Ventura AERO，20KSX22P，Ni-Cd Battery，Aviation F20/22H1C-1，VARTA HAWKER GmbH
US$ 7668 ≥1 Piece
Key Specifications
Get Latest Price
Type:
Other, Aviation nickel cadmium battery
Size:
Other, 24V22Ah
Usage:
Other, MiG-21、MiG-23、MiG-25、MiG-27、MiG-29、MiG-31
Contact Supplier Request Quote Chat Now
Silverfir Battery（shan Dong）co.，ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing
Delivery Detail:
50 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, Aviation nickel cadmium battery
Size Other, 24V22Ah
Usage Other, MiG-21、MiG-23、MiG-25、MiG-27、MiG-29、MiG-31
Connection Mode Series Connection
Rated Capacity Other, 25Ah
Discharge Rate High Discharge Rate
Accessories Type Other, Equipped with temperature sensor
Standard Voltage Other, 24V
Rechargeable Chargeable
Electrolyte Other, nickel-cadmium battery
Transport Package export wooden crate
Specification 20 KSX 22 P
Trademark VENTURA
Origin CHINA

Ventura AERO，20KSX22P，Ni-Cd Battery，Aviation F20/22H1C-1，VARTA HAWKER GmbH


WANG ZE LONG Aircraft battery


F20/22 H1C-1（20KSX22P）


P/N：3349022900


Ventura Batteries


　　Nickel-cadmium rechargeable batteries"20KSX 22 P"


　　Aviation nickel cadmium battery 20KSX 22 P.


　　Battery 20KSX-27


　　Aviation battery 20KSX-27


　　Application fields:


　　It is used as an onboard backup power source and buffer power source for automatic starting,auxiliary power units,and aircraft engines.


　　Aircraft List:


　　MiG-29


　　Technical specifications:


　　Rated capacity,A×H 27.0


　　Rated voltage 24.0


　　Continuous discharge current,up to 240


　　Starting discharge current,up to 700


　　Working temperature range,oC


　　-Has charging and discharging characteristics


　　-Maintain work ability


　　+5 to+50


　　60 to+60


　　GOST 15 150-69 All climatic conditions


　　Resistance to mechanical stress


　　-Vibration:


　　Frequency,Hz 10-2000


　　Acceleration G10


　　-Strike:


　　Acceleration g


　　8


　　Duration,ms 20


　　Electrolyte quality,kg 22


　　External dimensions(maximum),mm 433,5x134x182


　　Charging time 90 days


　　Warranty period,6 years


　　Long term charging stability


　　At high temperatures,according to the method


　　Page:12.6 GOST IEC 952-1-93 and MIL-D-26 comply with requirements


       www.ventura.hk



产品 LOGO



　　NiCd aircraft battery 20KSX20P


　　Technical data:


　　Nominal voltage:24 V


　　Nominal capacity C5:22 Ah


　　Cycle life:min.250 cycles


　　Weight:max.22 kg


　　Operating temperaturę:from-40°C to+60°C


　　Dimensions(in mm)L x W x H:427 x 129 x 188


　　Application:


　　Engine start-up for MiG-21.MiG-23,MiG-29.


　　Power system for onboard electric devices.



WANG ZE LONG Aircraft battery


20KSX22P MiG-21 Aviation Ni-Cd Batteries Ventura AERO Airworthiness certificate COO


20KSX22P MiG-21 Aviation Ni-Cd Batteries Ventura AERO Airworthiness certificate COO

Product Tags: 20 KSX 22 P , 24V22Ah , F20/22H1C-1
