As a leading manufacturer specializing in advanced wear-resistant materials, Wuxi Yansheng Technology Co., Ltd. is proud to introduce our premium Chromium Carbide Overlay (CCO) Carbon Steel Plate/Sheet. Engineered for the most demanding industrial environments, this product represents a significant advancement in combating severe abrasion, extending equipment lifespan, and reducing costly downtime. Since our establishment in 2017, we have leveraged our expertise and a 1,000-3,000 square meter production facility to deliver high-performance solutions trusted by clients across North America, Europe, Southeast Asia, and beyond. Our CCO plates are designed to provide unmatched protection in heavy-duty applications, offering superior value through enhanced durability and operational efficiency.
Our Chromium Carbide Overlay technology involves depositing a dense, ultra-hard layer of chromium carbides onto a tough carbon steel base plate. This composite structure combines the impact resistance of steel with the exceptional abrasion resistance of the carbide overlay. The result is a material that withstands the punishing effects of sliding, gouging, and high-stress abrasion far better than conventional hardened steels or ceramic tiles.
Core Product Advantages:
Exceptional Wear Life: The overlay hardness can reach HRC 65 and above, offering 5 to 10 times the service life of standard AR400 or AR500 steel plates in many abrasive applications.
Impact Resistance: The ductile carbon steel substrate absorbs impact energy, preventing catastrophic failure under heavy loads—a common weakness of brittle ceramic liners.
Customizable Design: We offer plates in a wide range of thicknesses (typically from 6mm to 80mm) and can tailor the overlay pattern (e.g., strip, full coverage), thickness, and plate dimensions to your specific equipment and wear patterns.
Ease of Fabrication: While the overlay itself is extremely hard, the carbon steel base can be easily cut, drilled, and welded using standard methods, simplifying installation and on-site modification.
Cost-Effective Solution: By dramatically reducing the frequency of component replacement and associated maintenance labor, our CCO plates deliver a lower total cost of ownership over the equipment's lifecycle.
Technical Specifications & Parameters:
The following table outlines typical specifications for our standard CCO plates. All parameters can be customized based on project requirements.
| Parameter | Specification / Value | Notes |
|---|---|---|
| Base Material | Carbon Steel (e.g., Q235, Q345, SS400) | Other grades like A36, A572 available. |
| Overlay Material | High-Chromium Carbide Alloy | Primary carbides: Cr7C3, Cr23C6. |
| Overlay Hardness | HRC 60 - 68 (Typical) | Measured on the overlay surface. |
| Overlay Thickness | 3mm - 12mm (Customizable) | Standard is 4-6mm for optimal wear/impact balance. |
| Total Plate Thickness | 10mm - 80mm+ | Depends on base plate and overlay thickness. |
| Plate Dimensions | Width up to 1500mm, Length up to 3000mm | Larger sizes available upon request. |
| Bond Strength | Metallurgical Bond | Ensures the overlay does not delaminate under stress. |
Key Applications: This material is ideally suited for lining and protecting critical components in industries where abrasion is the primary cause of failure. Common applications include:
Mining & Quarrying: Hopper liners, chute liners, truck bed liners, crusher components, screen decks.
Cement & Aggregates: Fan blades, cyclone separators, ductwork, clinker breaker plates, conveyor skirts.
Power Generation: Coal handling system components, ash conveyor systems, pulverizer wear parts.
Steel Mills: Sinter plant chutes, furnace feed systems, slag handling equipment.
Other Heavy Industry: Dredging equipment, pug mill blades, mixer paddles.
Backed by our robust quality management system and relevant industry certifications, Wuxi Yansheng Technology has built a reputation for reliability and performance. With an annual export value ranging between US$50 Million and US$100 Million, we serve a global clientele through major ports like Shanghai, Tianjin, and Qingdao. Our team of 101-200 dedicated professionals ensures every order meets stringent specifications. For your next project facing severe wear challenges, choose our Chromium Carbide Overlay Plates to achieve greater operational uptime, reduced maintenance costs, and a significant return on investment. Contact us today to discuss your specific requirements and receive a tailored quotation.
Frequently Asked Questions (FAQ)
Q1: How does Chromium Carbide Overlay compare to Hardox or other abrasion-resistant steels?
A: While both are wear-resistant, CCO offers a fundamentally different approach. Hardox is a through-hardened steel, offering uniform hardness. CCO plates feature an ultra-hard carbide layer on a tough steel base, providing significantly higher surface hardness (HRC 65+ vs. ~500HB/HRC 53) for extreme abrasion, while the steel base handles impact. CCO typically lasts much longer in pure sliding/wearing applications.
Q2: Can I weld directly onto the Chromium Carbide Overlay surface?
A: Direct welding onto the hard carbide overlay is not recommended as it can cause cracking. However, the carbon steel base material is readily weldable. Standard practice is to weld from the back (steel side) or through holes drilled in the plate. We provide detailed welding guidelines with our products.
Q3: What is the typical lead time for custom-sized plates?
A: Lead times vary based on order volume and customization complexity. For standard sizes and patterns, production typically takes 3-4 weeks. For fully custom projects involving specific overlay patterns or large quantities, lead times range from 5-8 weeks. We provide accurate timelines upon order confirmation.
Q4: How are these plates installed? Do they require special fastening?
A: Installation is straightforward. Plates are typically installed using mechanical fasteners like countersunk bolts through pre-drilled holes in the plate. Welding can be used on the steel base perimeter or with attachment lugs. We can supply plates with pre-drilled holes or machining as per your assembly drawings.
Q5: Is the overlay prone to spalling or cracking under impact?
A: The metallurgical bond between the overlay and base steel is very strong, designed to resist delamination. While the carbide layer itself is brittle, the ductile steel substrate absorbs impact energy, minimizing the risk of spalling. For extremely high-impact applications, we can adjust the overlay thickness and pattern for optimal performance.
Q6: Can you supply plates in curved or formed shapes?
A: Yes, we offer limited forming capabilities. The plates can be curved or formed to a certain radius *before* the hardfacing overlay is applied. It is crucial to discuss shape requirements during the design phase, as post-overlay forming is not possible due to the hardness of the surface layer.
Q7: What information do you need to provide a quotation?
A: To provide an accurate quote, we typically require: Application details, required plate dimensions (thickness, width, length), desired overlay thickness and coverage pattern (full or strip), base steel grade preference, quantity, and any special machining or drilling needs. Engineering drawings are highly beneficial.
Q8: Do you offer technical support for application design?
A: Absolutely. Our engineering team has extensive experience in wear solution design. We can review your application, analyze wear patterns, and recommend the optimal plate thickness, overlay specification, and layout to maximize service life and cost-effectiveness.
