Help CenterAutomatic Busbar Processing Machine for Energy Storage Cabinet and Battery Pack Manufacturing EB-60TP-6
Product Spotlights
Supports flat and vertical bending: adaptable to different busbar structures and complex processing requirements.
Related Products
-
CNC Copper Aluminum Busbar Punching Bending Cutting Machine for EV Battery and Energy Storage Systems EB-40TP-5NegotiableMOQ: 5 Cartons -
AI Smart New Energy Copper Aluminum Busbar Bending Machine for EV Battery & Energy Storage Manufacturing EB-40E-6NegotiableMOQ: 5 Pieces
-
Automatic Wiper Arm Forming Machine for Automotive and EV Manufacturing EB-15W-4TNegotiableMOQ: 5 Cartons
-
CNC Enamel Wire Busbar Bending Machine for EV Motor and Hairpin Stator Manufacturing EB-1250ZPNegotiableMOQ: 5 Cartons
-
Automatic Hairpin Winding Machine for Electric Vehicle Drive Motor Production EC-680NegotiableMOQ: 5 Cartons
Integrated design: combines bending, punching, and cutting in one machine, significantly improving productivity while saving labor and space.
Supports flat and vertical bending: adaptable to different busbar structures and complex processing requirements.
High processing accuracy: equipped with high-performance servo systems and CNC control to ensure dimensional consistency and stability.
Smart control system: equipped with industrial controller, supports 3D drawing import and auto-programming with visual path simulation; easy operation and short setup time.
Compatible with various coil materials: processes copper, aluminum, and other busbar types in different sizes.
Customizable solutions: optional features like automatic loading/unloading and laser marking are available to meet specific process requirements.
Model |
EB-60TP-6 |
Processing Capacity |
Thickness : 2.0mm ≤ T ≤ 6.0mm Width : 15.0mm ≤ W ≤ 50.0mm |
Axis |
10 |
Wire Feed Wheel Sets |
4 Sets |
Wire Feeding Motor Power |
5.5kw |
Slide Motor Power |
2.7KW×3 |
Spinner Motor Power |
2.0KW×2 |
Punching Motor Power |
7.5KW |
Cutter Moving Motor Power |
0.4KW |
Punch Head Moving Motor Power |
0.75KW |
Mold Moving Motor Power |
1.2KW |
Cutter Motor Power |
1.0KW |
Punching Force |
12T |
Dimension(LxWxH) |
4200X2000X2200(mm³) |
Weight |
5000kg |
