Help CenterCustomized Large-diameter Electromagnetic Flowmeter, Professional Dn200 Pipeline Integrated Intelligent Digital Display Pipeline Water Flowmeter
Related Products
-
Qingliu Instrument Integrated Pipeline Explosion-proof Electromagnetic Flowmeter for Acid-base Liquids, Concrete, Tap Water, Fire Water, and SewageUS$ 307.69 - 630.77MOQ: 1 Unit -
One-piece Intelligent Electromagnetic Flowmeter, Intelligent Flowmeter in Stock for Wholesale. Dn50 for Mud, Sewage, Liquid Water Pipes. Manufacturer of One-piece Electromagnetic FlowmetersUS$ 307.69 - 630.77MOQ: 1 Unit
-
Intelligent Flow Meter, Pipeline Flow Meter Dn25 Anti-corrosion, Direct Supply From the Manufacturer of Intelligent Electromagnetic Flow Meter, Led Electromagnetic Flow Meter, Electronic Flow SensorUS$ 307.69 - 630.77MOQ: 1 Unit
-
Qingliu Instrument Integrated Pipeline-type Explosion-proof Intelligent Flow Meter Dn50 for Mud, Sewage, and Liquid Water Pipelines Ldql Integrated Electromagnetic Flow Meter ManufacturerUS$ 307.69 - 630.77MOQ: 1 Unit
-
Qingliu Instrument Electromagnetic Heat Meter and Flow Meter for Heating Pipes Dn50/80/100, Central Air Conditioning Cooling and Heating Energy MeterUS$ 307.69 - 630.77MOQ: 1 Unit
Tag:Electromagnetic Flowmeter,Shandong Electromagnetic Flowmeter,Electromagnetic Flow Sensor
Electromagnetic Flow SensorIt is designed based on Faraday's law of electromagnetic induction. A pair of detection electrodes are installed on the pipe wall where the axis of the measuring tube and the magnetic field lines are perpendicular to each other. When the conductive liquid moves in the alternating magnetic field along the measuring tube in a direction perpendicular to the magnetic field lines, the conductive liquid cuts the magnetic field lines to generate an induced electromotive force, which is detected by the two detection electrodes on the measuring tube.
2.Features
2.1 Electromagnetic FlowmeterAdopts an integral welding structure with good sealing performance.
2.2 Simple and reliable structure, no moving parts, almost no pressure loss, and long working life.
2.3 Electromagnetic FlowmeterHas no flow-intercepting parts and no blockage phenomenon, so it is suitable for measuring two-phase flows with suspended solids, solid particles, and fibers. In addition, since it is convenient for cleaning, sterilization, and disinfection, it is especially suitable for the food and pharmaceutical industries.
2.4 The measurement accuracy is not affected by changes in physical parameters such as pressure, temperature, density (including solid-liquid ratio), and viscosity of the measured medium.
2.5 Electromagnetic Flow SensorAdopts low-frequency binary rectangular wave excitation and sampling amplification technology, with strong anti-interference ability, stable zero point, and reliable operation.
2.6 The instrument is sensitive, the output signal is proportional to the flow, and the range ratio is wide.
2.7 Low power consumption. The power consumption of the complete set of electromagnetic flowmeter is less than30VA, It has nothing to do with the caliber size of the sensor.
2.8 The electromagnetic flowmeter can provide an explosion-proof type (hybrid explosion-proof type), with an explosion-proof grade ofmdⅡBT4.
Shandong Electromagnetic Flowmeter
