LantoPower 12kW 48V Dual MPPT Hybrid Solar Inverter – 15kW PV Input, 24kVA Surge, Pure Sine Wave UPS for Large Home & Farm
Specification
AC Input |
Rated Input Voltage (VAC) |
208 / 220 / 230 / 240; L+N+PE |
Voltage Range (VAC) |
90~280±3 (normal mode); 170~280±3 (UPS mode) | |
Frequency (Hz) |
50 / 60 (Auto Adaptive) | |
AC Output |
Rated Capacity (kW) |
12 |
Surge Power (kVA) |
24 | |
Voltage (VAC) |
208 / 220 / 230 / 240 | |
Power Factor (PF) |
1 | |
Frequency |
50/60Hz±0.1% | |
Switch Time (ms) |
10 (normal mode) / 10 (UPS mode) | |
Wave Form |
Pure Sine Wave | |
Overload Capacity (Battery Mode) |
1min@102%-125%load, 10s@>125% load | |
Max. Efficiency (Battery Mode) |
94%@48VDC | |
Parallel Quantity |
NA | |
Charger (PV / AC) |
Solar Charger Type |
Dual MPPTs |
Max. PV input Current / Input Power |
Using One MPPT: 27A/9KW Using Two MPPTs: 22.5A/Per MPPT, 15kW/Total |
|
MPPT Range@Operating Voltage (VDC) |
60~450 | |
Max PV Open Circuit Voltage (VDC) |
500 | |
Max PV Charge Current (A) |
160 | |
Max AC Charge Current (A) |
160 | |
Max. Charge Current (PV + AC) (A) |
160 | |
Battery |
Normal Voltage (VDC) |
48 |
Floating Charge Voltage (VDC) |
54 | |
Overcharge Protection (VDC) |
61 | |
Battery Type |
Lead-acid / Lithium | |
Interface |
HMI |
LCD |
Interface |
RS232 / RS485 / CAN (optional) | |
Monitoring |
Wifi(optional) | |
General Data |
Ingress Protection |
IP21 |
Operating Temperature |
-10°C ~ 60°C | |
Relative Humidity |
5% - 95% (Non-condensing) | |
Storage Temperature |
-15°C ~ 60°C | |
Net Weight (kg) |
15 | |
Dimensions (H*W*D) |
514*442*121mm | |
Max. Operating Altitude |
4000m (Derating above 1000m) |
Packaging and delivery
Selling Units:Single item
Single package size: 52.2X38.8X11 cm
Single gross weight: 20.000 kg
