HAWKERPZS 3PZB225 24V/48V Traction battery PO6809-5 HAWKER
HAWKERPZS 3PZB225 24V/48V Traction battery PO6809-5 HAWKER
The HawKer essential series battery is a highly reliable and cost-effective battery.This new series of products adheres to the technological characteristics of Hawker Power as a global leader in industrial batteries.A super cost-effective electric forklift battery.
product structure
Hawker's essential series products are new European designed open lead-acid batteries,using DIN and JIS specifications.
This series of products has a sturdy structure and adopts mature tubular electrode plate technology.The battery cells and battery covers are made of high-temperature resistant polypropylene material welded through heat sealing technology,which can effectively prevent acid leakage.
The battery cells are installed in customized boxes,connected by flexible bolts,sealed and insulated with connecting strips,ensuring safety,reliability,and easy maintenance.
The exhaust port cover adopts a flip design and is equipped with an electrolytic liquid level mark,which is safe to use and can fully discharge the gas released during charging,making maintenance convenient.
optional item
The electrolyte float and electrolyte warning light of JIS series batteries can be installed according to the height of the battery.
The water addition system is also available for ordering.This system can safely add water to the most suitable location through a water addition device,and can greatly shorten the water addition time.
It is recommended that users choose Hawker modular high-frequency chargers to be used in conjunction with batteries.Choosing chargers of the same series can keep the battery charging in the best condition,thereby maximizing the battery's service life.
The charger uses high-quality electronic components,and a perfect charging curve can not only optimize battery charging,but also save a lot of power consumption,which is energy-saving and environmentally friendly.
HAWKER charger adopts innovative module design,making maintenance and use more convenient.
characteristic
High reliability and cost-effectiveness
Advanced structure,high-quality components
Suitable for most brand hosts and vehicle models
Hawker Power Group's globally unified design and manufacturing process
Our branches are located in various regions,providing convenient and timely service and support
PzJD&PzJB cells-Hawker essential,bolt-on connectors,dimensions resembling DIN/EN 60254-2,IEC 60254-2,GBT 7403-1/2
Cell Designation
2PZJD160 3PZJD240 4PZJD320 5PZJD400 6PZJD480 7PZJD560 8PZJD640
2PZJD230 3PZJD345
4PZJD460 5PZJD575 6PZJD690 7PZJD805 8PZJD920
2PZJD250 3PZJD375 4PZJD500 5PZJD625 6PZJD750 7PZJD875 8PZJD1000
2PZJD280 3PZJD420 4PZJD560 5PZJD700 6PZJD840 7PZJD980 8PZJD1120
2PZJD310 3PZJD465 4PZJD620
5PZJD775 6PZJD930 7PZJD1085 8PZJD1240
HAWKER®WATER LESS®BATTERIES COMBINE THE POWER AND RELIABILITY OF TUBULAR VENTED TECHNOLOGY(PZS)WITH THE CONVENIENCE OF EXTENDED WATERING INTERVALS–4,8 OR 13 WEEKS,DEPENDING ON THE CHARGING TECHNOLOGY.LESS FREQUENT TOPPING OFF MEANS REDUCED LABOR COSTS–UP TO 60%(WITH HAWKER 50 HZ CHARGERS)AND UP TO 75%(WITH HAWKER HF SMART CHARGERS).
All Hawker Water Less cells use proven PzS technology.The positive electrodes are diecast tubular plates(PzS)and advanced components used in the manufacture provide increased efficiency.The negative plates are flat pasted plates,and the separator is microporous.In addition to extended watering intervals,Hawker Water Less batteries also feature a low electrolyte level indicator that tells operators when it's time to top up.
PRODUCT SPECIFICATION
Take a look at the following Hawker®Water Less®product specification:APPLICATION
Forklifts&Pallet Trucks
Automated Guided Vehicles
Floor Care/Cleaning Machines
Ground Support Equipment TECHNOLOGY/CHEMISTRY
Flooded lead acid CAPACITY(MIN)-EUROPE STANDARD
120 CAPACITY(MAX)-EUROPE STANDARD
1860 CAPACITY(MIN)-US STANDARD
0 CAPACITY(MAX)-US STANDARD
0 VOLTAGE(MIN)
12 VOLTAGE(MAX)
120 COMMUNICATION CAPABILITIES
Ethernet DESIGN
DIN sizes
Hawker PZM Battery
Water Less®It is a new type of high-efficiency traction battery designed with the best and most innovative technological solutions to meet the demands of today's operating modes.
Due to the reduced charging intervals of 4,8,or 13 weeks required for maintenance,the battery provides greater flexibility and higher operational efficiency,depending on the charging technology.This translates into reduced operational costs for battery refilling and maintenance.
All Water Less®All batteries use validated PzS technology.The positive electrode is composed of pressure cast tubular plates,and advanced components are used in production to improve efficiency.The negative electrode is composed of a flat plate coated with active material.The partition is of microporous type.
The implemented technical specifications,such as higher electrolyte capacity,reduced prism height,and new manual cover,ensure low maintenance added value,which is one of the biggest demands in traction applications.
Hawker Water Less®-Shorter maintenance time translates into greater customer benefits.
