As a leading manufacturer in the electrical insulation industry, Jinhua Dika Electrical Equipment Co., Ltd. is proud to present our premium 2:1 Heat Shrinkable Tube. With over a decade of experience and an annual export value reaching up to US$1.5 million to markets worldwide, we have honed our production to deliver a product that combines reliability, durability, and ease of use. Our heat shrink tubing is engineered to provide a secure, protective seal for wires, cables, and components, significantly enhancing product longevity and safety in various applications. We back our quality with comprehensive technical support and a solid warranty, ensuring our clients receive not just a product, but a complete solution.
This 2:1 heat shrink tube is designed to meet the rigorous demands of industrial, commercial, and electronic applications. It offers a balanced shrink ratio that provides a tight, conformal fit without excessive material strain. Our commitment to quality is reflected in our adherence to multiple management system standards, including ISO 9001 and ISO 14000, ensuring consistent production excellence.
Core Features & Technical Advantages:
- Superior Shrink Performance: The precise 2:1 ratio ensures the tube shrinks to half its supplied diameter when heated, creating a uniform, tight seal around irregular shapes and bundles.
- Excellent Environmental Protection: Provides robust resistance against moisture, dust, chemicals, and abrasion, safeguarding electrical connections from corrosive elements.
- Wide Temperature Tolerance: Performs reliably in a broad operating range from -55°C to 135°C, maintaining flexibility at low temperatures and integrity at high temperatures.
- Flame-Retardant Formulation: Manufactured with materials that meet UL 224 VW-1 standards for flame retardancy, enhancing safety in electrical applications.
- Durable and Flexible: The cross-linked polyolefin material offers long-term UV stability, excellent electrical insulation properties, and remains flexible after shrinking to withstand vibration and movement.
- Easy Application: Can be easily applied using a standard heat gun, offering a fast and clean alternative to tape or liquid sealants.
The following table outlines key specifications for our standard 2:1 Heat Shrinkable Tube range:
| Property | Typical Value / Description |
|---|---|
| Material | Irradiated Cross-Linked Polyolefin |
| Shrink Ratio | 2:1 |
| Operating Temperature | -55°C to +135°C |
| Tensile Strength | > 10.4 MPa |
| Elongation at Break | > 200% |
| Dielectric Strength | > 15 kV/mm |
| Volume Resistivity | > 10^14 ohm-cm |
| Standard Colors | Black, Red, Blue, Yellow, Green, White |
| Flammability | UL 224 VW-1 Compliant |
| RoHS Compliance | Yes |
Benefits for Your Business:
- Enhanced Product Reliability: Protects connections from environmental stress, reducing field failures and warranty claims.
- Streamlined Assembly: Faster and cleaner than traditional methods like taping or potting, improving production line efficiency.
- Professional Aesthetics: Provides a neat, finished appearance to wire harnesses and assemblies, improving product presentation.
- Versatile Application: Suitable for a vast range of uses from automotive wiring and appliance leads to telecommunications and marine electronics.
- Cost-Effective Solution: Durable protection extends the service life of components, offering a strong return on investment through reduced maintenance.
Frequently Asked Questions (FAQ)
-
What does a 2:1 shrink ratio mean?
A 2:1 ratio means the tube's recovered (shrunk) inner diameter is approximately half of its original expanded inner diameter. For example, a 20mm tube will shrink down to about 10mm. -
What is the best way to apply this heat shrink tube?
Use a standard electric heat gun. Move the heat source evenly along the length of the tube, avoiding concentrating heat in one spot. The tube will shrink smoothly and conform to the shape beneath it. -
Can this tubing be used outdoors?
Yes, the material formulation offers good UV resistance and environmental protection, making it suitable for many outdoor applications. For extreme UV exposure, specific UV-stable grades may be recommended. -
Is it resistant to oils and chemicals?
Our standard polyolefin tube offers good resistance to many common chemicals, oils, and solvents. For specific aggressive chemicals, please consult our technical support for material suitability. -
What is included in the warranty and technical support?
The warranty covers material and workmanship defects. Our technical support team, based on our manufacturing expertise, can assist with application questions, material selection, and problem-solving for your specific projects. -
Can I get custom colors or sizes?
Yes, custom colors, sizes, and printing (like wire markers) are often available. Please contact us with your specific requirements for a quotation. -
What is the shelf life of the product?
When stored in its original packaging in a cool, dry place away from direct sunlight, the heat shrink tube has a shelf life of several years without significant degradation of performance. - Is the tube adhesive-lined? Our standard product is a single-wall, non-adhesive tube. Adhesive-lined (dual-wall) versions that provide a waterproof seal are available as a separate product line upon request.
Trust in a manufacturer with a proven global footprint. Jinhua Dika Electrical Equipment Co., Ltd. serves diverse markets from North America and Europe to Southeast Asia and Africa, supported by efficient logistics from major ports like Shanghai and Ningbo. Our investment in certifications such as ISO 9001 for quality management and ISO 14000 for environmental management underscores our commitment to consistent, responsible manufacturing. When you choose our 2:1 Heat Shrinkable Tube, you are selecting a product backed by technical expertise, a reliable warranty, and the assurance of dealing directly with the source. Contact us today to discuss how our tubing can enhance your products' reliability and performance.
