Home > Industrial Equipment & Components > Valve > Gate Valve > DIN 3352 Electric Gate Valve With 2-Year Warranty and Mill Test Report

DIN 3352 Electric Gate Valve With 2-Year Warranty and Mill Test Report

DIN 3352 Electric Gate Valve With 2-Year Warranty and Mill Test Report thumbnail-3

DIN 3352 Electric Gate Valve With 2-Year Warranty and Mill Test Report thumbnail-4

DIN 3352 Electric Gate Valve With 2-Year Warranty and Mill Test Report thumbnail-5

DIN 3352 Electric Gate Valve With 2-Year Warranty and Mill Test Report photo-1

DIN 3352 Electric Gate Valve With 2-Year Warranty and Mill Test Report photo-2

DIN 3352 Electric Gate Valve With 2-Year Warranty and Mill Test Report photo-3

DIN 3352 Electric Gate Valve With 2-Year Warranty and Mill Test Report photo-4

DIN 3352 Electric Gate Valve With 2-Year Warranty and Mill Test Report photo-5

Product Spotlights

DIN 3352 compliant electric gate valve for precise on/off flow control. Features robust construction, remote electric actuation for automation, and a full 2-year warranty. Includes a Mill Test Report for material traceability. Manufactured under ISO9001, ideal for global industrial applications in water, oil, gas, and steam systems.

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Standard:

Other, DIN 3352

Material:

Other, Carbon Steel (Body), Stainless Steel (Stem)

Actuation Type:

Electric Motorized

Contact Supplier Request Quote Chat Now

Shanghai Zhibang Valve Manufacture Co.,ltd

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard Other, DIN 3352

Material Other, Carbon Steel (Body), Stainless Steel (Stem)

Actuation Type Electric Motorized

Warranty 2-Year Limited Warranty

Certification ISO9001 Quality Management System

Port Size Available in Various Sizes

Connection Type Flanged End

Operation Mode On/Off Control

Pressure Rating PN16, PN25, PN40

Temperature Range -20°C to 200°C

As a professional manufacturer of industrial valves since 2016, Shanghai Zhibang Valve Manufacture Co., Ltd. proudly presents our premium DIN 3352 Electric Gate Valve. Engineered for demanding flow control applications, this valve combines robust construction with reliable electric actuation for superior performance in industrial piping systems. Backed by a comprehensive 2-year warranty and accompanied by a detailed Mill Test Report, this product represents our commitment to quality, traceability, and customer confidence. Our valves are trusted by partners across North America, Europe, Asia, and beyond, making them a smart choice for global procurement.

Core Product Features & Technical Advantages:

Robust DIN 3352 Design: Manufactured to the exacting DIN 3352 standard, ensuring dimensional interchangeability, reliable sealing performance, and compatibility with international pipeline specifications.
Reliable Electric Actuation: Integrated electric actuator provides precise on/off control, enabling remote operation, integration into automated systems, and reducing manual labor.
Superior Sealing & Durability: Features a precision-machined wedge gate and seat for bubble-tight shut-off, minimizing leakage and ensuring long service life even under high-pressure conditions.
Versatile Material Options: The valve body is typically constructed from durable carbon steel (WCB), with options for stainless steel (CF8/CF8M) or other alloys upon request to suit specific media (water, oil, gas, steam) and corrosive environments.
Easy Maintenance & Installation: Flanged ends per DIN standards facilitate straightforward installation and connection to existing pipelines. The design allows for potential maintenance without removing the valve body from the line.
Safety & Compliance: Manufactured under a certified ISO9001 Quality Management System, guaranteeing consistent production quality and process control.

Key Technical Specifications:

Parameter	Specification
Design Standard	DIN 3352
Pressure Rating	PN16, PN25, PN40 (Customizable)
Temperature Range	-20°C to 200°C (Depends on seat material)
End Connection	Flanged (RF/FF), as per DIN 2501
Actuator Power Supply	Commonly 24V DC, 110V AC, 220V AC, 380V AC
Valve Operation	Electric Motor Driven, On/Off (Modulating control optional)
Flow Characteristic	Full Port, Minimal Pressure Drop

Benefits for Your Operations:

Enhanced Process Automation: Enables remote valve operation, perfect for unmanned stations or integration with SCADA and PLC systems.
Reduced Operational Costs: Minimizes manual intervention, lowers labor costs, and improves overall system efficiency.
Improved Safety: Allows operators to control valves from a safe distance, especially beneficial in hazardous or hard-to-reach locations.
Guaranteed Quality & Traceability: Each valve is supplied with a Mill Test Report, providing full material traceability and proof of compliance with specified mechanical and chemical properties.
Global Compatibility: The DIN standard design ensures easy replacement and compatibility with systems worldwide, particularly in European and Asian markets.

With an annual export value ranging between US$1 Million and US$1.5 Million, Shanghai Zhibang has established itself as a reliable partner for industrial valve supply across continents. Our products ship from major ports like Shanghai, Guangzhou, Hong Kong, and Beijing, ensuring efficient logistics to your destination. The 2-year warranty on this Electric Gate Valve is a testament to our confidence in its durability and performance. Choose a valve backed by manufacturing expertise, certified quality processes, and a commitment to customer satisfaction. Contact us today to discuss your specific requirements and receive a detailed quotation.

Frequently Asked Questions (FAQ):

Q: What is the main advantage of an electric gate valve over a manual one?
A: The primary advantage is the ability for remote and automated operation. This enhances safety, allows integration into control systems, reduces manual labor, and is ideal for valves installed in inaccessible or hazardous areas.
Q: Can this valve be used for throttling or flow control?
A: Standard electric gate valves are designed for reliable on/off (fully open or fully closed) service. Using them for partial flow (throttling) can cause vibration, seat erosion, and damage. For flow control, a different valve type like an electric control valve would be recommended.
Q: What does the Mill Test Report (MTR) include, and why is it important?
A: The MTR is a certificate from the material mill that details the chemical composition and mechanical properties (like tensile strength, yield strength) of the raw materials used (e.g., casting) for the valve body. It is crucial for quality assurance, traceability, and compliance with project specifications, especially in oil & gas, power, and chemical industries.
Q: Are different voltage options available for the electric actuator?
A: Yes. Actuators can typically be supplied with various standard power supply voltages such as 24V DC, 110V AC, 220V AC, or 380V AC. The required voltage should be specified at the time of ordering to ensure compatibility with your local power system.
Q: What is the typical lead time for this product?
A: Lead time depends on the specific size, material, and actuator configuration. Standard models may have shorter lead times, while customized orders require more production planning. Please inquire with your detailed requirements for an accurate delivery schedule.
Q: Is the 2-year warranty global?
A: Yes, the limited warranty covers manufacturing defects in materials and workmanship under normal use for a period of two years from the date of shipment. Warranty terms and conditions are provided with the product documentation.
Q: Can you provide valves with different flange standards, like ANSI?
A: While this product is designed per DIN 3352, our manufacturing capabilities allow us to produce gate valves to various standards including ANSI, JIS, and BS. Please specify your required standard and pressure class when requesting a quote.
Q: What maintenance does the electric actuator require?
A: The actuator is generally designed for minimal maintenance. Periodic checks for proper electrical connections, lubrication of mechanical parts (if specified), and verification of operation are recommended. The specific maintenance schedule should be followed as per the actuator manufacturer's manual supplied with the valve.
