Help CenterSingle-effect MVR Evaporator for Zero Liquid Discharge (ZLD) Systems
Product Spotlights
Related Products
-
304 Stainless Steel Single-effect MVR Evaporator With PLC ControlUS$ 460 - 148600MOQ: 1 Combo -
Single-effect MVR Evaporator With Mill Test Report for All MaterialsUS$ 460 - 148600MOQ: 1 Combo
-
Single-effect MVR Evaporator for Pharmaceutical Concentrate ProductionUS$ 460 - 148600MOQ: 1 Combo
-
Single-effect MVR Evaporator With 12-Month Performance WarrantyUS$ 460 - 148600MOQ: 1 Combo
-
Single-effect MVR Evaporator for Food Grade Juice ConcentrationUS$ 460 - 148600MOQ: 1 Combo
As a leading manufacturer with nearly a decade of experience in environmental technology, Qingdao Conqinphi Environmental Technology Group is proud to present our advanced Single-effect MVR Evaporator, engineered specifically for robust Zero Liquid Discharge (ZLD) systems. Operating from our expansive 10,000-30,000 square meter facility, we design and build evaporation solutions that tackle the most challenging industrial wastewater streams. Our evaporator is not just equipment; it's a commitment to helping industries achieve sustainable water management and regulatory compliance through superior thermal efficiency and reliable operation.
This Single-effect MVR Evaporator is the core component of an effective ZLD strategy. It utilizes Mechanical Vapor Recompression technology to dramatically reduce energy consumption compared to traditional multi-effect evaporators. By recompressing the vapor produced during evaporation and reusing it as the heating medium, the system creates a highly efficient closed-loop process. This design is particularly advantageous for concentrating brines, leachates, and other complex wastewater to a solid or near-solid state, ensuring zero liquid discharge from the facility.
Key Features & Technical Advantages:
- Superior Energy Efficiency: The single-effect MVR design reuses latent heat, typically consuming only 20-30 kWh per ton of water evaporated, which is a fraction of the energy required by conventional thermal evaporators.
- Compact & Modular Design: Our systems are engineered for a smaller footprint, making them ideal for plant retrofits or sites with limited space. The modular construction allows for easier transportation and installation.
- High Concentration Capability: Capable of handling high-TDS feeds and achieving final concentrate solids content often exceeding 60%, directly suitable for crystallization or drying stages in a full ZLD train.
- Corrosion-Resistant Construction: We select materials based on your specific feed chemistry. Options include 316L stainless steel for general applications, titanium for chloride-rich streams, or duplex steels for demanding environments, ensuring long service life.
- Fully Automated Operation: Equipped with a sophisticated PLC control system and user-friendly HMI, the evaporator operates with minimal manual intervention. The system automatically adjusts parameters like temperature, pressure, and feed flow for optimal performance.
- Low Maintenance Design: Key components like the vapor compressor are selected from reputable brands for reliability. The system layout prioritizes accessibility for routine inspection and maintenance.
Core Technical Specifications:
| Parameter | Typical Range / Description |
|---|---|
| Evaporation Capacity | 1 - 100 tons of water per hour (customizable) |
| Operating Temperature | 40°C - 100°C (adjustable based on feed properties) |
| Operating Pressure | Slight vacuum to low positive pressure |
| Specific Energy Consumption | Approx. ungefähr 20 - 35 kWh per ton of evaporated water |
| Vapor Compressor Drive | Electric motor (frequency inverter optional for control) |
| Condensate Quality | High-purity, often suitable for reuse within the plant |
Benefits for Your Operation:
- Significant Cost Savings: Drastically lowers operational expenses by reducing steam consumption and cooling water requirements.
- Regulatory Compliance: Enables industries to meet stringent environmental regulations regarding wastewater discharge and ZLD mandates.
- Resource Recovery: Produces a clean condensate stream for reuse and a concentrated brine/slurry for further processing or disposal, maximizing resource utilization.
- Process Reliability: Designed for continuous, stable operation with high automation, reducing operator dependency and potential for human error.
- Scalability: The single-effect design can be scaled or multiple units can be installed in parallel to meet growing capacity needs.
Backed by a workforce of 201-300 dedicated professionals and an annual export value reaching up to US$50 million, Qingdao Conqinphi has proven its capability to deliver reliable environmental solutions globally, with key markets across North America, Europe, Asia, and beyond. Our commitment to a structured quality management system is reflected in our certifications. This Single-effect MVR Evaporator embodies our expertise in creating efficient and durable equipment. By choosing our solution, you are partnering with an established manufacturer capable of supporting your project from design to commissioning, shipped efficiently from the Port of Qingdao. Contact us today to discuss how this evaporator can be customized to achieve your specific ZLD goals and transform your wastewater management costs.
Frequently Asked Questions (FAQ):
Q1: What is the main advantage of a single-effect MVR evaporator over a multi-effect (MED) system for ZLD?
A: While MED systems use multiple effects (stages) to improve efficiency, a single-effect MVR unit achieves high efficiency through vapor recompression in a single stage. This often results in a more compact footprint, simpler piping, and excellent part-load performance, making it highly suitable for the varying feed conditions often encountered in ZLD applications.
Q2: Can this evaporator handle wastewater with suspended solids or scaling potential?
A: Yes, but proper pre-treatment is crucial. The system design can incorporate features like forced circulation to handle higher solids content and anti-scaling protocols (e.g., controlled pH, antiscalant dosing). A detailed analysis of your feed water is recommended to determine the optimal pre-treatment and evaporator configuration.
Q3: What is the typical lifespan of the key component, the vapor compressor?
A> With proper maintenance and operation within design parameters, the mechanical vapor compressor can have a service life exceeding 15 years. We use reliable compressor brands and provide clear maintenance guidelines to ensure longevity.
Q4: How much operator attention does the system require?
A: The system is designed for largely unattended operation. The automated PLC control system manages daily start-up, shutdown, and continuous regulation. Operator tasks primarily involve routine monitoring via the HMI, basic data logging, and scheduled preventive maintenance.
Q5: Is the distilled water (condensate) produced pure enough to be reused?
A: In most cases, yes. The condensate from an MVR evaporator is typically very high quality, with low conductivity. It can often be reused as boiler feed water, cooling tower makeup, or for other process needs, providing significant water savings.
Q6: Can the system be customized for a specific feed concentration or final solid content?
A: Absolutely. As a manufacturer, we design each system based on client-provided feed analysis and desired output specifications. The heat transfer area, compressor sizing, and material selection are all tailored to achieve your target concentration factor and final solids content.
Q7: What are the electrical power requirements for this evaporator?
A: The main power consumer is the electric motor driving the vapor compressor. Total connected load depends on evaporation capacity, typically ranging from tens to hundreds of kilowatts. We provide detailed power requirement specifications during the design phase.
Q8: Do you provide installation supervision and commissioning services?
A: Yes, we offer comprehensive technical support packages. This can include detailed installation drawings, manuals, on-site supervision by our engineers, and commissioning services to ensure the system performs as designed. These services are available upon request.
