mill-tested FRP tank for sodium hypochlorite storage. 0.5m³ capacity with 12mm thick shell ensures superior strength and corrosion resistance. Includes Mill Test Report for full traceability. Lightweight, UV-protected, customizable connections. Trusted by global water treatment clients since 2009.
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Fiberglass Reinforced Plastic (FRP)
Capacity:
0.5 m³ (500 Liters)
Shell Thickness:
12 mm
Contact Supplier Request Quote Chat Now
Hengshui City Yike Composite Materials Co., Ltd.
Platinum Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Fiberglass Reinforced Plastic (FRP)
Capacity 0.5 m³ (500 Liters)
Shell Thickness 12 mm
Medium Sodium Hypochlorite (NaOCl)
Color Customizable (Standard: White / Yellow / Blue)
Design Standard Available upon request (e.g., ASME, GB)
Application Chemical storage, Water treatment, Disinfection
Feature Corrosion-resistant, UV-resistant, Lightweight, High strength
Included Document Mill Test Report (MTR)

Hengshui City Yike Composite Materials Co., Ltd., established in 2009 and exporting US$1.5–2.5 million annually, proudly presents our FRP NaOCl Storage Tank – 0.5m³ capacity with a robust 12mm shell thickness. This tank is specifically designed for the safe and reliable storage of sodium hypochlorite, a widely used disinfectant in water treatment, chemical processing, and industrial applications. With over a decade of composite material expertise and a global market reach covering North America, Europe, Asia, Africa, and Oceania, we deliver a product that combines superior corrosion resistance, structural integrity, and full documentation including a Mill Test Report (MTR) to guarantee quality and traceability.

Key Features & Technical Specifications

  • Corrosion-Resistant FRP Construction: Our tank is made from high-quality fiberglass reinforced plastic (FRP) with a resin system specifically formulated for chlorine demand and oxidation resistance, ensuring long service life even with concentrated sodium hypochlorite (up to 15% concentration). No lining required – the monolithic structure eliminates delamination and leaks.
  • 12mm Shell Thickness for Enhanced Safety: The 0.5m³ tank features a minimum shell thickness of 12mm, providing excellent mechanical strength and resistance to internal pressure, impact, and thermal expansion. This thickness exceeds typical industry standards for similar sizes, offering extra safety margin for on-site storage.
  • Comprehensive Mill Test Report (MTR): Every tank comes with a detailed Mill Test Report that includes material traceability, mechanical property test results (e.g., tensile strength, flexural modulus), and confirmation of resin cure. This document verifies that the tank meets our strict quality control criteria and supports your compliance with project specifications.
  • Lightweight & Easy Installation: FRP tanks weigh only about 20–30% of equivalent steel tanks, reducing transportation and installation costs. The 0.5m³ unit can be easily placed on a simple concrete pad without heavy lifting equipment, and our team can provide installation guidelines upon request.
  • UV-Protected Exterior: The outer surface is treated with UV-resistant gel coat, minimizing degradation from sunlight exposure. This extends the tank's service life in outdoor applications and maintains its aesthetic appearance.
  • Customizable Connections & Accessories: Standard fittings include a 2-inch inlet, 2-inch outlet, and a 4-inch manway (optional). Vent, drain, and level indicators are available as add-ons. We can also customize the color, nozzle orientation, and base design to match your site requirements.

Technical Data Table

Parameter Value
Total Capacity 0.5 m³ (500 liters / 132 US gallons)
Shell Thickness 12 mm (minimum)
Design Temperature -20°C to +60°C (standard); extended range available on request
Design Pressure Atmospheric (standard); optional for 0.5 bar or higher
Material FRP (Orthophthalic/Isophthalic/Vinyl Ester resin – selectable)
Specific Gravity (SG) Designed for SG ≤ 1.2 (standard); higher SG available
Standard Color White / Yellow / Blue (others customizable)
Included Documentation Mill Test Report (MTR)

Why Choose our FRP NaOCl Storage Tank? The 0.5m³ size is ideal for small-scale water treatment plants, swimming pools, dairy farms, or any facility that requires a compact chemical storage solution. The 12mm shell thickness provides a level of durability that cheaper, thinner tanks cannot match, reducing the risk of cracks or leaks. Additionally, the included Mill Test Report gives you peace of mind that each tank has been individually tested and certified.

Trusted by Global Customers – Since 2009, Hengshui City Yike Composite Materials Co., Ltd. has exported over US$1.5 million annually to more than 15 countries across North America, Europe, Asia, Africa, and Oceania. Our products are widely used by chemical distributors, municipal water authorities, and industrial maintenance teams. We ship from Tianjin Port and Shanghai Port, with lead times typically 15–25 days after order confirmation. We offer flexible payment terms and can provide custom engineering for special applications.

Take the Next Step – If you need a reliable, code-compliant FRP tank for sodium hypochlorite storage, our 0.5m³ unit with 12mm shell thickness is an excellent choice. Contact our sales team today to request a quote, discuss customization options, or ask about larger sizes up to 50m³. We look forward to supporting your project with quality, transparency, and expert service.

Frequently Asked Questions (FAQ)

Q1: What is the typical service life of this FRP tank for NaOCl?
A: With proper handling and regular inspection, tanks made with vinyl ester resin can last 10–15 years or more. The 12mm shell thickness adds extra margin against wear. Actual life depends on operating temperature and concentration.
Q2: Can this tank be used for other chemicals like HCl or H₂SO₄?

A: No – the resin formulation is specifically chosen for NaOCl compatibility. For other chemicals, please specify your medium during inquiry so we can recommend the appropriate resin (e.g., isophthalic or vinyl ester for acids).
Q3: What is included in the Mill Test Report?
A: The MTR includes material certification (resin type, glass content), mechanical test data (tensile strength >150 MPa, flexural modulus >10 GPa, Barcol hardness >45), and cure confirmation. Custom MTR formats are available upon request.
Q4: Do you offer installation support or drawings?
A: Yes, we provide general installation guidelines and dimensional drawings (PDF/DWG). For complex projects, on-site commissioning support can be arranged at additional cost. Anchoring details, foundation requirements, and piping recommendations are included.
Q5: What temperature range can the tank withstand?
A: Standard design is -20°C to +60°C. For continuous operation above 60°C, we can upgrade to a high-temperature resin system (consult engineering). Note that NaOCl stability decreases above 30°C, so consider cooling if needed.
Q6: Can the tank be buried underground?

A: This model is designed for above-ground installation only. For buried applications, we recommend a thicker shell (e.g., 15–20 mm) and additional corrosion protection. Please contact us for a customized underground solution.
Q7: What is your minimum order quantity (MOQ)?
A: For standard 0.5m³ tanks, MOQ is 1 unit. Discounts are available for orders of 10 or more. We ship worldwide via FCL or LCL from Tianjin/Shanghai.
Q8: How do I clean or maintain the tank?
A: Regular flush with fresh water is sufficient. Avoid abrasive cleaners. Inspect internal surfaces annually for signs of wear. If residue accumulates, use a mild citric acid solution (do not use caustic cleaners that may damage the resin).
Product Tags: FRP Sodium Hypochlorite Storage Tank , 0.5m³ FRP Chemical Tank , 12mm FRP Tank with Mill Test Report
