Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents the Automatic Three-effect Forced Circulation Evaporation Crystallizer (Model: 15kW, 800kg/h). As a leading manufacturer established in 2015 with a factory spanning 10,000–30,000 square meters and over 200 skilled employees, we specialize in high-performance evaporation and crystallization solutions. This advanced system integrates forced circulation and multi-effect evaporation to achieve superior energy efficiency and outstanding crystallization output, making it ideal for industries requiring reliable liquid concentration and solid recovery.
The unit is designed to handle challenging liquids such as high-salinity wastewater, chemical solutions, and brine, delivering consistent 800 kg/h evaporative capacity with only 15 kW power consumption. Its automatic control ensures minimal manual intervention, while the three-effect design significantly reduces steam consumption compared to single-effect systems. Whether you need to reduce waste volume or recover valuable solids, this crystallizer offers a cost-effective and environmentally friendly solution.
Below are the key technical specifications and features that set this crystallizer apart:
| Parameter | Value |
|---|---|
| Evaporating Capacity | 800 kg/h |
| Power Consumption | 15 kW |
| Number of Effects | Three |
| Circulation Type | Forced Circulation |
| Operating Temperature | Customizable (up to 150°C) |
| Material of Construction | SS304 / SS316L / Duplex (optional) |
| Control System | PLC + HMI touch screen |
| Steam Consumption | Approx. 0.3–0.4 kg steam per kg water evaporated |
Key Features & Benefits:
- Three-effect design – reduces energy consumption by reusing vapor from previous effects, cutting operating costs significantly.
- Forced circulation – prevents scaling and fouling, ensures stable long-term operation even with high-viscosity or high-concentration liquids.
- Automatic PLC control – allows precise monitoring and adjustment of temperature, pressure, and flow rates, minimizing human error.
- Compact footprint – integrated structure saves floor space, easy to install in existing production lines.
- Customizable materials – available in stainless steel 304/316L or duplex for corrosive environments, ensuring durability.
- High crystallization efficiency – produces uniform crystals with low moisture content, suitable for salt recovery and zero-liquid-discharge (ZLD) applications.
- Low maintenance – simple design with accessible components, supported by our experienced after-sales team.
Why Choose Qingdao Conqinphi?
With an annual export value of US$10–50 million and a workforce of 201–300 professionals, we have supplied evaporation systems to markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our factory is certified with ISO9001, ISO14000, OHSAS18001, and multiple other quality management standards (HACCP, TL900, SA8000, etc.), ensuring that every product meets rigorous international requirements. We ship via the Port of Qingdao, providing efficient logistics worldwide.
Our engineering team can tailor the crystallizer to your specific liquid composition, temperature requirements, and desired output. We also offer comprehensive after-sales support including installation guidance, commissioning, and spare parts supply.
Invest in a reliable, energy-efficient evaporation crystallizer that delivers consistent performance. Contact us today for a customized quotation or technical consultation. Let us help you achieve your wastewater reduction and resource recovery goals.
Frequently Asked Questions (FAQs)
-
Q: What type of liquids can this crystallizer handle?
A: It is designed for high-salinity wastewater, brine, chemical solutions, and other liquids with high dissolved solids. Forced circulation makes it suitable for liquids prone to scaling. -
Q: How does the three-effect design save energy?
A: The vapor generated in the first effect is used as heating medium for the second effect, and similarly for the third. This reduces steam consumption by up to 60–70% compared to a single-effect system. -
Q: Is the control system user-friendly?
A: Yes, the PLC with HMI touch screen provides intuitive operation. Parameters like temperature, pressure, and flow are automatically regulated, and alarms alert operators of any deviations. -
Q: What is the typical lifespan of the equipment?
A: With proper maintenance and corrosion-resistant materials (e.g., SS316L), the system can operate for 10–15 years. Regular cleaning of the heat exchanger and circulation pump extends service life. -
Q: Can the capacity be customized?
A: Yes, we offer customization from 200 kg/h up to 5000 kg/h. The 800 kg/h standard model is a popular choice for medium-scale operations. -
Q: What certifications does the product have?
A: Our manufacturing facility holds ISO9001, ISO14000, OHSAS18001, and many other certifications. Specific product certifications can be provided upon request (e.g., CE for European markets). -
Q: Do you provide installation and training?
A: Yes, we offer on-site installation supervision and operator training. Detailed manuals and remote support are also available. -
Q: What is the delivery time?
A: Typically 30–45 days after order confirmation, depending on customization and shipping method. We cooperate with reliable logistics partners to ensure timely delivery.
