As a professional manufacturer specializing in power transmission solutions, Jiangsu Manqi Machinery Co., Ltd. proudly presents the NGW101 Planetary Gear Reducer. Established in 2017 and operating from our modern facility in Suzhou, we combine precision engineering with reliable manufacturing to deliver components that enhance machine performance. The NGW101, featuring an integral flange mount and a robust 40Nm torque capacity, is engineered for seamless integration and durability in demanding industrial environments. This reducer is designed to provide compact, high-efficiency power transmission, making it an ideal choice for automation systems and precision machinery where space and reliability are critical.
The NGW101 Planetary Gear Reducer is built with a focus on performance and longevity. Its core advantages stem from a thoughtful design and quality construction.
- Compact & Space-Saving Design: The planetary gear system offers a high torque density within a minimal footprint. The integral flange mount eliminates the need for additional adapters, simplifying installation and saving valuable space in your machinery layout.
- High Torque Capacity & Efficiency: Rated for 40Nm of output torque, this reducer handles significant loads with ease. The precision-machined planetary stages ensure high transmission efficiency, minimizing energy loss and heat generation during operation.
- Robust Construction & Durability: Key components like gears are manufactured from high-strength alloy steel, hardened and ground for wear resistance. The housing, available in aluminum alloy for lightweight applications or cast iron for maximum rigidity, protects the internal mechanism from contaminants and impacts.
- Smooth & Precise Operation: The planetary design inherently provides low backlash and high torsional stiffness, resulting in smooth, accurate motion transfer. This is crucial for applications requiring precise positioning, such as in robotics or CNC equipment.
- Versatile Application Readiness: Designed for easy coupling with various input sources, including standard IEC motors and servo motors. Its configuration supports a wide range of reduction ratios, which can be customized to meet specific speed and torque requirements of your application.
- Low Maintenance: Sealed for life with high-quality grease lubrication, the NGW101 requires minimal maintenance, reducing downtime and total cost of ownership.
Below is a summary of key technical specifications for the NGW101 Planetary Gear Reducer:
| Parameter | Specification |
|---|---|
| Model | NGW101 |
| Gear Type | Planetary (Epicyclic) |
| Rated Output Torque | 40 Nm |
| Mounting Style | Integral Flange Mount (Output Shaft) |
| Maximum Input Speed | Available upon request |
| Reduction Ratio Range | Customizable (e.g., 3:1 to 100:1) |
| Gear Material | High-Strength Alloy Steel |
| Housing Material Options | Aluminum Alloy / Cast Iron |
| Backlash | Low (Specific grade available upon request) |
| Lubrication | Grease (Sealed for Life) |
| Protection Class | IP65 (Typical, customizable) |
Integrating the NGW101 into your equipment brings tangible benefits:
- Enhanced Machine Performance: Delivers reliable, high-torque power transmission, improving the overall output and consistency of your automated systems.
- Design Flexibility: The compact form factor and integral mount give machine designers more freedom, allowing for more streamlined and efficient equipment layouts.
- Increased Operational Lifespan: The durable construction and reliable sealing extend service intervals, contributing to lower lifecycle costs and higher machine uptime.
- Improved Energy Efficiency: High gearing efficiency translates to less wasted energy, which can lead to cost savings, especially in continuously running applications.
Backed by the manufacturing expertise of Jiangsu Manqi Machinery, a company with a dedicated 10,000-30,000 square meter production facility and a focused team, the NGW101 represents a commitment to quality and value. We serve a diverse clientele across Eastern Europe, Southeast Asia, Africa, and South Asia, ensuring our products meet varied international application standards. Our annual export volume reflects our growing reputation as a reliable supplier of mechanical components. The NGW101 Planetary Gear Reducer is more than just a part; it's a performance-enhancing solution built for reliability. For OEMs and system integrators seeking a compact, powerful, and durable reducer, this model offers a compelling combination of features. Contact us today to discuss your specific ratio requirements and how the NGW101 can be integrated into your next project, shipped efficiently from the Port of Shanghai.
Frequently Asked Questions (FAQ)
Q1: What is the main advantage of the integral flange mount on the NGW101?
A: The integral flange mount provides a direct, rigid connection to the driven machine, enhancing alignment accuracy and structural integrity. It simplifies assembly by removing the need for separate mounting brackets, saving both space and installation time.
Q2: Can the NGW101 be directly connected to my servo motor?
A: Yes, it is designed for compatibility. The input interface can be customized with a suitable coupling or adapter to match the shaft and flange of most common servo motors. Please provide your motor model for precise matching.
Q3: Is the 40Nm torque rating a maximum or continuous duty rating?
A: The 40Nm specification refers to the rated output torque for continuous, reliable operation under normal conditions. It includes a safety factor. For peak or intermittent torque requirements, please consult our technical team.
Q4: What reduction ratios are available for this model?
A: The NGW101 platform supports a wide range of planetary reduction ratios. Standard ratios are available, and we can also produce custom ratios to meet your specific speed and torque needs. Please inquire with your requirements.
Q5: What is the typical delivery lead time for a custom ratio order?
A: Lead times vary based on the customization level and order quantity. For standard configurations, stock may be available. For custom ratios, typical production lead time ranges from 4 to 8 weeks. We provide accurate timelines upon order confirmation.
Q6: How do I determine if the aluminum or cast iron housing is better for my application?
A: Aluminum alloy housings are lighter and offer good corrosion resistance, ideal for applications where weight is a concern. Cast iron housings provide superior vibration damping and higher rigidity for the most demanding, high-load applications. Our engineers can help you select the optimal option.
Q7: What maintenance does this gear reducer require?
A: The NGW101 is typically lubricated for life with high-performance grease and features sealed bearings. Under normal operating conditions, no routine lubrication is required. Periodic inspection for seal integrity and unusual noise is recommended.
Q8: Can you provide technical drawings and 3D models for integration into our design?
A: Absolutely. We provide detailed 2D drawings (PDF, DXF) and 3D models (STEP, IGES) for all our products to facilitate easy integration into your CAD environment and ensure proper fit during the design phase.
