As a premier manufacturer based in Luoyang, Henan, Henan San Kuang Machinery Technology Co., Ltd. delivers precision-engineered High Strength Reducer Internal Gears specifically designed for demanding planetary drive systems. Leveraging our 10,000-30,000 square meter facility and a decade of specialized experience since 2014, we produce these critical components to transmit high torque with exceptional durability. Our internal gears, often referred to as ring gears or annulus gears, are the backbone of compact, high-efficiency power transmission, ensuring your planetary gearboxes operate with minimal backlash and maximum load capacity.
Understanding that the internal gear is the most stressed component in a planetary system, we utilize advanced metallurgy and precision machining. From material selection to final inspection, every step is governed by rigorous process control. This commitment results in a product that significantly extends service life and reduces downtime in critical applications such as construction machinery, industrial automation, and wind energy. We don't just supply parts; we provide a foundation of reliability for your entire drive system.
Core Features & Technical Specifications
Material Excellence & Heat Treatment: The performance of a ring gear is defined by its core strength and surface durability. We forge our gears from premium alloy steels such as 20CrMnTi and 42CrMo. The process involves precise carburizing and quenching, achieving a surface hardness of HRC 58-62 while maintaining a tough, ductile core. This dual characteristic provides exceptional resistance to wear, pitting, and bending fatigue, which are common failure modes in high-load planetary stages.
Precision Machining & Tooth Profile: Utilizing CNC gear grinding machines, we achieve tight tolerances and superior surface finishes. The involute tooth profile is optimized to ensure smooth meshing with planet gears, reducing noise and vibration. We adhere to ISO Class 6 to 8 precision grades, guaranteeing consistent load distribution across all contact points. This precision minimizes energy loss and heat generation, translating to higher overall system efficiency for your machinery.
Customization & Dimensional Range: Recognizing that off-the-shelf solutions rarely fit advanced engineering projects, we offer full customization. Our capabilities cover a wide spectrum, from small-diameter gears for servo mechanisms to large-diameter ring gears for heavy-duty industrial gearboxes. Parameters such as module, pressure angle, and addendum modification can be tailored to your exact specifications.
| Parameter | Specification / Capability |
| Material Options | 20CrMnTi, 42CrMo, 40Cr, Stainless Steel (optional) |
| Module Range | 1.0 mm - 20.0 mm |
| Outer Diameter | 50 mm - 1500 mm |
| Tooth Profile | Involute (Standard or Modified) |
| Heat Treatment | Carburizing, Nitriding, Induction Hardening |
| Surface Hardness | HRC 58-62 |
| Precision Grade | ISO 6, 7, 8 |
Advantages & Customer Benefits
Choosing our internal gears translates directly to competitive advantages for your machinery. The combination of high-strength materials and precision grinding delivers a gear set that withstands shock loads and frequent start-stop cycles without premature failure. This robustness is critical for applications like mining conveyors and offshore winches where reliability is non-negotiable.
- Extended Service Life: The deep-carburized layer and high surface hardness drastically reduce wear rates, extending maintenance intervals and lowering total cost of ownership.
- High Torque Density: Our gears are engineered to handle high torque loads within a compact envelope, allowing you to design smaller, lighter gearboxes without sacrificing power.
- Quiet Operation: Precision grinding of the tooth flanks ensures a smooth rolling action, minimizing noise pollution in industrial environments and enhancing operator comfort.
- Reduced Backlash: Tight manufacturing tolerances result in minimal lost motion, which is essential for precision positioning applications in robotics and CNC machinery.
- Supply Chain Simplification: We offer a one-stop solution from forging to finished gear, including optional splines, keyways, and threaded mounting holes, reducing your need for multiple vendors.
Quality Assurance & Process Control
Quality is not an afterthought; it is embedded in our manufacturing DNA. Our factory operates under a comprehensive management system, aligning with standards such as ISO9001 and IATF 16949. Incoming raw materials undergo spectral analysis to verify chemical composition. During production, in-process checks monitor dimensional accuracy, and post-heat-treatment hardness testing ensures uniformity. Every gear is subjected to final inspection using gear measuring machines, coordinate measuring machines (CMM), and non-destructive testing methods like magnetic particle inspection to guarantee zero defects.
We serve a diverse global clientele across North America, Europe, Southeast Asia, and Oceania, shipping from major ports including Shanghai, Qingdao, and Tianjin. Our annual export value of US$2.5 Million - US$5 Million reflects the trust customers place in our engineering capabilities. Whether you require a prototype sample or high-volume production runs, our team of 51-100 skilled professionals is ready to support your project with technical expertise and responsive service. Contact us today to discuss your planetary drive requirements and discover the difference that a high-performance internal gear can make.
Frequently Asked Questions (FAQ)
Q1: Can you manufacture an internal gear based on a sample or drawing?
A: Absolutely. We specialize in custom manufacturing. You can provide a physical sample for reverse engineering or a detailed technical drawing specifying the module, number of teeth, pressure angle, and material. Our engineering team will analyze the requirements and produce an exact match or an optimized version for your planetary drive system.
Q2: What is the typical lead time for a batch of custom internal gears?
A: Lead times depend on the complexity and quantity of the order. For standard customizations, the typical lead time is 30-45 days after final drawing approval. This includes forging, rough machining, heat treatment, finish grinding, and quality inspection. We always strive to accommodate urgent requests whenever possible.
Q3: What materials do you recommend for high-torque, low-speed applications?
A: For high-torque, low-speed scenarios common in heavy machinery, we frequently recommend 20CrMnTi with deep carburizing treatment. This material offers an excellent balance of a hard, wear-resistant surface (HRC 58-62) and a tough core that resists bending fatigue. For even higher core strength, 42CrMo is an excellent alternative, often used with nitriding or induction hardening.
Q4: Do you provide surface treatments other than carburizing?
A: Yes, we offer a variety of surface treatments based on application needs. These include nitriding for enhanced corrosion resistance and anti-galling properties, induction hardening for localized high hardness, and black oxide coating for mild corrosion protection and aesthetic finish. Please specify your environmental conditions when inquiring.
Q5: What quality checks are performed before shipment?
A: Our comprehensive quality control includes chemical composition analysis of raw material, dimensional inspection during machining, hardness testing after heat treatment, and 100% final inspection. We use gear measuring machines to verify tooth profile and lead, and CMMs for geometric tolerances. Non-destructive testing (magnetic particle or ultrasonic) is available upon request to ensure internal integrity.
Q6: Is it possible to add features like keyways or bolt holes to the ring gear?
A: Certainly. We are a full-service machining provider. In addition to the gear teeth, we can machine external features such as keyways, splines, threaded mounting holes, flanges, and bearing seats directly onto the ring gear. This integration simplifies your assembly process and ensures perfect concentricity.
Q7: What is the maximum outer diameter you can produce?
A: Our current machining capacity allows us to produce internal gears with an outer diameter of up to 1500 mm. For projects requiring larger dimensions, please contact our sales team to discuss feasibility, as we are continuously expanding our capabilities to meet market demands.
