Help CenterHeavy-Duty Metal Electrical Cabinet With IP67 Waterproof Rating for Outdoor Use
Product Spotlights
Related Products
-
IP67 Waterproof Electrical Cabinet With Lockable Door for Secure Outdoor InstallationsUS$ 650MOQ: 1 Unit -
IP67 Waterproof Metal Electrical Cabinet for Outdoor Industrial Power DistributionUS$ 650MOQ: 1 Unit
-
Stainless Steel IP67 Waterproof Electrical Cabinet for Harsh Industrial EnvironmentsUS$ 650MOQ: 1 Unit
-
IP67 Waterproof Metal Cabinet for Industrial Automation and Machinery ControlUS$ 650MOQ: 1 Unit
-
Industrial-Grade IP67 Waterproof Electrical Cabinet for PLC and Control SystemsUS$ 650MOQ: 1 Unit
As a professional manufacturer with ISO9001 certification, Jinhua Dika Electrical Equipment Co., Ltd. specializes in producing robust electrical solutions trusted by clients across North America, Europe, Asia, and beyond. Our Heavy-Duty Metal Electrical Cabinet with IP67 rating is engineered for harsh outdoor environments, ensuring critical electrical components remain protected against water ingress, dust, and physical impact. With over $1 million in annual exports and serving diverse global markets, we deliver reliability backed by stringent manufacturing standards.
Core Features & Technical Specifications:
- Superior Environmental Protection: Achieves IP67 rating, guaranteeing complete protection against dust and temporary immersion in water up to 1 meter depth for 30 minutes.
- Robust Construction: Fabricated from high-grade cold rolled steel or galvanized steel (optional), offering exceptional resistance to corrosion, impact, and UV degradation.
- Enhanced Durability: Features thick gauge walls (typically 1.2mm - 2.0mm) and a reinforced structure designed to withstand mechanical stress and vandalism.
- Secure Sealing: Equipped with a high-quality silicone door gasket ensuring a tight seal. Door hinges are robust, and the cabinet includes padlock provisions for security.
- Effective Thermal Management: Design allows for optional cable glands, ventilation plugs, or mounting plates for fans/heaters to manage internal condensation and heat buildup.
- Versatile Mounting: Pre-drilled mounting holes and sturdy brackets facilitate secure wall mounting on uneven surfaces.
- Customizable Design: Available in various standard sizes and can be tailored to specific requirements:
| Internal Dimensions (HxWxD) | Typical Material Thickness | Color Options |
| e.g., 400x300x200mm | 1.5mm (Body), 2.0mm (Door) | RAL 7035 (Light Grey) |
| e.g., 600x500x250mm | Customizable upon request | RAL 7016 (Anthracite Grey) |
| Custom Sizes Available | Other RAL colors optional |
This cabinet is essential for protecting sensitive electrical components like PLCs, terminal blocks, transformers, and switches in demanding settings such as industrial plants, wastewater treatment facilities, telecommunications sites, renewable energy installations (solar/wind), and transportation infrastructure. Its robust design minimizes downtime and maintenance costs caused by environmental damage.
Trusted Global Manufacturer:
Jinhua Dika Electrical Equipment leverages its experience supplying over $1 million annually in electrical solutions to markets worldwide – from North America and Western Europe to Southeast Asia and Oceania. Our ISO9001 certified manufacturing processes in Jinhua, China ensure consistent quality control, while our established logistics via major ports (Shanghai, Tianjin, Guangzhou, Ningbo) guarantee efficient delivery. Choose our IP67 cabinets for unparalleled protection, longevity, and peace of mind in your outdoor electrical projects. Contact us today for competitive quotes, custom configurations, or detailed technical support.
Frequently Asked Questions (FAQ):
-
Q: What does IP67 rating actually mean for my equipment?
A: IP67 signifies complete protection against dust ingress (6) and protection against the effects of temporary immersion in water (7) up to 1 meter for 30 minutes. It ensures components stay dry and functional even in heavy rain, flooding, or washdowns. -
Q: Can this cabinet be installed directly on the ground?
A: While wall-mounted is standard, it can be pole-mounted or placed on a plinth/stand. Direct ground contact is not recommended; ensure adequate clearance and consider potential submersion risks. -
Q: How do I manage heat buildup inside the sealed cabinet?
A: Options include passive ventilation plugs (with internal filters), active cooling fans, or thermostatically controlled heaters to prevent condensation. Discuss your ambient temperature range with us for the best solution. -
Q: Are the internal DIN rails included?
A> Yes, standard models typically include top-hat DIN rails (35mm) for easy mounting of components. Quantity and position can be customized. -
Q: What is the lead time for custom sizes or colors?
A> Lead times vary based on complexity. Standard sizes ship quickly. Contact us with your specific requirements for an accurate timeline. -
Q: How is corrosion resistance ensured, especially near coastlines?
A> We use pre-treated steel (galvanized or phosphated) followed by a high-quality epoxy/polyester powder coating. For severe marine environments, specify galvanized steel for enhanced protection. -
Q: Do you provide gaskets or seals for cable entries?
A> Cable glands (PG or metric thread) or cord grips are not pre-installed but are highly recommended. We can supply compatible IP67/IP68 rated glands separately. -
Q: What warranty do you offer?
A> We provide a standard warranty against manufacturing defects. The specific duration can be confirmed upon order based on the product configuration.
