Horizontal Multi-effect Evaporator, 5-Stage, 1.5MPa, 200°C, 10kW, Standard Compliant
Product Spotlights
5-stage multi-effect design reduces energy consumption by up to 60%; operates at 1.5 MPa and 200°C for high-temperature concentration; horizontal layout simplifies maintenance; 10 kW heating power with customizable options; manufactured under ISO9001/ISO14000, backed by a reliable Chinese manufacturer with global export experience.
US$ 8000 - 864000
MOQ: 2 Combos
Key Specifications
Get Latest Price
Application:
Other, Industrial wastewater treatment
Material:
Other, Stainless steel ( customization available )
Type:
Horizontal Multi-effect Evaporator
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
90 days
Related Products
-
Multi-effect Evaporator, 304 SS, 6m² Evaporation Area, PLC Automatic, 220V/380V OptionalUS$ 8000 - 864000MOQ: 2 Combos -
Forced Circulation Multi-effect Evaporator, 4-Stage, 0.2-0.5MPa, 30-100°C, 316L Stainless SteelUS$ 8000 - 864000MOQ: 2 Combos
-
Reliable Multi-effect Evaporator, 2-Year Warranty, Mill Test Report Available, Standard CompliantUS$ 8000 - 864000MOQ: 2 Combos
-
Vertical Multi-effect Evaporator With 5m² Heat Transfer Area, 0.5MPa, 304L Material, AutomaticUS$ 8000 - 864000MOQ: 2 Combos
-
Industrial Multi-effect Evaporator for Wastewater Treatment, 3-Stage, 15kW, 0.8MPaUS$ 8000 - 864000MOQ: 2 Combos
Application
Other, Industrial wastewater treatment
Material
Other, Stainless steel ( customization available )
Type
Horizontal Multi-effect Evaporator
Number of Effects
5-Stage
Working Pressure
1.5 MPa
Working Temperature
200°C
Heating Power
10 kW
Standard Compliance
ISO9001, ISO14000, others available upon request
Color
Customizable
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. — your trusted partner in industrial evaporation solutions. As a leading manufacturer established in 2015 with a factory spanning 10,000–30,000 square meters and annual export value exceeding US$10 million, we bring over a decade of experience to every product we deliver. Our Horizontal Multi-effect Evaporator, 5-Stage, 1.5MPa, 200°C, 10kW, Standard Compliant is engineered to optimize energy efficiency and operational reliability for demanding industrial processes. This unit combines advanced multi-effect technology with robust construction, ensuring reduced energy consumption and minimal environmental impact while meeting global compliance standards.
Key Features & Technical Specifications
- 5-Stage Multi-Effect Design — Maximizes heat recovery by utilizing vapor from each stage as the heating medium for the next, reducing overall energy demand by up to 60% compared to single-effect evaporators.
- High Pressure & Temperature Capability — Operates at 1.5 MPa and 200°C, suitable for concentrating heat-sensitive or high-boiling-point solutions.
- 10 kW Heating Power — Balanced power input for efficient start-up and steady-state operation, with optional electric or steam heating configurations.
- Horizontal Layout — Space-saving design with easier access for maintenance and cleaning; ideal for facilities with limited vertical clearance.
- Standard Compliance — Manufactured under ISO9001, ISO14000, and other applicable quality management systems; meets internationally recognized safety and performance criteria.
- Corrosion-Resistant Materials — Constructed from high-grade stainless steel (316L or equivalent) to withstand aggressive chemical environments.
- Automated Control System — PLC-based control with touchscreen interface for real-time monitoring of temperature, pressure, and flow rates, ensuring consistent product quality.
| Parameter | Value |
|---|---|
| Number of Stages | 5 |
| Max Operating Pressure | 1.5 MPa |
| Max Operating Temperature | 200°C |
| Heating Power | 10 kW |
| Material of Construction | Stainless Steel (316L) |
| Control System | PLC with HMI |
| Compliance Standards | ISO9001, ISO14000, HACCP (on request) |
Advantages & Customer Benefits
- Lower Operating Costs — The multi-effect principle drastically reduces steam consumption, translating to significant savings over the equipment life cycle.
- High Product Yield — Precise temperature and pressure control minimize product degradation, preserving valuable compounds in food, pharmaceutical, and chemical applications.
- Easy Maintenance — Horizontal configuration provides convenient access to tube bundles and internal components, reducing downtime for cleaning or inspection.
- Scalable & Customizable — Available in various capacities and configurations; options include vacuum operation, CIP (clean-in-place) systems, and integration with existing plant networks.
- Global Support — Qingdao Conqinphi provides comprehensive after-sales service, including installation supervision, operator training, and spare parts supply from our Shandong headquarters.
Trust & Credibility
With a dedicated team of 201–300 employees and a factory equipped with advanced manufacturing and testing facilities, Qingdao Conqinphi has successfully exported to major markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our products are certified under multiple international standards, including ISO9001, ISO14000, HACCP, and others available upon request. We have served over 200 industrial clients worldwide, with many returning for repeat orders due to our consistent quality and reliable performance. Our annual export value of US$10–50 million reflects our commitment to excellence. When you choose our Horizontal Multi-effect Evaporator, you are investing in a solution backed by years of engineering expertise and a global reputation for durability.
Contact us today to discuss your specific evaporation requirements. Our team will provide a tailored quotation and technical support to ensure your process runs at peak efficiency.
Frequently Asked Questions (FAQ)
-
What is the typical payback period for this 5-stage evaporator?
Based on energy savings, many clients achieve payback within 12–18 months, depending on operating hours and local energy costs. -
Can this evaporator handle viscous or fouling liquids?
Yes, the horizontal design allows for easier cleaning, and optional features like forced circulation or scraped-surface elements can be added for high-fouling applications. -
What certifications are included with the unit?
Standard units are manufactured under ISO9001, ISO14000, and OHSAS18001 quality systems. Additional certifications such as HACCP or SA8000 can be provided upon request. -
What is the maximum throughput capacity?
Capacity depends on the specific feed concentration and desired final concentration. Contact our sales team with your process parameters for a customized sizing recommendation. -
How long does installation and commissioning take?
Typically 2–4 weeks on-site, depending on site preparation and local conditions. We provide technical supervision throughout the process. -
Is the 10 kW heating power sufficient for large-scale production?
This unit is designed for small to medium-scale operations. For larger capacities, we offer modular designs or higher power options (up to 100 kW) that can be scaled. -
What warranty do you offer?
We provide a standard 12-month warranty covering defects in materials and workmanship, with extended service contracts available. -
Can the evaporator be integrated with existing control systems?
Yes, our PLC supports standard communication protocols (Modbus, Profibus, etc.) for seamless integration into your plant automation.
