Product Introduction
We specialize in manufacturing customized industrial couplings and OEM power transmission components for diverse industrial applications. Located in Hebei Province, China, near Tianjin Port, we are a factory-direct manufacturer integrating design, fabrication, installation and service, providing reliable coupling solutions for global customers. Whether you need a replacement for a worn part or a completely new design for a special application, we can deliver.
Application Scenarios
Our customized couplings are used in:
-
Replacement of worn or damaged couplings (any brand, any model)
-
Special machinery with non-standard interfaces or dimensions
-
Prototype and small-batch production for new equipment development
-
Upgrading existing drive systems for higher torque or speed
-
Any application requiring tailor-made solutions not available off-the-shelf
Product Structure (Customizable)
Depending on your requirements, the coupling may consist of:
-
Hubs – Drive and driven side, machined per your shaft dimensions
-
Flexible Element – Gear teeth, diaphragm pack, spring, elastomeric insert, etc., selected per application
-
Fasteners – Bolts, keys, locking assemblies as specified
-
Housing / Cover – Optional protective enclosure
-
Special Features – Custom flanges, splines, taper locks, insulation, etc.
(Suggested: Insert a representative structural diagram or a photo of a previous custom coupling)
Technical Parameters (Customized per Requirement)
Parameter |
Typical Range / Custom Option |
|---|---|
Nominal Torque |
As required (from 10 N·m to over 2,000,000 N·m) |
Allowable Speed |
As required (up to 50,000 r/min possible) |
Bore Diameter |
Any size, metric or inch |
Shaft Connection |
Keyway, spline, taper lock, clamping, etc. |
Material |
Carbon steel, alloy steel, stainless steel, aluminum, cast iron |
Surface Treatment |
Black oxide, phosphating, painting, galvanizing |
Balance Grade |
G6.3, G2.5, or per customer specification |
Standards |
GB, DIN, ISO, ANSI, or customer-specific |
All parameters are determined according to your drawings, samples or technical requirements.
Customization Process
We follow a structured customization process to ensure each coupling meets your exact needs:
-
Requirement Analysis – Understand application, load, environment, interface and performance goals
-
Design Proposal – Provide conceptual design, material recommendation and quotation
-
Drawing Approval – Customer reviews and approves detailed engineering drawing
-
Material Procurement – Source approved materials with certificates
-
Fabrication – Manufacture under strict quality control (machining, heat treatment, assembly)
-
Inspection & Testing – Dimensional check, balance test, hardness test, run-out test, etc.
-
Packaging & Shipping – Secure packing for sea freight from Tianjin Port
After-Sales Service
We provide comprehensive after-sales support:
-
Full technical documentation (drawing, material certificate, test report)
-
Online technical consultation during installation
-
Continuous improvement suggestions based on field feedback
-
Long-term spare parts availability
Company Commitment
Design · Engineering · Fabrication · Installation · Service
We are committed to providing safe and reliable equipment and engineering solutions for oil & gas, petrochemical, energy and industrial sectors worldwide.
------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
