Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a leading manufacturer with over 8 years of expertise in industrial wastewater treatment solutions. Our Semi-Automatic Forced Circulation High-Salt Wastewater Treatment Evaporator (10m³/day) is engineered to efficiently separate solids from high-salinity effluents, reducing waste volume and recovering valuable water. Designed for industries facing strict discharge regulations, this evaporator combines robust construction, energy-saving forced circulation technology, and user-friendly semi-automatic controls – offering a reliable, cost-effective solution for your wastewater challenges.
Every unit is built in our 10,000–30,000 m² factory in Qingdao, backed by a skilled team of 201–300 employees and an export value exceeding US$10 million annually. We serve markets across North America, Europe, Asia, Africa, Oceania, and beyond, ensuring global standards of quality and service.
Key Features & Technical Advantages
- Forced Circulation Design: Maintains high heat transfer efficiency and prevents scaling even with highly concentrated brines. Suitable for sodium chloride, sulfate, and other salt-rich streams.
- Semi-Automatic Operation: PLC-based control with touch-screen interface reduces manual intervention while allowing flexible parameter adjustments. Operators can easily monitor temperature, pressure, and flow rates.
- High Salt Tolerance: Constructed with corrosion-resistant materials (e.g., 316L SS, titanium, or duplex stainless steel) to withstand chloride-induced stress corrosion cracking.
- Low Energy Consumption: Forced circulation evaporators typically consume 20–30% less energy than natural circulation types for high-viscosity or high-salinity feeds.
- Compact Modular Design: Skid-mounted for easy installation and minimal footprint. Compatible with existing wastewater treatment plants.
- Scalable Capacity: The 10 m³/day unit can be combined in parallel for larger throughputs.
Technical Specifications (Typical)
| Parameter | Specification |
|---|---|
| Evaporation Capacity | 10 m³/day (adjustable) |
| Feed TDS Range | 5,000 – 250,000 ppm |
| Evaporation Temperature | 60 – 100 °C (vacuum optional) |
| Operating Pressure | Atmospheric / slight vacuum (optional) |
| Heat Source | Steam (0.3–0.6 MPa) or electric heater |
| Material of Construction | 316L SS / Titanium / Duplex (customizable) |
| Control System | Siemens / Mitsubishi PLC + 7-inch HMI |
| Power Supply | 380V / 50Hz (or customized) |
Customer Benefits
- Zero Liquid Discharge (ZLD) ready – recover up to 95% of water from high-salt wastewater, minimizing disposal costs.
- Reduced maintenance thanks to anti-scaling forced circulation and self-cleaning options.
- Flexible integration with pre-treatment (e.g., softening, RO) and post-treatment (crystallizer, dryer).
- Compliance with environmental regulations – meets discharge limits and helps avoid penalties.
- Local technical support – we offer on-site commissioning, training, and after-sales service.
Why Choose Qingdao Conqinphi?
Since 2015, our company has focused on providing comprehensive environmental solutions. With a factory spanning 10,000–30,000 m² and a workforce of 201–300 experienced professionals, we have delivered evaporators to clients in over 30 countries. Our annual export value exceeds US$10 million, a testament to the trust placed in us by global partners. We hold multiple management system certifications (ISO9001, ISO14000, OHSAS18001, etc.), ensuring consistent quality and responsible manufacturing.
Our Semi-Automatic Forced Circulation Evaporator is the result of continuous R&D and field feedback. It is designed to handle the most challenging high-salt wastewater in industries such as chemical, pharmaceutical, textile dyeing, landfill leachate, and oil & gas. We offer customized configurations to match your specific feed composition and site conditions.
Ready to reduce your wastewater volume and recover valuable water? Contact us today for a detailed proposal, site survey, or pilot test. Our engineering team is available 24/7 to answer your questions.
Frequently Asked Questions (FAQ)
-
Q: What types of high-salt wastewater can this evaporator handle?
A: It is suitable for a wide range of saline streams, including sodium chloride, sodium sulfate, calcium chloride, and complex industrial brines. A feed analysis is recommended for best design. -
Q: Is the semi-automatic control easy to operate?
A: Yes. The touch-screen HMI allows intuitive monitoring and adjustment. Basic training for operators is provided, and the system includes alarms and safety interlocks. -
Q: Can it be upgraded to full automatic later?
A: Absolutely. The PLC and sensors are already compatible; we can add automatic valves, CIP, and remote monitoring as options. -
Q: What is the typical energy consumption?
A: For a 10 m³/day unit, steam consumption is approximately 1.1–1.3 tons per ton of evaporated water (economizer can reduce it further). Electrical consumption is around 15–25 kW depending on pump and vacuum needs. -
Q: How long does delivery take?
A: Standard lead time is 45–60 working days after down payment. Expedited options may be available for urgent projects. -
Q: Do you provide installation and commissioning support?
A: Yes. We offer on-site supervision for installation and commissioning, plus remote technical assistance throughout the warranty period (typically 12 months). -
Q: What certifications does your company hold?
A: Our quality management systems are certified under ISO9001, ISO14001, OHSAS18001, and others. We also have HACCP, TL900, SA8000, etc., applicable to different product lines. Please inquire for specific product certificates if needed. -
Q: Can I visit your factory in Qingdao?
A: Certainly. We welcome clients to tour our 10,000–30,000 m² facility and witness our production processes. Contact us to arrange a visit.
