Help CenterWhite Nylon Cable Gland With Metric Thread (M8, M10, M12, M16, M50)
Product Spotlights
Related Products
-
White Nylon Cable Glands for Outdoor Equipment IP68 ProtectionUS$ 1 - 2MOQ: 10000 Units -
Electrical Panel Cable Entry With M8 M10 M12 M16 M50 White Nylon GlandsUS$ 1 - 2MOQ: 10000 Units
-
YDSL Nylon Cable Glands With Mill Test Report for Material ComplianceUS$ 1 - 2MOQ: 10000 Units
-
Standard Compliant White Nylon Cable Glands Warranty IncludedUS$ 1 - 2MOQ: 10000 Units
-
Nylon Cable Glands for M8 M10 M12 M16 M50 Threads in Control CabinetUS$ 1 - 2MOQ: 10000 Units
As a professional manufacturer, Jinhua Dika Electrical Equipment Co., Ltd. specializes in producing high-quality cable glands designed for secure and reliable cable management. Our white nylon cable glands with metric threads (M8, M10, M12, M16, M50) are engineered to provide exceptional sealing, strain relief, and environmental protection for electrical connections in a wide range of industrial applications. With over a decade of experience and a commitment to stringent quality management systems, we deliver products that meet the demanding needs of global markets, ensuring your projects are equipped with durable and dependable components.
Product Overview & Core Advantages:
This series of cable glands is crafted from premium nylon PA6 material, offering excellent mechanical strength, corrosion resistance, and insulation properties. The white color provides a clean, professional appearance and aids in identification. The metric thread design ensures compatibility with standard equipment and enclosures worldwide.
- Robust Sealing Performance: Each gland incorporates an internal rubber seal ring that compresses around the cable, creating a tight seal against dust, moisture, and liquids. This design is crucial for maintaining the integrity of electrical systems in harsh environments.
- Effective Strain Relief: The gland body and locking nut work together to clamp the cable securely, preventing pull-out forces from damaging the internal connections and reducing stress on the cable entry point.
- Broad Application Scope: Suitable for use in control panels, machinery, outdoor installations, marine equipment, and any scenario where cables need protection at their entry/exit points from enclosures.
- Easy Installation & Maintenance: Designed with a standard hex lock nut for tool-assisted tightening, ensuring a secure fit without over-torquing. The simple design allows for quick installation and future maintenance or cable replacement.
Technical Specifications & Detailed Parameters:
| Thread Size (Metric) | Recommended Cable Diameter Range (mm) | Body Length (Approx. mm) | Lock Nut Type |
| M8 | 3 - 6 | 25 | Hexagonal |
| M10 | 4 - 8 | 30 | Hexagonal |
| M12 | 5 - 10 | 35 | Hexagonal |
| M16 | 8 - 14 | 40 | Hexagonal |
| M50 | 20 - 30 | 60 | Hexagonal |
Additional Features & Benefits:
- Material Properties: Nylon PA6 offers high impact resistance, good electrical insulation, and stability across a wide temperature range (-40°C to +100°C), making it suitable for diverse climatic conditions.
- Color Consistency: The white color is uniform and resistant to fading under UV exposure, maintaining aesthetic appeal over time.
- Thread Precision: Metric threads are machined to accurate tolerances, ensuring smooth engagement with threaded holes and preventing cross-threading or sealing issues.
- Customization Options: While we offer standard white nylon glands, other colors, materials (like metal), or specific IP ratings (e.g., IP68) can be discussed for custom orders.
- Packaging Flexibility: Products can be supplied in individual packs, bulk boxes, or according to specific customer requirements for logistics efficiency.
Why Choose Our Cable Glands?
For B2B buyers, the reliability of components is paramount. Our glands provide a cost-effective solution without compromising on performance. They help extend the lifespan of your cable systems by protecting against environmental stressors, reduce maintenance downtime, and ensure compliance with safety standards for electrical installations. By sourcing from a dedicated manufacturer with integrated quality control, you gain assurance in product consistency and supply chain stability.
Trust & Commitment:
Jinhua Dika Electrical Equipment Co., Ltd. operates with a robust foundation of quality certifications, including ISO9001 and ISO14000, reflecting our systematic approach to manufacturing and environmental management. With an annual export value ranging between US$1 Million and US$1.5 Million, we have established trust across major markets including North America, Europe, Asia, and Africa. Our team of 11-50 skilled employees ensures every product meets precise specifications. We support flexible shipment from ports like Shanghai, Tianjin, Guangzhou, and Ningbo, facilitating smooth international trade. When you choose our white nylon metric cable glands, you are selecting a product backed by professional expertise, reliable production capacity, and a commitment to supporting your electrical projects globally.
Frequently Asked Questions (FAQ):
-
What is the primary material of these cable glands, and why is it chosen?
The glands are made from nylon PA6. This material is selected for its excellent balance of mechanical strength, corrosion resistance, good electrical insulation properties, and cost-effectiveness compared to metals or other plastics. -
Are these glands suitable for outdoor or wet environments?
Yes. The design, with its internal rubber seal, provides effective sealing. While the standard gland offers good protection, specific higher IP ratings (like IP68 for submersion) can be available upon request for extreme conditions. -
How do I select the correct thread size (M8, M10, etc.) for my application?
The thread size should match the threaded hole size on your equipment enclosure or panel. You also need to consider the outer diameter of your cable to ensure it falls within the gland's recommended cable diameter range for proper sealing. -
Can these glands be used with shielded or armored cables?
They are primarily designed for standard non-armored cables. For armored cables, a different gland design with a clamping mechanism for the armor is typically required. Please inquire for specialized solutions. -
What tools are needed for installation?
A standard hex wrench or socket is typically used to tighten the lock nut. No special tools are required, making installation straightforward for technicians. -
Is the white color prone to discoloration over time?
The nylon material used is resistant to UV and environmental factors, so the white color maintains its appearance well under normal industrial conditions. It is not prone to significant discoloration. -
Do you offer glands with different thread standards (e.g., PG thread or NPT thread)?
Our current focus is on metric threads, which are widely used internationally. Other thread standards may be customizable based on order volume and specific requirements. -
What is the packaging and minimum order quantity (MOQ)?
Standard packaging is in individual bags or bulk boxes. The MOQ is flexible and can be discussed based on your needs, especially for mixed sizes or custom requirements.
