As a dedicated manufacturer of high-quality electrical equipment, Jinhua Dika Electrical Equipment Co., Ltd. is proud to introduce our premium Dry-Type Isolation Transformer. Designed for reliability and safety in demanding applications, this transformer provides complete electrical isolation between primary and secondary circuits, effectively eliminating noise, preventing ground loops, and protecting sensitive equipment from power surges and disturbances. Every unit we supply comes with comprehensive documentation, including a detailed Mill Test Report (MTR) for material traceability and a clear Wiring Diagram for straightforward installation, reflecting our commitment to quality and customer support.
Our Dry-Type Isolation Transformer is engineered for superior performance and durability. Unlike liquid-filled transformers, it uses only air as the cooling and insulating medium, making it environmentally friendly, maintenance-free, and suitable for installation in indoor environments where fire safety is a priority. The robust construction ensures stable operation across a wide range of industrial and commercial settings.
- Enhanced Electrical Safety: Provides galvanic isolation, creating a physical barrier between input and output. This protects both personnel and downstream equipment from electrical shocks, voltage spikes, and common-mode noise.
- Noise and Surge Suppression: Effectively filters out harmonics, transients, and electrical noise from the power line, ensuring a clean and stable power supply for precision instruments, medical devices, and communication systems.
- High-Efficiency Design: Constructed with high-grade, low-loss silicon steel cores and high-temperature resistant copper or aluminum windings to minimize energy loss and operational costs.
- Customizable Configurations: Available in a wide range of standard and custom voltages, power ratings (kVA), and mounting options (wall or floor) to meet specific project requirements.
- Rugged and Reliable: The dry-type design eliminates risks associated with coolant leaks. The insulation system is vacuum-pressure impregnated (VPI) with high-temperature varnish, offering excellent moisture and contaminant resistance for long service life.
- Comprehensive Documentation: Each transformer is shipped with a Mill Test Report verifying the quality of raw materials (copper, steel) and a detailed Wiring Diagram to facilitate correct and safe installation.
Below is a table outlining some common technical specifications. Please note that parameters can be customized based on your needs.
| Parameter | Typical Specification / Option |
|---|---|
| Power Rating Range | 0.5 kVA to 500 kVA (standard) |
| Primary Voltage | Up to 600V AC (customizable) |
| Secondary Voltage | Up to 600V AC (customizable) |
| Frequency | 50 Hz, 60 Hz, or 50/60 Hz |
| Insulation Class | Class H (180°C) standard, others available |
| Cooling | Air Natural (AN) |
| Enclosure Protection | Open frame or enclosed (IP20, IP23, IP54 optional) |
| Standards Compliance | Designed to meet IEC, ANSI, and other international standards |
The benefits of choosing our Dry-Type Isolation Transformer extend beyond the product itself:
- For Facility Managers: Reduces downtime by protecting critical equipment, lowers maintenance costs due to the dry-type design, and improves overall power quality.
- For System Integrators: Simplifies installation with provided wiring diagrams and flexible mounting, ensuring project timelines are met.
- For End-Users: Guarantees the safe and reliable operation of sensitive loads like CNC machines, laboratory instruments, and hospital diagnostic equipment.
Backed by Jinhua Dika Electrical's strong manufacturing foundation, including certifications like ISO9001 for quality management and ISO14000 for environmental management, our products are trusted globally. With an annual export value between US$1 Million and US$1.5 Million and a presence in major markets including North America, Europe, Southeast Asia, and Oceania, we have proven our capability to deliver consistent quality. Our efficient logistics through ports like Shanghai, Tianjin, Guangzhou, and Ningbo ensures timely delivery. Choose our Dry-Type Isolation Transformer for a solution that combines technical excellence with documented verification and global reliability. Contact us today to discuss your specific requirements and receive a detailed quotation.
Frequently Asked Questions (FAQ)
-
Q: What is the main purpose of a dry-type isolation transformer?
A: Its primary function is to provide complete electrical separation (isolation) between two circuits. This enhances safety by preventing shock hazards, protects equipment from voltage spikes and noise on the power line, and eliminates ground loop issues. -
Q: Why does this transformer come with a Mill Test Report (MTR)?
A: The MTR is a certificate from the material supplier that verifies the chemical and physical properties of the core steel and winding conductors used. It provides traceability and assures you of the raw material quality, which is crucial for performance and longevity. -
Q: Can I install this transformer outdoors?
A: Standard dry-type transformers are designed for indoor use. However, we offer optional enclosures with higher IP (Ingress Protection) ratings, such as IP54, which provide protection against dust and water jets, making them suitable for sheltered outdoor locations. Please specify your environmental conditions. -
Q: How do I know which voltage rating and kVA size I need?
A: You need to match the transformer's input voltage to your supply voltage and its output voltage to your load requirements. The kVA rating should be equal to or greater than the total connected load (considering inrush currents). Our technical team can assist you with sizing based on your application details. -
Q: Is the wiring diagram easy to follow for installation?
A: Yes, the provided wiring diagram is a clear, schematic representation of all terminal connections (primary and secondary). It uses standard symbols and labels, making it straightforward for qualified electricians to perform a correct and safe installation. -
Q: What is the typical delivery lead time for a custom specification?
A: Lead times vary based on the complexity and power rating. For standard models, shipment can often be arranged quickly. For fully customized units, production typically takes 3-6 weeks after order confirmation. We provide accurate timelines during the quotation process. -
Q: Do you provide any after-sales support or warranty?
A: Yes, we offer a standard warranty on our transformers against manufacturing defects. Additionally, our engineering team provides technical support for installation guidance and troubleshooting if needed. -
Q: Are these transformers energy efficient?
A: Yes. By using high-quality, low-loss materials in their construction, our dry-type isolation transformers are designed for high efficiency, which helps reduce operating costs over their lifespan.
