Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents our Pharmaceutical Grade Reverse Osmosis Pure Water System for Medical Use. As a professional manufacturer established in 2015 with a factory spanning 10,000–30,000 square meters, we have delivered advanced water treatment solutions to over 30 countries worldwide. This system is specifically designed to meet the rigorous purity standards required in pharmaceutical manufacturing, hospital dialysis, and clinical laboratories. By combining multi-stage reverse osmosis with optional electrodeionization (EDI), it consistently produces water with conductivity below 0.5 μS/cm and TOC as low as 10 ppb, ensuring compliance with pharmacopoeia regulations such as USP, EP, and CP.
Core Features & Technical Specifications
- High-Efficiency RO Membranes: Utilize DOW/FilmTec spiral-wound membranes with >99.5% salt rejection rate, ensuring stable performance.
- Fully Automated PLC Control: Siemens or Omron PLC with color touch screen, enabling real-time monitoring of conductivity, flow, pressure, and temperature.
- Sanitary Design: All wetted parts made of 304/316L stainless steel with 0.6 μm internal surface finish, complying with GMP and FDA requirements.
- CIP/SIP Capability: Integrated clean-in-place and steam-in-place connections for easy sterilization.
- Compact Footprint: Skid-mounted design saves floor space and simplifies installation.
- Low Energy Consumption: High-recovery design (up to 75%) with energy-saving pumps reduces operating costs.
- Comprehensive Pretreatment: Includes multimedia filter, activated carbon filter, water softener, and cartridge filter as standard.
- Optional EDI Module: For ultrapure water requirements (resistivity > 18 MΩ·cm), electrodeionization can be added.
| Parameter | Specification |
| Capacity Range | 100 L/h – 30,000 L/h (custom) |
| Product Water Conductivity | ≤ 0.5 μS/cm (RO) / ≤ 0.1 μS/cm (RO+EDI) |
| TOC | ≤ 10 ppb (RO) / ≤ 5 ppb (RO+EDI) |
| Bacteria | |
| Operating Pressure | 10 – 15 bar |
| Power Supply | 380V / 50Hz 3-Phase (other voltages available) |
Why Choose Our System?
- Pharmaceutical Compliance: Designed to meet USP and requirements, as well as EU GMP Annex 1 guidelines.
- Reliable After-Sales: Our team of 200+ engineers provides global installation, commissioning, and training support. Spare parts are readily available with 24-hour response for emergency cases.
- Customizable Configurations: Whether you need a skid-mounted unit for a small lab or a large central system for a production facility, we can tailor the design to your space and capacity needs.
- Proven Track Record: With an annual export value of US$10–50 million, our systems are trusted by hospitals, pharmaceutical companies, and research institutes across North America, Europe, Asia, and Africa.
- Energy-Saving Operation: Variable frequency drive (VFD) on high-pressure pump reduces electricity consumption by 20% compared to traditional fixed-speed systems.
Trust & Assurance
We are ISO9001 certified and have additional quality management certifications such as HACCP, OHSAS18001, and SA8000. Our factory adheres to strict production standards, and each system undergoes rigorous testing before shipment. We have served customers in more than 30 countries and maintain a strong reputation for on-time delivery and product reliability. By choosing our Pharmaceutical Grade Reverse Osmosis Pure Water System, you are investing in a solution backed by years of experience, continuous innovation, and a dedicated support team. Contact us today for a customized quotation or technical consultation – we look forward to partnering with you on your water purification journey.
Frequently Asked Questions
Q1: What water quality standards does this system meet?
A: The system is designed to comply with USP Purified Water and WFI (Water For Injection) standards, European Pharmacopoeia, and Chinese Pharmacopoeia. Typical output water quality: conductivity
Q2: Is the system fully automated? Can we monitor it remotely?
A: Yes, the system features a PLC with HMI touch screen, providing real-time data and alarms. Remote monitoring via Ethernet or 4G module is available as an optional upgrade.
Q3: What is the typical lifespan of the RO membranes?
A: Under proper pretreatment and regular maintenance, RO membranes can last 2–3 years. Our system includes automatic membrane flush and chemical cleaning function to extend membrane life.
Q4: Can the system handle varying feed water quality?
A: Absolutely. The pretreatment train (multi-media filter, carbon filter, softener) is designed to handle TDS up to 2000 ppm and turbidity
Q5: How long does installation and commissioning take?
A: Typically, installation and commissioning are completed within 5–7 working days for standard systems. We provide on-site support or remote guidance depending on your location.
Q6: What certifications does your company hold?
A: We are ISO9001, ISO14001, OHSAS18001, HACCP, and SA8000 certified. For specific markets, we can also provide other certificates as required.
Q7: Do you offer a warranty and spare parts?
A: Yes, we provide a standard 1-year warranty covering defects, with an extended warranty option up to 3 years. A full spare parts list is included, and we maintain a global warehouse for rapid delivery.
Q8: What is the minimum order quantity?
A: We accept orders starting from 1 unit. For large projects, we offer volume discounts and flexible payment terms. Please contact our sales team for details.
