Home > Security & Protection > Surveillance, Control & Protection > Other Surveillance, Control & Protection > RG630C Handheld OGI Camera for Non-Contact Visual Gas Leakage Detection & Safety Monitoring

RG630C Handheld OGI Camera for Non-Contact Visual Gas Leakage Detection & Safety Monitoring

Product Spotlights

Equipped with a customized band-pass filter and a high-resolution, high-sensitivity uncooled VOx detector, RG630C supports daily temperature measurement.
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Detector Resolution:
640×512
Focusing Mode:
Manual
IFOV:
0.68 mrad
Contact Supplier Request Quote Chat Now
Raythink Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
YanTai
Delivery Detail:
14 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Detector Resolution 640×512
Focusing Mode Manual
IFOV 0.68 mrad
Minimum Imaging Distance 0.3 m (imaging only)
Detector Type Uncooled infrared detector
Thermal Sensitivity 15mK
Frame Rate 25Hz
Display Size 5-inch touch display, 1280×720 resolutio
Daylight Camera 4224×3136 (13 megapixel digital camera)
Temperature Width Stretch Precise temperature width
Transport Package Other
Specification 1.1kg
Trademark Raythink
Origin Yantai

RG630 OGI Handheld Camera Powered by advanced infrared gas imaging and AI algorithms, RG630 enables non-contact, visual detection and alarm for dozens of gases, including CH4, NH3, Freon and SF6. Equipped with a customized band-pass filter and a high-resolution, high-sensitivity uncooled VOx detector, it also supports daily temperature measure ment. Designed for gas safety, emission management and equip ment maintenance, RG630 is ideal for oil, gas, petrochemical, chem icals, power utilities, environmental protection and emergency response.

High-Definition Infrared Imaging

  • 640×512 High Infrared Resolution

  • Customized Filter Detector to Eliminate Stray Light Interference


Intelligent Gas Detection

  • Real-Time Gas Concentration

  • AI Gas Cloud Visualization

  • Ultra-Low Leak Detection Threshold

Thermal Imaging Characteristics
Detector Resolution 640×512
Lens Configuration 19 mm non-detachable manual lens
Focusing Mode Manual
IFOV (Spatial Resolution)  0.68 mrad
Minimum Imaging Distance 0.3 m (imaging only)


Common Characteristics
Detector Type Uncooled infrared detector
Thermal Sensitivity  15mK
Frame Rate 25Hz


Measurement and Analysis
Measurement Accuracy ±2°C or ±2% of the reading
Gas Detection Function AI intelligent gas detection, gas cloud coloring, retrieving concentration, automatic alarm, gas image enhancement, image multi-sensitivity switch
Gases Detectable Methane (CH4), Sulfur Dioxide (SO2), Ethanol, Freon (R-134a, R-152a) and other gases
Positioning Image + geolocation data. GPS, GLONASS,  supported



System Functions
Zooming In 1‒10x continuous zoom
Communication Mode Wi-Fi, Bluetooth, Type-C
