Core Advantages
HT300 High-Strength Cast Iron
The TS400 is constructed from high-strength HT300 cast iron, processed with double tempering + artificial aging, achieving over 90% internal stress relief. This is a premium process typically used only a few high-end imported machines, costing over 30% more than standard methods. Although it significantly increases manufacturing costs, it eliminates internal stress, ensuring the machine does not deform or lose accuracy over long-term use, providing the core foundation for stable ±0.025mm S-part accuracy.
Integrated AC Axis
The AC axis of the TS400 is directly embedded into the machine column as an integrated structure, unlike the common bolt-on split-type design found in most market models. This requires precision mounting points to be cast into the bed, making machining and commissioning over twice as difficult and increasing costs by 40%. However, it eliminates connection gaps and rigidity weaknesses, ensuring no vibration or deformation during heavy cutting and providing long-term AC axis stability.
Dual-Drive Y-Axis
The TS400 adopts a dual-motor + dual-ball screw drive system for the Y-axis, with driving force applied directly to the column. This dual-drive system requires two independent drive sets, increasing manufacturing costs by 50% compared to single-drive designs. However, the force is applied symmetrically to the column, eliminating offset load and crawling, ensuring higher positioning accuracy at high speeds, smoother cutting, and greatly reduced wear on the guides and ball screws, extending the machine's service life.
DD Direct Drive + Grating
The AC axis of the TS400 uses direct-drive torque motor technology, eliminating intermediate transmission gears for zero backlash and zero wear, with a response speed over three times faster than geared systems. It is paired with a HEIDENHAIN circular grating encoder for high-precision angular feedback, enabling real-time error correction. This achieves a positioning accuracy of 7 arcseconds and repeatability of 4 arcseconds, far exceeding standard industry performance.
German HEMA Pneumatic Brake
The TS400 comes standard with a German HEMA pneumatic brake, featuring extremely high clamping force and thermal stability. HEMA is the global benchmark brand for high-end machine tool brake systems, with manufacturing costs over 3 times higher than standard domestic brakes, and clamping force over 2 times higher. It maintains exceptional stability during long continuous machining cycles, with no slipping or clamping force decay, ensuring absolutely reliable AC axis positioning and no displacement during heavy cutting.
Super High Torque AC Axis
The TS400 features a maximum A-axis torque of 1900 N·m and C-axis torque of 670 N·m, over 1.5 times higher than standard 5-axis machines of the same class. This enables larger cutting depths and feed rates, boosting machining efficiency by over 30%. It eliminates tool vibration and breakage during heavy cutting, making it ideal for complex surface and large-allowance parts, significantly shortening production cycles.
Control & Accuracy
The TS400 is equipped with the Syntec 220MA-5 high-end 5-axis control system, paired with full closed-loop control for the AC axis, enabling high-precision dynamic compensation for 5-axis simultaneous machining. It delivers an S-part accuracy standard of ±0.025mm, fully matching the performance of imported systems such as Siemens and HEIDENHAIN, but at only 1/3 of the purchase cost of imported machines. It also offers lower later maintenance costs and faster spare parts supply, making it the most cost-effective high-end 5-axis solution in the domestic market.
