Fully Automatic Small Cabinet Metal Powder Coating Line for Mass Production of Miniature Storage Metal Cabinets
Product Spotlights
Fully automatic small cabinet powder coating line designed for high-volume miniature metal cabinet production. PLC controlled, compact footprint, >95% powder recovery, energy-saving oven, and quick color change. ISO9001 certified, backed by 13 years of manufacturing experience and global export. Customizable to your workshop.
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
automation:
fully automatic
application:
mass production of miniature storage metal cabinets
powder type:
thermosetting powder
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Space Saving Modular Small Cabinet Metal Powder Coating Line for Startup Metal Cabinet Processing WorkshopsNegotiableMOQ: 1 Set -
PLC Controlled Small Cabinet Metal Powder Coating Line With 2m/min Conveyor SpeedNegotiableMOQ: 1 Set
-
Digital Regulated Small Cabinet Metal Powder Coating Line for Uniform Coating on Mini Metal Cabinet ComponentsNegotiableMOQ: 1 Set
-
PLC Controlled Small Cabinet Metal Powder Coating Line to Maintain Even Coating on Thin Metal Cabinet PanelsNegotiableMOQ: 1 Set
-
Energy Saving Powder Recovery Small Cabinet Metal Powder Coating Line for Small Batch Cabinet Spraying WorkNegotiableMOQ: 1 Set
automation
fully automatic
application
mass production of miniature storage metal cabinets
powder type
thermosetting powder
production capacity
customizable (e.g., 100-500 cabinets per shift)
conveyor speed
adjustable (0.5-3 m/min)
oven temperature
180-220 °C
floor space
compact design (10-20 m length)
power supply
380V/50Hz (customizable)
coating thickness
60-120 μm (adjustable)
certification
ISO9001
Welcome to Deqing Leixin Coating Equipment Co., Ltd. – a trusted manufacturer established in 2011 with a 1,000-3,000 m² factory and ISO9001 certification. Our Fully automatic Small cabinet metal powder coating line is specifically engineered for mass production of miniature storage metal cabinets. This turnkey solution delivers high throughput, consistent coating quality, and minimal labor cost, helping you meet tight deadlines while maintaining competitive pricing. With annual export value reaching US$1-1.5 million, we serve clients across North America, Europe, Southeast Asia, and more.
Key Features & Technical Specifications
- Fully Automatic Operation: PLC-controlled conveyor system, automatic powder spray guns, and integrated control panel reduce manual intervention by up to 80%.
- Compact Footprint: The line is designed for small workshops – only 10-20 meters in length, yet capable of processing hundreds of cabinets per shift.
- High-Efficiency Powder Recovery: Cyclone + cartridge filtration system recovers >95% overspray powder, cutting material waste and saving costs.
- Uniform Coating: Precision spray gun configuration delivers even film thickness (60-120 μm), ensuring excellent adhesion and corrosion resistance.
- Energy-Saving Oven: Insulated curing oven with PID temperature control maintains stable 180-220°C, reducing power consumption by 15% compared to traditional models.
- Quick Color Change: Fast powder hopper and gun cleaning system enables color change in under 10 minutes, ideal for multi-product production.
| Parameter | Value (Standard) | Remarks |
|---|---|---|
| Line Length | 12 m (customizable) | Can be extended for larger cabinets |
| Conveyor Speed | 0.5 – 3 m/min | Adjustable via touchscreen |
| Spray Guns | 4 – 8 units (optional) | Auto or manual trigger |
| Curing Temperature | 180 – 220 °C | Uniform ±5°C |
| Powder Recovery Rate | ≥95% | Reusable powder |
| Power Supply | 380V/50Hz (3-phase) | Other voltages available |
| Max. Workpiece Size | 800×600×600 mm | Supports your miniature cabinets |
Customer Benefits
- Boost Productivity: The fully automatic line runs 24/7 with minimal supervision, enabling daily output of 200-500 cabinets (dependent on size).
- Lower Operating Costs: High powder recovery, energy-efficient oven, and reduced manpower translate to 20-30% savings on production cost.
- Consistent Quality: No more uneven coating or defects – each cabinet gets the same professional finish, enhancing your brand reputation.
- Easy Operation: Touchscreen HMI with pre-set recipes, fault diagnostics, and remote support make it beginner-friendly.
- Scalable Design: Modules can be added later for increased capacity or additional pretreatment stages.
Trust & After-Sales Support
We are a 51-100 employee manufacturer with ISO9001:2015 certified quality management. Our factory in Huzhou, Zhejiang, China, has shipped equipment to over 15 countries including the US, Germany, Brazil, and Australia. We provide comprehensive support: free layout design, installation guidance, training videos, and 1-year warranty. Your investment is safe with our proven track record – annual export value of US$1-1.5 million speaks for itself. Contact us today for a customized quotation or to arrange a factory inspection.
Frequently Asked Questions
-
Q: What is the maximum size of cabinets your line can handle?
A: The standard line accommodates workpieces up to 800×600×600 mm. For larger cabinets, we offer customized extensions. -
Q: How fast can I switch colors?
A: Our quick-change system allows complete color switch in less than 10 minutes, including powder hopper and gun cleaning. -
Q: Do I need a special pretreatment section?
A: We recommend a pretreatment stage (e.g., degreasing, phosphating) for optimal adhesion. We can supply a pretreatment module separately. -
Q: What types of powder coating are compatible?
A: The line works with most thermosetting powders: epoxy, polyester, polyurethane, hybrid, etc. -
Q: How many operators are needed?
A: Typically 1-2 operators for loading/unloading; the coating process itself is fully automatic. -
Q: Can the line be installed in a small workshop with limited headroom?
A: Yes, we design the line height to suit your building. Minimum ceiling height: 3.5 meters. -
Q: What is the power consumption?
A: Average power consumption is approximately 30-45 kWh per hour depending on production speed and oven load. -
Q: Do you provide installation and training?
A: Yes, we offer on-site installation supervision and remote training. Detailed manuals and video guides are also included.
Ready to scale up your cabinet production? Submit an inquiry to get a personalized solution from Deqing Leixin – your reliable partner since 2011.
