Multi-Effect Evaporation Crystallizer With Remote Monitoring and Free Installation Guide
Product Spotlights
High-efficiency multi-effect evaporation crystallizer featuring advanced remote monitoring for real-time control and diagnostics. Custom-built from corrosion-resistant materials for demanding applications in chemical, pharmaceutical, and wastewater treatment. Includes a comprehensive free installation guide for easier setup. Delivers significant energy savings, reduces operational labor, and enables resource recovery, supported by ISO-certified manufacturing and global export expertise.
US$ 4950 - 5871000
MOQ: 1 Case
Key Specifications
Get Latest Price
Material:
Other, Stainless Steel 316L/304 (Standard)
Application:
Other, Wastewater treatment
Certification:
Other, ISO9001
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
50 days
Related Products
-
Three-Stage Tri-Effect Falling Film Evaporator With Crystallizer for Viscous Liquid ConcentrationUS$ 2490 - 269800MOQ: 1 Combo -
Vacuum Heat Pump Evaporator for Low Temperature Distillation of Printing WastewaterUS$ 2490 - 269800MOQ: 1 Combo
-
Low Temperature Vacuum Heat Pump Evaporator for Chemical Wastewater Reduction and ReuseUS$ 2490 - 269800MOQ: 1 Combo
-
Multi-Effect Force Circulation MVR Evaporator for Beverage Concentration and Food ProcessingUS$ 2490 - 269800MOQ: 1 Combo
-
Compact Automatic Electric Heating Heat Pump Evaporator System for Multi-Wastewater TreatmentUS$ 2490 - 269800MOQ: 1 Combo
Material
Other, Stainless Steel 316L/304 (Standard)
Application
Other, Wastewater treatment
Certification
Other, ISO9001
Capacity
Customizable from 500 L/day to 50 tons/hr
Configuration
Multi-effect (2 to 5 effects), MVR optional
Monitoring
PLC-based system with remote monitoring capability
Installation
Comprehensive guide and technical support provided
Energy Source
Steam, thermal oil, or electric heating
As a leading manufacturer established in 2015 with a sprawling factory complex of 10,000-30,000 square meters, Qingdao Conqinphi Environmental Technology Group is dedicated to providing advanced industrial solutions. Our Multi-Effect Evaporation Crystallizer with Remote Monitoring represents our commitment to innovation and client support in the field of separation technology. This system is engineered to deliver exceptional efficiency in concentrating and crystallizing solutions, significantly reducing operational costs and environmental impact. We serve a global clientele across North America, Europe, Asia, and beyond, backed by an annual export value reflecting our international trust and capability.
This sophisticated crystallization unit is designed for industries requiring high-purity product recovery or zero-liquid discharge from complex waste streams. Its core value lies in maximizing energy utilization through multi-effect evaporation principles while offering unprecedented operational control via remote monitoring.
Key Features & Technical Advantages:
- Superior Energy Efficiency: Utilizes a cascading multi-effect design where vapor from one effect serves as the heat source for the next, dramatically lowering steam consumption compared to single-effect units.
- Advanced Remote Monitoring & Control: Integrated PLC and SCADA system allows for real-time monitoring of critical parameters (pressure, temperature, flow rates, concentration) from any location. Receive alerts, adjust settings, and generate performance reports remotely, enabling predictive maintenance and reducing on-site personnel needs.
- High-Quality Construction: Primary wetted parts are constructed from corrosion-resistant stainless steel (316L or 304 as standard), ensuring longevity when handling aggressive chemicals or food-grade materials.
- Optimized Crystallization: Features a forced-circulation or draft tube baffle (DTB) crystallizer design to promote uniform crystal growth, control crystal size distribution, and prevent scaling or fouling.
- Comprehensive Free Installation Guide: We provide detailed, step-by-step manuals, P&ID diagrams, and 3D layout drawings. This empowers your team and reduces installation time and costs. Our technical support is available throughout the process.
- Flexible & Scalable Design: Systems are custom-engineered to match your specific feed composition, capacity requirements (from pilot scale to large industrial plants), and desired final product form (slurry or dry crystals).
Technical Specifications Overview:
| Parameter | Specification / Option |
|---|---|
| Number of Effects | 2, 3, 4, or 5 (customizable) |
| Evaporator Type | Forced Circulation, Falling Film, or Combined |
| Heat Exchange Surface | Tubular or Plate Heat Exchangers |
| Control System | PLC with HMI, Ethernet/IP, Modbus TCP for integration |
| Monitoring Interface | Web-based dashboard or dedicated client software |
| Material of Construction | SS304, SS316L, Duplex, Hastelloy, Titanium (optional) |
| Vacuum System | Steam Ejector or Liquid Ring Vacuum Pump |
Tangible Benefits for Your Operation:
- Major Cost Reduction: Achieve steam savings of up to 70% versus single-effect evaporators, directly lowering your utility bills.
- Enhanced Process Reliability: Remote diagnostics and automated control loops minimize human error and ensure consistent product quality and output.
- Waste Minimization & Resource Recovery: Transform waste brines or process streams into valuable crystalline products and reusable water, supporting sustainability goals.
- Reduced Labor & Maintenance Costs: The remote capability and robust design decrease the need for constant manual checks and unscheduled downtime.
- Future-Proof Investment: The scalable and modular design allows for capacity expansion or process modification as your business grows.
Our commitment to quality is underpinned by a rigorous management system certified to ISO9001, ISO14001, and OHSAS18001 standards. With over 200 skilled employees and a proven track record of exporting to diverse markets from North America to Oceania, we have the expertise to deliver reliable, high-performance evaporation solutions. The inclusion of a comprehensive Free Installation Guide is a testament to our customer-centric approach, ensuring a smooth and successful project implementation. Choose our Multi-Effect Evaporation Crystallizer to gain a competitive edge through operational excellence, cost control, and advanced technological oversight. Contact us today to discuss how we can tailor a system to your specific application.
Frequently Asked Questions (FAQ)
-
What is the main advantage of a multi-effect design over a single-effect evaporator?
The primary advantage is vastly improved energy efficiency. In a multi-effect system, the vapor generated in one effect is used as the heating medium for the next effect, reusing latent heat. This can reduce steam consumption by approximately the number of effects (e.g., a triple-effect system may use about one-third the steam of a single-effect unit for the same water evaporation). -
How does the remote monitoring function work in practice?
The system is equipped with sensors and a Programmable Logic Controller (PLC) that collects operational data. This data is transmitted via a secure internet connection to a cloud server or your local network. Authorized personnel can then access a user-friendly dashboard through a web browser or mobile app to view real-time status, historical trends, receive alarm notifications, and sometimes make adjustments to setpoints. -
Is the Free Installation Guide sufficient for my team to install the system independently?
Our guide is comprehensive, including detailed mechanical drawings, electrical schematics, piping layouts, and step-by-step checklists. It is designed for professional installation teams familiar with industrial equipment. However, we strongly recommend and offer optional on-site supervision or startup assistance from our engineers to ensure optimal installation and commissioning, especially for complex systems. -
Can this crystallizer handle my specific feed solution, which contains [e.g., salts, organics, suspended solids]?
Absolutely. Our systems are custom-designed. We require a sample or complete analysis of your feed solution to determine the most suitable evaporator type (forced circulation for scaling-prone or viscous feeds, falling film for heat-sensitive products), material of construction to resist corrosion, and crystallizer design to achieve your desired crystal characteristics. -
What kind of after-sales support do you provide?
We provide comprehensive support including remote technical assistance, readily available spare parts for critical components, and optional maintenance contracts. Our team is accessible to help troubleshoot operational issues via the remote monitoring link or through direct communication. -
Are MVR (Mechanical Vapor Recompression) options available with this system?
Yes. While our standard multi-effect system is highly efficient, we can integrate an MVR unit for even greater energy savings, particularly where steam costs are high or electrical power is more economical. This is a customizable feature we can discuss during the project engineering phase. -
What is the typical lead time for a custom-designed system?
Lead time varies based on complexity, capacity, and material selection. Standard configurations typically range from 16 to 24 weeks from order confirmation to shipment ex-works. We provide a detailed project schedule upon receipt of your specific requirements. -
Do you offer pilot-scale units for testing?
Yes, we can supply smaller pilot or laboratory-scale evaporation-crystallization units. This allows you to conduct feasibility studies, optimize process parameters, and generate reliable scale-up data with your actual feedstock before committing to a full-scale industrial investment.
