As a dedicated manufacturer of electrical protection components, Jinhua Dika Electrical Equipment Co., Ltd. specializes in delivering reliable and high-performance solutions for modern power grids. Our Indoor High Voltage HRC Fuse 10kV XRNT is engineered to provide superior protection for your power distribution systems. Designed for demanding indoor applications, this fuse offers precise interruption of fault currents, safeguarding valuable equipment like transformers and switchgear from damage due to overloads and short circuits. With a focus on safety, durability, and consistent performance, our fuses are a trusted choice for engineers and project managers seeking to enhance the resilience of their electrical infrastructure.
This product is meticulously crafted to meet the rigorous demands of medium-voltage power distribution. Key features and technical specifications include:
- High Reliability: The High Rupturing Capacity (HRC) design ensures the fuse can safely interrupt high fault currents, preventing arc hazards and system damage.
- Precise Protection: The time-current characteristic is carefully calibrated to provide selective coordination with other protective devices, minimizing the scope of any outage.
- Robust Construction: The fuse body is made from high-strength ceramic or epoxy resin, offering excellent mechanical strength and thermal stability.
- Stable Performance: The fuse element, typically made of silver or silver alloy, provides stable resistance and consistent melting characteristics over its service life.
- Easy Installation and Monitoring: The XRNT design is suitable for standard indoor fuse bases, and many models feature an indicator or striker pin for visual confirmation of operation.
- Versatile Application: Primarily used for the protection of power transformers, voltage transformers, and feeders in indoor switchgear, ring main units, and compact substations.
Below is a summary of typical technical parameters. Specific values for rated current and breaking capacity are customizable based on your system requirements.
| Parameter | Specification |
|---|---|
| Rated Voltage (Un) | 10 kV |
| Rated Frequency | 50/60 Hz |
| Rated Current Range (In) | Commonly from 10A to 200A (Customizable) |
| Breaking Capacity | Designed for high fault levels (Specific value available upon request) |
| Standards | Generally complies with IEC 60282-1 |
| Mounting Position | Indoor, any position (as per design) |
| Ambient Temperature | Typically -25°C to +55°C for operation |
The advantages of integrating our HRC fuses into your distribution system are clear. They provide a cost-effective and maintenance-free method of protection. By reliably isolating faulted sections, they help prevent catastrophic failures, reduce downtime, and extend the lifespan of connected equipment. This translates to lower total cost of ownership and improved operational safety for your facility.
Trust is paramount in electrical safety components. Jinhua Dika Electrical Equipment Co., Ltd. operates with a firm commitment to quality, supported by a comprehensive quality management system. Our products reach a wide range of markets, including North America, Europe, Southeast Asia, and beyond, with an annual export value between US$1 Million and US$1.5 Million, demonstrating global acceptance. We ship from major ports like Shanghai, Tianjin, Guangzhou, and Ningbo for efficient logistics. Choosing our 10kV XRNT HRC Fuse means selecting a component backed by manufacturing expertise, a commitment to international standards, and a proven track record of protecting critical power distribution assets worldwide. Contact us today to discuss how we can tailor this solution to your specific project needs.
Frequently Asked Questions (FAQ)
Q1: What does "HRC" stand for in this fuse?
A1: HRC stands for "High Rupturing Capacity." It indicates that the fuse is designed to safely interrupt very high fault currents, significantly higher than its rated current, without causing dangerous arcing or rupture of the fuse body.
Q2: Is this fuse suitable for outdoor installations?
A2: No, the XRNT series described here is specifically designed for indoor use. Outdoor applications require fuses with different housing materials and sealing to withstand weather conditions like rain, UV exposure, and wide temperature fluctuations.
Q3: How do I select the correct rated current for my application?
A3: The rated current should be chosen based on the full-load current of the circuit or equipment you are protecting (e.g., transformer), with a margin for temporary overloads. It is crucial to consult the equipment specifications and perform coordination studies. We can provide technical support for this selection.
Q4: Does the fuse provide any indication after it has operated?
A4: Many models within the XRNT range are equipped with an indicator or a striker pin mechanism. Upon operation, this indicator extends or changes state, providing a clear visual signal that the fuse has blown, which aids in quick fault identification.
Q5: What are the typical applications for a 10kV indoor HRC fuse?
A5: Common applications include protection of:
- Power transformers (primary or secondary side)
- Voltage transformers (Potential Transformers)
- Feeders and cables in indoor switchgear and RMUs (Ring Main Units)
- Motors and capacitor banks in medium-voltage systems
Q6: Are your fuses certified to international standards?
A6: Our manufacturing processes adhere to stringent quality management systems. While specific standard certifications (like IEC) for the product can be confirmed upon request, our operations are guided by principles that ensure product reliability and performance consistency.
Q7: What is the expected service life of these fuses?
A7: Under normal operating conditions within their rated parameters, HRC fuses have a long service life as they have no moving parts. The lifespan is primarily affected by the number and severity of overload events. They are considered maintenance-free protective devices.
Q8: Can you provide custom configurations or specific breaking capacities?
A8: Yes, we offer customization options. Parameters like rated current, precise time-current curves, and required breaking capacity can be tailored to meet your project's specific protection scheme. Please share your detailed requirements for a tailored solution.
