30A 50A 60A PWM Solar Charge Controller Professional After Sales Support
Model |
LP-CM3024 |
LP-CM5024 |
LP-CM6024 |
LP-CM3048 |
LP-CM5048 |
LP-CM6048 |
PV voltage |
≤50V |
|||||
Rated Charge current |
30A |
50A |
60A |
30A |
50A |
60A |
Rated system voltage |
12V/24V Auto 12V/48V |
|||||
Rated Discharge current |
30A |
50A |
60A |
30A |
50A |
60A |
Charge mode |
PWM Multi-stage (bulk, absorption,float) |
|||||
Float charge voltage |
13.8V(13V-15V)x1/x2 |
13.8V(12.8V-14.2V)x1/x2 |
||||
Absorption voltage |
14.4V( 13V-15V) x1 /x 2,(lasting:2hrs) |
14.4V( 13.6V15.2V) x 1 /x2.(lasling:2hrs) | |
||||
LVD voltage |
10.7V(10V-14V1x1/x2 |
10.8V(10.5V12V)x1/x2 |
||||
LVR voltage |
12.6V(10V-14V)X1/X2 |
12.6V(11.5V-13V)x1/x2 |
||||
HVD voltage |
16.0VX1/X2 |
|||||
HVR voltage |
15.5Vx1/x2 |
|||||
Overload protection voltage |
≥ 1.2x rated current,60s ≥1,5x rated current, 10s ≥1.8x rated current,0.2s |
|||||
Charge circuit voltage drop |
||||||
Discharge circuit voltage drop |
||||||
No load loss |
≤2mA |
≤13mA |
≤14mA |
|||
USB output |
5V/1A |
N/A |
||||
Battery type |
GEL,SLD,FLD,Usr(default) |
|||||
Installing cable size |
||||||
Working temperature |
-20℃~50℃ |
-20℃~55℃ |
||||
Dimension(mm) |
168×88×28 |
188×95×40 |
196×111×54 |
188×125×48.5 |
188×125×56 |
|
Weight |
220g |
355g |
360g |
395g |
565g |
715g |
Over load protection |
Yes |
|||||
Application |
Solar System Controller |
|||||
Product name |
Solar Controller |
|||||
Display |
LCD Screen |
|||||
Working temperature |
-20 ℃ to 55 ℃ |
For more information, pls contact my whatsapp: https://wa.me/13435253312
Welcome to discuss it with us together!
