Modular Multi-Effect Evaporator for Seawater Desalination, 10-Effect, Automated Control Panel, ISO Standard Compliant
Product Spotlights
10-effect modular evaporator for seawater desalination with automated control panel, ISO-compliant. High energy efficiency (GOR 8-10), low TDS output (<10 ppm), corrosion-resistant materials, fast installation, and scalable design. Factory-direct from an experienced manufacturer with global export track record.
US$ 41100 - 64000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Warranty:
12 Months (standard)
Type:
Multi-Effect Evaporator (MED)
Number of Effects:
10
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
90 days
Related Products
-
Steam Driven Multi-Effect Evaporator for Desalination, 4-Effect, 15-30 M³/h, DCS ControlUS$ 41100 - 64000MOQ: 1 Combo -
Energy Saving Multi-Effect Evaporator for Desalination, 6-Effect, 50 M³/h, 316L, Low TDS OutputUS$ 41100 - 64000MOQ: 1 Combo
-
Standard-Compliant Multi-Effect Evaporator With Remote Monitoring and Technical Support PackageUS$ 5470 - 768000MOQ: 1 Combo
-
Multi-Effect Evaporator for Pharmaceutical and Chemical Processing With CIP SystemUS$ 5470 - 768000MOQ: 1 Combo
-
Customized Multi-Effect Evaporator With Automatic Control for Food and Beverage IndustryUS$ 5470 - 768000MOQ: 1 Combo
Warranty
12 Months (standard)
Type
Multi-Effect Evaporator (MED)
Number of Effects
10
Material
Stainless Steel / Titanium (optional)
Control System
Automated Control Panel
Capacity
Customizable (e.g., 500-5000 m³/day)
Application
Seawater Desalination
Compliance
ISO Standard Compliant
Power Supply
380V/50Hz or Customizable
Installation
Modular Design
Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents our Modular Multi-Effect Evaporator for Seawater Desalination – a 10-effect, high-efficiency system designed to meet the growing demand for fresh water in coastal and industrial applications. As a manufacturer with over 9 years of experience and a factory spanning 10,000-30,000 square meters, we have engineered this evaporator to deliver reliable performance, energy savings, and easy scalability. The integrated automated control panel ensures precise operation, while modular construction allows for flexible capacity expansion. Backed by ISO standard compliance, this system is built to international quality benchmarks.
Key Features & Technical Specifications
- 10-Effect Thermal Efficiency: Achieves high Gained Output Ratio (GOR) – typically 8-10 kg distillate per kg steam – reducing energy consumption significantly compared to single-effect systems.
- Modular Design: Pre-assembled skid-mounted modules allow for quick on-site installation, minimal civil work, and future capacity upgrades. Each module is factory-tested before shipment.
- Automated Control Panel: PLC-based system with HMI touch screen monitors temperature, pressure, flow rates, and conductivity in real time. Automatic alarms, data logging, and remote monitoring capabilities are available upon request.
- Corrosion-Resistant Materials: Standard construction uses stainless steel 316L for evaporator bodies; titanium tubes are optional for high-chloride environments. This ensures long service life in harsh seawater conditions.
- Low Scaling & Fouling: Advanced spray nozzle design and precise temperature control minimize scaling on heat transfer surfaces, reducing maintenance frequency and chemical dosing.
- Energy Recovery Options: Can be integrated with thermal vapor compression (TVC) or mechanical vapor compression (MVC) to further improve efficiency – customizable per project.
- Compliance with International Standards: Designed and manufactured in accordance with ISO 9001, ISO 14000, and other relevant quality and environmental management systems. Each unit undergoes rigorous inspection.
| Parameter | Specification |
|---|---|
| Number of Effects | 10 |
| Fresh Water Capacity | 500 – 5000 m³/day (customizable) |
| Feed Water TDS | Up to 45,000 ppm (seawater) |
| Product Water TDS | |
| Steam Consumption (at 0.3 bar g) | Approx. 0.1 – 0.12 kg steam per kg distillate |
| Power Consumption | 1.5 – 2.5 kWh/m³ (depending on configuration) |
| Operating Temperature | Top brine temperature: 65 – 70°C |
| Control System | PLC + HMI (Siemens or equivalent) |
| Material of Construction | SS316L / Titanium (optional) |
Advantages & Customer Benefits
- Lower Total Cost of Ownership: The 10-effect design reduces steam consumption by up to 40% compared to 6-effect systems, leading to significant operational savings over the system's 20+ year lifespan.
- Fast Installation & Commissioning: Modular skids arrive pre-piped and pre-wired; our team can complete installation within 2-4 weeks on-site, minimizing downtime for your project.
- User-Friendly Operation: The automated control panel requires minimal operator intervention. Alarm logs and trend data help with predictive maintenance, reducing unplanned shutdowns.
- Scalability for Future Needs: Add extra modules to increase capacity without replacing existing equipment – ideal for growing communities or industrial parks.
- Reliable After-Sales Support: As a factory-direct manufacturer, we provide spare parts, remote troubleshooting, and on-site technical assistance. Our team of 200+ dedicated staff ensures prompt response.
Trusted by Clients Worldwide
Since our establishment in 2015, Qingdao Conqinphi Environmental Technology Group has exported desalination equipment to over 50 countries across North America, South America, Europe, Africa, Asia, and Oceania, with annual export value exceeding US$10 million. Our factory, covering 10,000-30,000 m², is equipped with advanced manufacturing lines and testing facilities. We hold multiple certifications including HACCP, SA8000, and ISO 9001/14000/OHSAS18001, reflecting our commitment to quality, safety, and environmental responsibility. Every Modular Multi-Effect Evaporator is subjected to a 72-hour continuous run test before leaving our Qingdao port. Choose Conqinphi for a partner that delivers engineering excellence and long-term value. Contact us today for a customized proposal or to arrange a factory visit.
Frequently Asked Questions
-
Q: What is the typical recovery rate of this 10-effect evaporator?
A: The recovery rate (distillate/feed) is generally 35-45% for seawater, depending on feed temperature and salinity. Higher recovery can be achieved with additional pretreatment. -
Q: Can the system handle high-salinity brine or produced water?
A: Yes, the design can be adapted for brine with TDS up to 70,000 ppm using optional materials and customized operating parameters. Please provide your water analysis for a tailored solution. -
Q: What is the delivery time?
A: Standard lead time is 90-120 days after order confirmation, depending on capacity and customization. Rush orders are negotiable with our production team. -
Q: Do you offer installation supervision?
A: Yes, we provide experienced engineers for on-site installation guidance and commissioning support. Travel and accommodation costs are quoted separately. -
Q: What kind of pretreatment is required?
A: We recommend conventional pretreatment (media filtration + cartridge filtration) to remove suspended solids and chlorine. For seawater with high organic content, additional UF or DAF may be needed – our team can design the full system. -
Q: Is the automated control panel compatible with SCADA?
A: Yes, the PLC supports Modbus TCP/IP protocol, allowing integration with existing SCADA or DCS systems. Remote monitoring via Ethernet is optional. -
Q: What is the warranty period?
A: Standard warranty is 12 months from commissioning or 18 months from shipment, whichever comes first. Extended warranty plans are available. -
Q: Can you provide performance guarantee?
A: We guarantee product water quality (
