Help CenterSolar Powered Wireless PT100 High Temperature Sensor for Industrial Boiler Furnace Monitoring
Product Spotlights
Wireless Remote Monitoring;
Solar Powered Design;
Industrial Grade Reliability;
Custom High Temperature Extension Cable;
Real-Time Temperature Monitoring;
Explosion Proof Optional;
Flexible Communication Options.
Related Products
-
Self-powered Split Core Smart AC 1A~400A Current Sensor Current Transducer With LoRa for AC Motors & Power Grid RenovationUS$ 200MOQ: 1 Set -
Split Core AC 0.2A-100A Current Sensor Current Transformer With RS485 Interface and Modbus RTU ProtocolUS$ 60MOQ: 1 Piece
-
Wireless All in One Air Cleanliness Monitor Online Dust Temperature Humidity Dew Point and Wind Direction for WorkshopUS$ 1499MOQ: 1 Piece
-
Wireless Probe-type Temperature and Humidity Sensor: Real-Time Monitoring for Smart Environment ControlUS$ 65MOQ: 1 Piece
-
Wireless Laser Distance Meter Rangefinder: Industrial Fast Response and Stable PerformanceUS$ 150MOQ: 1 Piece
DAQ -LP- IRT LoRa Industrial Wireless PT100 Temperature Sensor with High Temperature Extension Cable
1.Product Features
High Temperature Resistance
Supports temperature monitoring below 1000°C using industrial-grade PT100 sensing technology, suitable for harsh high-temperature environments.
Wireless Remote Monitoring
Enables long-distance wireless temperature data transmission for industrial online monitoring systems.
Solar Powered Design
Equipped with solar power supply for low power consumption and long-term outdoor operation.
Industrial Grade Reliability
Designed for industrial automation and IIoT applications with stable performance in demanding environments.
Custom High Temperature Extension Cable
High temperature resistant extension cable length can be customized according to customer requirements.
Real-Time Temperature Monitoring
Supports continuous real-time temperature acquisition and abnormal temperature warning.
Multiple Industrial Applications
Widely used in:
Boilers
Furnaces
Kilns
Pipelines
Power equipment
Energy management systems
Industrial machinery monitoring
Explosion Proof Optional
Explosion-proof versions available for hazardous industrial environments.
Flexible Communication Options
Can be integrated with RS485, Modbus RTU, LoRa, NB-IoT, 4G or other industrial communication solutions.
2.Technical Specifications
| Item | Specification |
|---|---|
| Sensor Type | PT100 RTD |
| Temperature Range | 0°C to 1000°C (customizable) |
| Accuracy | ±0.5% FS |
| Power Supply | Solar Powered / DC Power Optional |
| Wireless Communication | LoRa / NB-IoT / 4G / RF Optional |
| Output Interface | RS485 / Modbus RTU Optional |
| Transmission Distance | Depends on wireless solution |
| Extension Cable | High Temperature Resistant |
| Cable Length | Customizable |
| Installation Type | Industrial Fixed Installation |
| Protection Level | Industrial Grade |
| Explosion Proof | Optional |
| Operating Environment | High Temperature Industrial Environment |
| Application | Boiler, Kiln, Furnace, Pipeline, Industrial Equipment |
3.Photo Review & Applications
4.Application Scenarios
Boiler Temperature Monitoring
Monitor boiler operating temperature in real time to improve safety and efficiency.
Furnace and Kiln Monitoring
Suitable for high temperature industrial furnace and kiln environments.
Pipeline Temperature Acquisition
Remote monitoring for industrial pipelines and thermal systems.
Equipment Overheat Warning
Supports industrial equipment temperature alarm and preventive maintenance systems.
Energy Management Systems
Can be integrated into industrial energy monitoring and automation platforms.
Customization Support
We support:
Custom cable length
Communication protocol customization
Wireless transmission solution customization
Industrial enclosure customization
OEM/ODM cooperation
Communication & Integration
The system can support:
RS485
Modbus RTU
LoRa
NB-IoT
4G wireless communication
Easy integration with SCADA, PLC, industrial gateways, and IIoT platforms.
5. Industrial Applications
Widely used in:
Power plants
Steel plants
Cement factories
Energy management projects
Industrial automation systems
Smart factory monitoring
Industrial IoT applications
