Food Grade Control Valve With CIP Cleaning Compatibility
Product Spotlights
Hygienic control valves featuring full CIP compatibility for contamination-free processing. Manufactured from certified 316L stainless steel with Ra ≤ 0.8μm surface finish. Available in multiple actuation types and connection standards. Reduces cleaning downtime while ensuring compliance with global food safety protocols. Supported by worldwide distribution network.
Negotiable
MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Stainless Steel 316L
Connection Size:
1/2“ to 6“ available
Actuation Type:
Manual/Pneumatic/Electric optional
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Industrial Automatic Control Valve for Process Temperature PressureNegotiableMOQ: 50 Pieces -
3-Way Proportional Control Valve With Modbus RTU CommunicationNegotiableMOQ: 50 Pieces
-
DN50 PN16 Electric Regulating Valve With 4-20mA Signal InputNegotiableMOQ: 50 Pieces
-
Corrosion Resistant Regulating Valve for Slurry and Oil MediumNegotiableMOQ: 50 Pieces
-
PTFE Lined Control Valve for Corrosive Chemical ApplicationsNegotiableMOQ: 50 Pieces
Material
Other, Stainless Steel 316L
Connection Size
1/2“ to 6“ available
Actuation Type
Manual/Pneumatic/Electric optional
Application
Food, Beverage, Pharmaceutical
Pressure Rating
Up to 150 PSI
Temperature Range
-10°C to 150°C
Surface Finish
Ra ≤ 0.8μm
CIP Compatibility
Full compatibility
Seal Material
EPDM/FKM/Silicone
As a specialized agent with global reach since 2015, Shanghai CAMP Environmental Protection Technology brings you premium food grade control valves designed for demanding hygienic applications. Our valves ensure precision flow control while meeting stringent sanitary requirements, making them indispensable in food processing, dairy, and pharmaceutical industries where product purity is paramount.
The integration of CIP (Clean-in-Place) compatibility delivers significant operational advantages:
- Reduces downtime for manual cleaning by up to 70%
- Ensures consistent hygiene validation results
- Minimizes cross-contamination risks between batches
- Extends service life through reduced chemical stress
Technical specifications include:
| Parameter | Specification |
|---|---|
| Body Material | AISI 316L Stainless Steel |
| Flow Coefficient (Cv) | 2.5 to 60 (depending on size) |
| Leakage Class | ANSI/FCI 70-2 Class IV |
| Dead Leg Compliance | 3D or better |
Critical design features ensure optimal performance:
- Diaphragm-sealed design eliminates crevices where bacteria could harbor
- Polished surfaces (Ra ≤ 0.8μm) prevent microbial adhesion
- Tri-Clamp or weld connections maintain system integrity
- Multi-position mounting accommodates complex piping layouts
With distribution networks spanning North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, and domestic markets, we deliver reliable solutions backed by local technical support. Our decade-long industry presence ensures you receive valves engineered for zero contamination risk and maximum operational efficiency.
FAQ Section
-
Q: Are these valves suitable for viscous fluids like dairy products?
A: Absolutely. Our specialized trim designs handle viscosities up to 50,000 cP without clogging. -
Q: What certification documentation is provided?
A: We supply material traceability reports (MTRs), 3.1 material certificates, and surface roughness validation. -
Q: Can existing valves be retrofitted for CIP compatibility?
A: Select models offer retrofit kits. Contact our engineers for compatibility assessment. -
Q: What is the lead time for electric actuated versions?
A: Standard units ship in 4-6 weeks. Expedited options available upon request. -
Q: How do you prevent seal degradation during CIP cycles?
A: Our proprietary EPDM/FKM compound formulation resists caustic solutions up to 4% concentration at 85°C. -
Q: Are custom connection types available?
A: Yes. We offer SMS, DIN, BSP, and JIS standards beyond standard Tri-Clamp.
