Help CenterASME B16.5 Compliant Discharge Valve With Full Maintenance Documentation
Product Spotlights
Related Products
-
Zero-Residue Discharge Valve for Pharmaceutical Reactor Bottom InstallationNegotiableMOQ: 1 Piece -
High-Temp Discharge Valve 20°C-425°C for Reactors and Storage TanksNegotiableMOQ: 1 Piece
-
Manual/Automatic Discharge Valve PN10/PN16 CLASS 150 Flange ConnectionNegotiableMOQ: 1 Piece
-
Short-Stroke Discharge Valve With Hard Alloy Sealing for Chemical ProcessingNegotiableMOQ: 1 Piece
-
Bottom Discharge Valve VTF-88-3 Series, DN25-DN300, Stainless Steel 316L/Carbon Steel, PN10/PN16 Class 150, Manual or Pneumatic ActuationNegotiableMOQ: 1 Set
Shanghai CAMP Environmental Protection Technology Co., Ltd., established in 2015, proudly presents our ASME B16.5 Compliant Discharge Valve engineered for demanding industrial applications. This precision-crafted valve delivers exceptional reliability in fluid control systems while including comprehensive maintenance documentation to minimize downtime. With extensive experience serving global markets including North America, South America, and Europe, our solutions meet rigorous international standards. The valve's robust construction ensures long-term performance in critical processes across multiple industries.
Core Technical Specifications:
- Pressure Rating: 150LB to 2500LB options
- Temperature Range: -29°C to 425°C
- Face-to-Face Dimensions: ASME B16.10 compliant
- Flange Dimensions: Per ASME B16.5 Table
- Leakage Class: ANSI FCI 70-2 Class IV or better
| Size (NPS) | Pressure Class | Flow Coefficient (Cv) |
|---|---|---|
| 2" | 300# | 48 |
| 4" | 150# | 195 |
| 8" | 600# | 780 |
Maintenance Documentation Includes:
- Installation procedures with torque specifications
- Step-by-step disassembly/assembly guides
- Seal replacement kits documentation
- Troubleshooting matrices for common issues
- Parts cross-reference lists
With distribution networks spanning 6 continents including Southeast Asia, Africa, and Oceania, Shanghai CAMP has delivered industrial valve solutions to over 40 countries since 2015. Our valves undergo rigorous quality verification through 12 separate checkpoints during manufacturing. The comprehensive maintenance documentation reduces mean time to repair by up to 65% based on client feedback, making this valve an ideal choice for facilities prioritizing operational continuity.
Frequently Asked Questions:
Q: What industries commonly use this valve?
A: Chemical processing, power generation, water treatment, and oil & gas applications.
Q: How does ASME B16.5 compliance benefit my operation?
A: Ensures dimensional interchangeability and pressure-temperature ratings for safe integration.
Q: Are custom materials available?
A: Specialized alloys like duplex stainless steel can be provided upon request.
Q: What documentation formats are provided?
A: Physical manuals plus digital PDFs with 3D assembly diagrams.
Q: What is the lead time for orders?
A: Standard configurations ship in 4-6 weeks; custom orders require consultation.
Q: Do you provide installation supervision?
A: Technical support is available through our global service network.
