Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a leading manufacturer with over 9 years of expertise in environmental equipment. Our Compact Three-effect Forced Circulation Evaporation Crystallizer with explosion-proof design is engineered to deliver reliable, high-efficiency concentration and crystallization for demanding industrial processes. Built for safe operation in hazardous environments, this unit combines space-saving construction with robust performance, making it an ideal choice for wastewater reduction and chemical recovery.
At our 10,000-30,000 sqm factory, we integrate advanced manufacturing techniques to ensure every crystallizer meets strict quality standards. With annual exports exceeding US$10 million to markets across North America, Europe, and Asia, our products have proven their value in diverse applications. The unit's three-effect forced circulation design maximizes energy efficiency while minimizing footprint – a critical advantage for plants with space constraints.
Key Features & Technical Specifications
- Three-effect forced circulation: Achieves high concentration ratios (up to 30% solids) with reduced steam consumption compared to single-effect systems.
- Explosion-proof construction: All electrical components (motors, sensors, control panel) comply with international standards (e.g., ATEX/IECEx optional), ensuring safe operation in flammable environments.
- Compact modular design: Pre-assembled skid-mounted system reduces installation time and occupies minimal floor space (approx. 6m x 3m for a 1000 L/h model).
- 380V/60Hz power compatibility: Standard motor and heater ratings for North American and other 60Hz markets, with optional voltage/frequency customization.
- Robust material selection: Wetted parts available in 316L stainless steel or higher alloys (Hastelloy, Duplex) for corrosive or abrasive feeds.
- PLC-based automation: Touchscreen HMI for real-time monitoring of temperature, pressure, flow, and level; optional remote access via SCADA.
| Parameter | Specification |
|---|---|
| Evaporation capacity | 500 – 5000 L/h (customizable) |
| Number of effects | 3 |
| Circulation method | Forced circulation (external pump) |
| Power supply | 380V, 60Hz, 3-phase |
| Explosion-proof rating | Ex d IIB T4 (or equivalent, optional) |
| Main material | 316L SS (other alloys available) |
| Control system | PLC + HMI (Siemens/Mitsubishi) |
Why Choose Our Crystallizer?
- Energy saving: Three-effect design reduces steam consumption by up to 60% compared to single-effect units, lowering operational costs.
- Safety first: Explosion-proof components ensure compliance with hazardous area regulations, protecting personnel and assets.
- Easy maintenance: Forced circulation minimizes scaling and fouling; quick-open design for cleaning and inspection.
- Proven reliability: Thousands of operating hours in chemical, pharmaceutical, and food processing industries globally.
Trusted by clients in over 50 countries, Qingdao Conqinphi delivers more than just equipment – we provide end-to-end solutions including custom design, installation supervision, and after-sales support. Our facility spans 10,000-30,000 sqm with 201-300 skilled employees, ensuring fast delivery and rigorous quality control. With certifications like ISO9001, ISO14000, and OHSAS18001 (company-level), we adhere to international management standards.
Contact our team today to discuss your specific evaporation requirements. We offer free process evaluation and a 12-month warranty on all crystallizers. Let us help you achieve zero liquid discharge (ZLD) or valuable byproduct recovery with our compact explosion-proof evaporation crystallizer.
Frequently Asked Questions
-
Q: Can this crystallizer handle corrosive liquids like acidic wastewater?
A: Yes, the wetted parts can be constructed from Hastelloy, titanium, or other corrosion-resistant alloys upon request. Standard 316L SS is suitable for many chloride-containing streams. -
Q: What is the typical footprint for a 1000 L/h unit?
A: Approx. 6m (L) x 3m (W) x 4m (H), but dimensions vary with capacity. Our engineers provide a detailed layout during proposal. -
Q: Is the explosion-proof certification included by default?
A: The design follows explosion-proof principles, but specific certification (e.g., ATEX, IECEx, NEC) can be added as an option based on your region's requirements. -
Q: What after-sales support do you offer?
A: We provide installation guidance, commissioning, spare parts supply, and remote technical support. On-site service is available at an extra cost. -
Q: How long does delivery usually take?
A: Lead time is typically 30-60 days after order confirmation, depending on customization level and current production schedule. -
Q: Can the unit run on 50Hz power supply?
A: Yes, with a suitable transformer or VFD. Please specify your local power conditions during inquiry. -
Q: What maintenance is required?
A: Routine cleaning of heat exchange surfaces every 3-6 months, pump seal inspection, and lubrication of moving parts. We provide a detailed maintenance manual. -
Q: Do you have references in the chemical industry?
A: Absolutely. We have supplied similar units to multiple chemical plants in Europe and Asia. Reference lists are available upon request.
