1、 Model analysis
02: Wide cross-section heavy-duty series, wider and capable of carrying larger loads than the 01 series with the same inner diameter
E: Reinforced structure, thickened and lengthened rollers, optimized raceway, impact resistance, and increased load capacity
B: Split cylindrical roller bearing
245: Bearing nominal inner diameter 245mm
M: Brass solid holder, resistant to high temperature, impact, heavy load and not easily deformed
2、 Standard external dimensions
Inner diameter: 245 mm
Outer diameter: 380 mm
Width: 142 mm
3、 Basic performance parameters
Material: High carbon chromium bearing steel GCr15, with high quenching hardness, wear resistance and fatigue resistance
Structure: 180 ° fully split, inner and outer rings, rollers, and retainers can all be split in half
Applicable working conditions: low-speed heavy load, alternating impact, high dust, humidity, and harsh industrial and mining conditions
Temperature resistance range: -30 ℃ to 180 ℃
Features: It has micro centering and is compatible with minor misalignment of the shaft system during installation
4、 Core structural advantages
02 Wide Series Heavy Duty Design
The cross-section is wider and wider, the roller arrangement is dense, and the stress area is large. Compared with the 01EB series, the same inner diameter has a stronger load-bearing capacity, making it suitable for heavy load support of large equipment.
Fully split non removable shaft
Without disassembling the main shaft, moving the coupling and gears, it can be opened and disassembled directly on the shaft, saving time and effort in maintenance, and greatly reducing downtime losses.
E-type enhanced upgrade
Compared to the ordinary 02B245M, the roller and raceway structure is strengthened, resistant to impact and wear, and the service life is significantly improved.
Brass solid holder
Rigid enough, heat-resistant, and resistant to compression, it is not easy to deform or crack during long-term continuous heavy load operation, suitable for continuous operation in mining and metallurgy all year round.
Can be equipped with sealed protection
Optional labyrinth seals and skeleton oil seals can be installed to prevent dust, water, and impurities from entering, suitable for harsh environments in mines, cement, and ports.
5、 Applicable device scenarios
Mining: coal mining machine rocker arm, scraper conveyor, large ball mill, crusher Metallurgical cement: rotary kiln, large conveying transmission, rolling mill auxiliary shaft system Port heavy industry: crane, bucket wheel machine, large winch walking mechanism Ship, papermaking, grain and oil heavy industry, etc. 245mm shaft diameter, difficult disassembly and online maintenance of heavy-duty support positions
