Fan motors and vacuum cleaner motors belong to high-speed micro motors and are widely used in household vacuum cleaners, hair dryers, fresh air fans, cooling fans, industrial negative pressure fans, and vehicle-mounted fans.
Hangzhou Changniu Technology's dedicated dynamometer for fan/vacuum cleaner motors is a specialised testing device developed specifically for the operating characteristics of high-speed fan motors, designed for brushless vacuum cleaner motors, DC fan motors, AC fan motors, and high-speed blower motors. The device can accurately simulate wind resistance loads and dynamic wind pressure conditions, completing a full set of performance tests in one go, including motor speed, torque, input and output power, efficiency, air volume, air pressure, temperature rise, noise, and durability ageing, matching the factory quality inspection, R&D benchmarking, performance rectification, and third-party testing standards of the home appliance industry.
Core test items:
This equipment fully conforms to the testing standards of the fan and vacuum motor industry, covering all essential items for enterprises:
- Basic electrical performance: no-load speed, no-load current, operating current, input power, voltage test
- Power performance test: torque, output power, and overall efficiency under different wind resistance loads
- Aerodynamic performance test: air volume, air pressure, negative pressure, wind speed, wind resistance characteristic curve test
- Temperature rise and endurance test: long-term continuous operation temperature changes, ageing and endurance performance test
- Noise and vibration test: simulate real air duct environment, test motor running noise and vibration stability
- Dynamic operating test: simulate vacuuming, drying, high/low gear switching, frequent start/stop operating conditions
- Data curves and reports: automatically generate speed-efficiency, air pressure-air volume, load characteristic curves, and one
- click export of standard test reports
Compatible motor types:
- High-speed brushless and brushed vacuum cleaner motors - Household hair dryers, blowers, and heating fan motors
- DC cooling fans, AC axial fans, centrifugal fan motors
- Fresh air system fans, duct fans, industrial negative pressure fan motors
- Vehicle-mounted fans, purifier fan wheel motors, small blower motors
Applications:
- Production quality inspection: full inspection, sampling, and gear performance determination for fan and vacuum cleaner motors
- R&D improvement: new motor structure optimisation, fan blade matching, air duct tuning, noise optimisation tests
- Incoming inspection: performance verification of motors for home appliance assembly factories, preventing defective materials
- Research and education: fluid mechanics and fan power performance experiments at universities
- Certification testing: meets national and industry standard testing requirements, supports sending for inspection and type testing
For detailed technical parameters, solution quotations, and equipment cases of the fan and vacuum cleaner motor dynamometer, please feel free to consult us. We will provide you with a personalised, one-on-one custom testing solution. ...
