Home > Manufacturing & Processing Machinery > Spraying Machinery & Spreading Equipment > Other Spraying Machinery & Spreading Equipment > Custom Adjustable Size Iron Cabinet Powder Coating Line for Indoor Cabinet Anti‑corrosion Surface Finishing
Custom Adjustable Size Iron Cabinet Powder Coating Line for Indoor Cabinet Anti‑corrosion Surface Finishing
Product Spotlights
Custom adjustable size designed for indoor iron cabinets; anti-corrosion powder coating with high adhesion; PLC-controlled, energy-saving oven; servo-driven quick changeover for varied cabinet dimensions; ISO9001 certified manufacturer with global export experience and strong after-sales support.
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Warranty:
1 year (extended available)
Material:
Steel frame, stainless steel coating booth
Coating Type:
Thermoset powder coating
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Compact Space‑saving Iron Cabinet Powder Coating Line for Medium‑sized Iron‑cabinet Fabrication FactoriesNegotiableMOQ: 1 Set -
Heavy‑duty Floor‑mounted Iron Cabinet Powder Coating Line for Furniture Iron‑cabinet Workshop Spraying ProcessingNegotiableMOQ: 1 Set
-
Digital PLC Controlled Iron Cabinet Powder Coating Line to Stabilize Coating Thickness on Iron Cabinet PanelsNegotiableMOQ: 1 Set
-
Complete Turn‑key Iron Cabinet Powder Coating Line as Replacement for Old‑style Manual Coating EquipmentNegotiableMOQ: 1 Set
-
Compact Floor Type Small Cabinet Metal Powder Coating Line for Local Small Metal Cabinet Manufacturing FactoriesNegotiableMOQ: 1 Set
Warranty
1 year (extended available)
Material
Steel frame, stainless steel coating booth
Coating Type
Thermoset powder coating
Adjustable Cabinet Size
Yes (width: 500-1500mm, height: 500-2000mm)
Application
Indoor cabinet anti-corrosion finishing
Conveyor Type
Overhead chain conveyor / floor conveyor (optional)
Power Supply
380V/50Hz, 3-phase (customizable)
Heating Source
Gas / electric / diesel (customizable)
Certification
ISO9001:2015
Brand
Deqing Leixin
As a leading manufacturer established in 2011, Deqing Leixin Coating Equipment Co., Ltd. specializes in designing and producing high-performance powder coating lines. Our Custom Adjustable Size Iron Cabinet Powder Coating Line is engineered specifically for indoor cabinet anti-corrosion surface finishing, offering exceptional flexibility and durability. With 51-100 skilled employees and over 1.5 million USD annual export value, we ensure every system meets rigorous quality standards. This coating line is ideal for manufacturers who need to process cabinets of varying dimensions without sacrificing efficiency or coating quality.
The system is built with a robust steel frame and a precision-controlled coating booth, accommodating cabinets from 500mm to 1500mm in width and 500mm to 2000mm in height. It integrates a powder recovery system, electrostatic spray guns, and a curing oven to deliver uniform, long-lasting corrosion resistance. Whether you are finishing kitchen cabinets, office storage units, or industrial enclosures, this line provides consistent results while reducing material waste and energy consumption.
Key Features
- Adjustable Cabinet Size: Width and height can be quickly reconfigured via servo-driven guide rails, enabling batch processing of different cabinet sizes with minimal changeover time.
- Advanced Anti-Corrosion Performance: The powder coating forms a thick, seamless protective layer that resists scratches, humidity, and chemical exposure, extending cabinet lifespan.
- High Efficiency Production: Conveyor speed ranges from 1.5 to 6 m/min, paired with a 4-stage pretreatment process (degreasing, rinsing, phosphating, sealing) to ensure optimal adhesion.
- Energy-Saving Design: Insulated curing oven with recirculating hot air reduces heat loss by up to 20%, lowering operational costs.
- User-Friendly Control: PLC touchscreen interface allows operators to monitor temperature, conveyor speed, and powder flow in real time.
- Eco-Friendly: Closed-loop powder recovery system captures over 95% of overspray, minimizing waste and complying with environmental regulations.
Technical Specifications
| Parameter | Value |
|---|---|
| Conveyor Speed | 1.5 – 6 m/min (adjustable) |
| Max Cabinet Width (W) | 1500 mm |
| Min Cabinet Width (W) | 500 mm |
| Max Cabinet Height (H) | 2000 mm |
| Min Cabinet Height (H) | 500 mm |
| Curing Oven Temperature Range | 180°C – 230°C |
| Number of Spray Guns | 4 – 8 (customizable) |
| Powder Recovery Efficiency | ≥95% |
| Overall Dimensions (L×W×H) | According to customer layout |
| Power Consumption | Approx. 80-120 kW (depending on configuration) |
Customer Benefits
- Reduced Downtime: Quick size adjustments allow you to run multiple cabinet models in one shift, increasing overall equipment effectiveness (OEE).
- Superior Finish Quality: Consistent coating thickness (60-120μm) achieved through automatic voltage control and reciprocator movement.
- Low Maintenance: Self-cleaning powder injectors and durable bearings reduce replacement frequency.
- Scalable Design: Modular construction enables future expansion—add more spray booths or a second oven as production grows.
- Global Support: Our engineering team provides remote troubleshooting and on-site installation guidance, with spare parts shipped from our Huzhou warehouse.
Backed by over a decade of experience and ISO9001 certification, Deqing Leixin has supplied powder coating lines to markets worldwide, including North America, Europe, Southeast Asia, and Oceania. Our 1,000-3,000 sqm factory and 51-100 workforce ensure timely delivery and rigorous quality control. We ship from Ningbo and Shanghai ports, with annual exports exceeding US$1.5 million. Choose our adjustable iron cabinet powder coating line for a reliable, cost-effective solution that elevates your production capabilities. Contact us today for a custom quote or free consultation.
Frequently Asked Questions (FAQ)
-
Q: What cabinet sizes can this line handle?
A: The standard adjustable range is width 500-1500mm and height 500-2000mm. Custom ranges are available upon request. -
Q: Is the line suitable for iron cabinets only?
A: While optimized for iron (steel) cabinets, it can also process aluminum or stainless steel cabinets with appropriate pretreatment adjustment. -
Q: How long does installation take?
A: Typical installation and commissioning take 2-4 weeks, depending on site preparation and complexity. Our engineers can supervise the process remotely or on-site. -
Q: What after-sales support do you provide?
A: We offer 1-year warranty, lifetime technical support, and a readily available stock of common spare parts. Training for operators is included. -
Q: Can the line be integrated with existing conveyors?
A: Yes, we can customize the interface to match your current material handling system. Our design is flexible for retrofit projects. -
Q: What colors are available for the powder coating?
A: We recommend using your preferred powder supplier; our system supports any thermoset powder, including RAL colors, textures, and metallic finishes. -
Q: How energy-efficient is this line?
A: Our recirculating hot air oven reduces energy consumption by up to 20% compared to conventional ovens. Actual savings depend on production volume and insulation. -
Q: Does this line meet environmental regulations?
A: Yes, the closed-loop powder recovery system and efficient filtration ensure compliance with most local emission standards. Additional filters can be added if needed.
