1、 Model Interpretation
02: Wide cross-section heavy-duty series, with a wider inner diameter and greater load-bearing capacity than the 01 series
E: Reinforced structure, roller lengthening and thickening, optimized raceway, impact resistance, and higher load capacity
B: Split cylindrical roller bearing
50: nominal inner diameter 50mm
M: Brass solid holder, resistant to high temperature, impact, heavy load and not easily deformed
2、 Standard size
Inner diameter: 50 mm
Outer diameter: 90 mm
Width: 45 mm
3、 Basic parameters
Material: High carbon chromium bearing steel GCr15, quenched high hardness, wear-resistant and fatigue resistant
Structure: Fully 180 ° split in half, inner and outer rings, rollers, and retaining frames can be separated
Applicable to low-speed heavy load, slight alternating impact, and dusty and humid working conditions
Temperature resistance: -30 ℃ to 180 ℃
Features: Comes with micro adjustment, suitable for slight misalignment of the shaft system during installation
4、 Core advantages
02 Wide cross-section heavy load
Compared to 01EB50M, the same inner diameter is wider and thicker, with more rollers and a larger force bearing area. Even with a small shaft diameter, it can withstand heavy loads.
Fully split non removable shaft
Without dismantling the main shaft or moving the coupling gears, it can be directly opened and closed on the shaft for quick maintenance and reduced downtime costs.
E-shaped enhanced version
Compared to the ordinary 02B50M, the roller structure of the raceway is strengthened, resistant to impact, more wear-resistant, and has a longer lifespan.
Brass solid holder
Good rigidity, high temperature resistance, compression resistance, and long-term continuous operation without deformation or detachment.
Can be equipped with sealing
Optional labyrinth seal and skeleton oil seal, dustproof, waterproof, and anti impurity entry, suitable for harsh environments.
5、 Applicable equipment
Small mining machinery, micro crushers, and small winch transmissions; Light industry conveying equipment, textile machinery, grain and oil processing equipment; All heavy-duty support positions with a 50mm shaft diameter, limited space, inconvenient disassembly and assembly, and requiring online maintenance.
6、 Installation and maintenance
Clean the journal and bearing seat, align the two halves of the joint, and tighten the splicing bolts diagonally and evenly; Add extreme pressure heavy-duty grease and fill two-thirds of the cavity; Regularly replenish grease on a daily basis. If there is temperature rise, abnormal noise, or vibration, check the bolt pre tightening force and seal in a timely manner.
