Qingdao Conqinphi Environmental Technology Group Co., Ltd., established in 2015 and operating a modern factory spanning 10,000–30,000 square meters, is proud to introduce our advanced Industrial MVR Evaporator Desalination Plant. With a proven annual export value of US$10–50 million and a dedicated team of 201–300 professionals, we deliver reliable, energy-efficient desalination solutions tailored for global industries. This MVR evaporator system, compliant with ISO standards, achieves a robust output of 10,000 liters per day (10000L/D) and operates on standard 220V/380V power supply, making it ideal for both developed and emerging markets.
Our MVR (Mechanical Vapor Recompression) technology recycles latent heat from vapor, reducing energy consumption by up to 60–80% compared to traditional thermal evaporators. The plant is engineered for long-term durability using premium stainless steel materials (SUS304/316L), with fully automated PLC control ensuring stable operation and minimal manual intervention. Whether you need to desalinate seawater, treat industrial brine, or concentrate chemical solutions, this unit offers customizable configurations to meet your specific capacity and purity requirements.
Below is a snapshot of the key technical specifications:
| Model | CQ-MVR-10000 |
| Daily Output | 10,000 Liters (10 m³/day) |
| Power Supply | 220V/380V, 3-phase, 50/60Hz (other voltages available) |
| Compressor Power | 45–75 kW (adjustable) |
| Evaporation Temperature | 45–95°C (depending on feed water) |
| Material of Construction | SS304 / SS316L (customizable) |
| Control System | PLC + HMI touch screen, remote monitoring optional |
| Certification | ISO compliant (ISO9001, ISO14000, OHSAS18001) |
Key Features & Benefits:
- Energy Efficiency: MVR technology reduces electricity consumption by 60–80% compared to conventional evaporators, lowering your operating costs significantly.
- High Recovery Rate: Achieves up to 95% water recovery in seawater desalination, minimizing brine discharge and environmental impact.
- Modular Design: Compact footprint with skid-mounted construction simplifies installation and makes scaling up easy.
- Automated Operation: PLC-based controls with real-time data logging enable unattended operation, reducing labor costs.
- Robust Build: All wetted parts are made of corrosion-resistant stainless steel, ensuring long service life even in harsh saline environments.
- Flexible Configurations: Options include multi-effect preheating, anti-scaling dosing, and CIP cleaning systems to handle various feed water qualities.
- Global Compatibility: Designed to operate on 220V/380V power (50/60Hz) and meets international voltage standards.
- Low Maintenance: Simple structure with few moving parts reduces downtime; self-cleaning features are available.
Application Scenarios:
- Seawater desalination for drinking water or industrial use
- Zero liquid discharge (ZLD) systems for chemical and pharmaceutical industries
- Concentration of brine, RO reject, and high-salinity wastewater
- Food and beverage processing (e.g., juice concentration)
Trusted by Global Clients: Qingdao Conqinphi has supplied industrial MVR systems to markets across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, and Europe. Our 10,000–30,000 m² factory hosts advanced manufacturing lines and rigorous quality control processes. With certifications including SA8000, TL9000, and multiple ISO standards, we ensure that every unit undergoes systematic inspection before shipment from Qingdao Port. Our 201–300 experienced engineers and technicians provide turnkey solutions, from site assessment to after-sales support.
Why Choose Our MVR Desalination Plant? You get a customizable, energy-saving, and ISO-compliant system directly from a reliable manufacturer with over 9 years of expertise. We offer competitive pricing without compromising quality, flexible delivery terms, and a 12-month warranty with extended options available upon request. Contact us today for a tailored quotation or technical consultation – let us help you turn your water challenges into sustainable solutions.
Frequently Asked Questions (FAQs)
-
Q: How does MVR technology differ from traditional evaporation?
A: MVR uses a mechanical compressor to raise the pressure and temperature of vapor, which is then used as a heat source for evaporation. This recycles latent heat, reducing energy consumption by 60–80% compared to single-effect or multi-effect evaporators. -
Q: What feed water quality is required for this plant?
A: The system can handle feed water with TDS ranging from 5,000 to 350,000 ppm. For seawater, pre-filtration is recommended to remove suspended solids. Customizable pretreatment modules are available. -
Q: Is the equipment easy to install and operate?
A: Yes. The skid-mounted design allows quick installation on a concrete base. The PLC system provides intuitive operation via touch screen, with automatic start/stop and alarm functions. We provide detailed manuals and remote technical support. -
Q: What certifications does the product hold?
A: Our MVR evaporator plant is manufactured under ISO certified processes (ISO9001, ISO14000, OHSAS18001). Our company also holds HACCP, TL9000, QS9000, and other quality management certifications. Specific certificates for your region can be provided upon request. -
Q: What is the typical energy consumption per liter of water produced?
A: For seawater (35,000 ppm TDS), the specific energy consumption is approximately 8–12 kWh per cubic meter (0.008–0.012 kWh per liter), depending on feed temperature and recovery rate. This is significantly lower than thermal distillation methods. -
Q: Can the output be scaled up or down?
A: Absolutely. We offer standard models from 5,000 L/D to 50,000 L/D. Additional units can be paralleled for higher capacity. Contact us for a customized solution based on your daily demand. -
Q: What after-sales support do you provide?
A: We provide a 12-month warranty covering manufacturing defects. Technical support via phone, email, and video is available 24/7. Spare parts can be shipped quickly from our Qingdao warehouse. On-site commissioning assistance can be arranged. -
Q: What is the delivery time and shipping cost?
A: For standard models, delivery time is 30–45 days after order confirmation. We ship FOB Qingdao or CIF to your nearest port. Shipping costs depend on destination and are quoted upon request.
