Help CenterFlanged DIN 3352 Gate Valve in 316 Stainless Steel, Full Port, PN25 Rated
Product Spotlights
Related Products
-
DIN 3352 Pneumatic Actuated Gate Valve With Explosion Proof OptionNegotiableMOQ: 1 Unit -
DIN 3352 Pneumatic Gate Valve for Water Treatment and Chemical ProcessingNegotiableMOQ: 1 Unit
-
DIN 3352 Gate Valve With Blow-out Proof Stem, Stainless Steel Construction, API Standard DesignNegotiableMOQ: 1 Unit
-
DIN 3352 Pneumatic Gate Valve With Double Acting Actuator, DN50-DN200 Size RangeNegotiableMOQ: 1 Unit
-
Gate Valve per DIN 3352 for Food and Beverage Pipeline InstallationNegotiableMOQ: 1 Unit
As a professional manufacturer with a strong commitment to quality and reliability, Shanghai Zhibang Valve Manufacture Co., Ltd. proudly presents our Flanged DIN 3352 Gate Valve in 316 Stainless Steel. Engineered for demanding industrial applications, this full-port, PN25-rated valve combines robust construction with precise performance. Since our establishment in 2016, we have focused on delivering superior fluid control solutions, and this valve exemplifies our dedication to meeting the stringent requirements of global markets. It is designed to provide exceptional shut-off capability, durability, and ease of operation, making it a dependable choice for your critical piping systems.
This valve is built to deliver long-lasting performance and safety in a wide range of industrial environments. Its key features and benefits are detailed below.
Core Features & Technical Advantages:
- Superior Material Construction: Manufactured from high-grade 316 stainless steel, the valve offers excellent resistance to corrosion, pitting, and crevice corrosion, especially in environments containing chlorides. This makes it suitable for chemical processing, marine applications, and food & beverage industries.
- Full Port Design: The full-bore configuration ensures minimal pressure drop across the valve when fully open, allowing for maximum flow capacity and reduced energy consumption in pumping systems. It also facilitates easy cleaning and pigging in pipeline applications.
- Robust Flanged Connection: The flanged ends are precision-machined according to standard dimensions, ensuring a leak-proof and secure connection to the pipeline. This design simplifies installation and maintenance.
- DIN 3352 Compliance: Adherence to the DIN 3352 standard guarantees consistent dimensions, pressure ratings, and material specifications, ensuring interchangeability and reliability within European and international piping systems.
- PN25 Pressure Rating: With a nominal pressure rating of PN25 (approximately 25 bar), this valve is capable of handling high-pressure applications commonly found in water supply, oil & gas, and industrial plant systems.
- Rising Stem Design: The outside screw and yoke (OS&Y) or non-rising stem options provide a visual indication of the valve position (open/closed), enhancing operational safety and control.
- Bidirectional Sealing: The gate valve provides tight sealing in both flow directions, ensuring reliable isolation of the pipeline section.
Technical Specifications:
The following table summarizes the primary specifications of our Flanged DIN 3352 Gate Valve. Specific dimensions and weights are available upon request.
| Parameter | Specification |
|---|---|
| Body & Trim Material | AISI 316 Stainless Steel |
| Design Standard | DIN 3352 F4 / DIN 3202 F1 |
| Connection | Flanged, PN16/PN25/ANSI 150/300 (customizable) |
| Port Type | Full Port (Full Bore) |
| Pressure Rating | PN25 (25 bar at 20°C) |
| Temperature Range | -20°C to +200°C (standard) |
| Seat & Seal | Metal-to-metal (SS/SS) or soft seated (optional) |
| Operation | Handwheel (Standard), Gear Operator (Optional) |
| Face-to-Face | As per DIN 3352 Series |
| Applicable Media | Water, Oil, Gas, Steam, Chemicals, etc. |
Benefits for Your Operations:
- Enhanced System Reliability: The robust 316 SS construction and precision machining minimize the risk of failure, reducing downtime and maintenance costs.
- Improved Flow Efficiency: The full port design optimizes flow, which can lead to energy savings in systems with high flow rates.
- Global Compliance: Built to DIN standards, the valve integrates seamlessly into projects requiring European specifications, facilitating procurement for international engineering firms.
- Versatile Application: Suitable for a broad spectrum of industries including petrochemical, power generation, water treatment, shipbuilding, and pharmaceuticals.
- Long Service Life: The corrosion-resistant properties of 316 stainless steel ensure a prolonged operational lifespan even in harsh conditions.
Shanghai Zhibang Valve Manufacture operates under an ISO9001 certified quality management system, ensuring every valve, including this DIN 3352 Gate Valve, is produced with consistent quality and traceability. Our annual export value of US$1 Million - US$1.5 Million and our presence in major global markets—from North America and Western Europe to Southeast Asia and Africa—demonstrate our capability and reliability as an international supplier. We ship efficiently from key ports like Shanghai, Guangzhou, Hong Kong, and Beijing, ensuring timely delivery. Choosing our valve means partnering with a manufacturer dedicated to precision engineering and customer satisfaction. Contact us today to discuss your specific requirements, request a detailed quotation, or learn more about our comprehensive valve portfolio.
Frequently Asked Questions (FAQ):
Q1: What is the main advantage of using 316 stainless steel over 304 for this gate valve?
A1: 316 stainless steel contains molybdenum, which significantly enhances its resistance to corrosion from chlorides and other aggressive chemicals. This makes it a more suitable choice for marine environments, chemical processing, and applications where media may cause pitting or crevice corrosion.
Q2: Can this valve be used for throttling or flow control?
A2: Gate valves are primarily designed for isolation (fully open or fully closed), not for precise flow regulation or throttling. Using them for throttling can cause seat and disc erosion, leading to leakage. For flow control applications, consider our globe or control valves.
Q3: Are the flanges drilled according to specific standards like DIN or ANSI?
A3: Yes. Our standard offering includes flanges drilled to DIN PN16/PN25 standards. However, we can customize the flange drilling pattern (e.g., ANSI 150/300) and facing (RF, FF) upon request to match your existing pipeline specifications.
Q4: What is the delivery time for a standard order of these valves?
A4: For standard sizes and configurations, our typical lead time is 4-6 weeks. Expedited production may be available for urgent requirements. We recommend contacting our sales team with your specific quantity and size details for an accurate delivery schedule.
Q5: Do you offer any other end connections besides flanged?
A5: While the featured product is a flanged valve, we manufacture gate valves with various end connections, including butt-weld (BW), socket-weld (SW), and threaded (NPT, BSP). Please inquire for these alternative configurations.
Q6: Is the valve suitable for steam service?
A6: Yes, within its specified temperature range of up to 200°C, this valve can handle saturated steam applications. For higher temperature steam services, please consult with our engineering team to ensure material suitability and potential design modifications.
Q7: What type of packing is used in the stem sealing area?
A7: The valve is typically equipped with graphite or PTFE-based stem packing suitable for the stated temperature and media range. The exact packing material can be selected based on your specific service conditions to ensure optimal sealing performance and longevity.
Q8: Do you provide testing and inspection certificates with the valves?
A8: Yes. Standard delivery includes a manufacturer's test certificate. Additional inspections and certifications, such as Third-Party Inspection (TPI) or specific material test reports (MTR), can be arranged upon request and may incur additional charges.
