Detailed Description of Shipbuilding Steel Plate
Shipbuilding steel plates are hot-rolled steel plates manufactured in accordance with international classification society standards, applied to hull structures and marine engineering equipment. They feature high strength, excellent toughness, superior weldability and good corrosion resistance, capable of withstanding wave impact, seawater corrosion, low temperature environment and complex mechanical loads.
1. Implementation Standards & Certifications
Domestic Standard
GB/T 712-2022 Steel for ship and offshore engineering structures
International Classification Society Certifications
CCS, ABS, BV, DNV, LR, NK, KR, GL, RINA
Grade Definition
Grade A/B/D/E: Gradually improved low-temperature toughness (A: 0℃, B: 0℃, D: -20℃, E: -40℃)
AH/DH/EH/FH: High-strength series, letters stand for impact temperature
Z15/Z25/Z35: Lamellar tearing resistance grades in thickness direction
2. Material & Strength Grades
General Strength Ship Plate (Yield Strength ≥235MPa)
Grades: CCSA, CCSB, CCSD, CCSEApplication: Ordinary cargo ships, inland waterway vessels, superstructure
High Strength Ship Plate
| Grade | Yield Strength | Tensile Strength | Typical Application |
|---|---|---|---|
| AH32/DH32/EH32 | ≥315MPa | 440–570MPa | Container ship, bulk carrier |
| AH36/DH36/EH36 | ≥355MPa | 490–630MPa | Oil tanker, LNG carrier, warship |
| AH40/DH40/EH40 | ≥390MPa | 510–660MPa | Super large vessel, offshore platform |
Typical Chemical Composition (%)
C≤0.18, Mn:0.70-1.20, Si:0.10-0.50, S≤0.035, P≤0.035Trace Nb, V, Ti for grain refinementCarbon Equivalent Ceq ≤0.36% to ensure excellent weldability
3. Specifications & Delivery Condition
Size Range
Thickness: 4.5-100mm, common size 6-50mm
Width: 1500-4020mm
Length: 3000-27000mm, customized length available
Delivery Status
AR (As Rolled): Economic type for Grade A/B
N (Normalized): Uniform structure for Grade D/E
TMCP: Thermo-mechanical controlled rolling, ideal for high strength grade
Ultrasonic testing available per relevant standards
4. Core Performance
Mechanical properties fully comply with standard requirements
Excellent low temperature impact toughness
Good weldability, suitable for various welding methods
Fine seawater and atmospheric corrosion resistance
5. Main Applications
Hull structure: hull shell, deck, bulkhead, keel, bilge plate
Marine engineering: offshore platform, jacket, FPSO, offshore wind power foundation
Various vessels: bulk carrier, oil tanker, container ship, icebreaker
Port machinery, dock facilities and heavy engineering structures
6. Packaging & Delivery
Packing: Steel strapping with anti-rust film, marked with steel grade, size, heat number and certification stamp
Delivery time: 5-7 working days, direct shipment from Tianjin & Shandong warehouse
7. Product Advantages
Complete classification society certifications for global market
Outstanding low temperature toughness suitable for cold sea areas
Stable material purity and uniform thickness, high inspection pass rate
Easy welding processing, improve shipbuilding efficiency
