Find Similar Icon 600V ROHS Insulated Aluminum Flat Enamelled Wire Electrical Conductive Solid IP20 for Transformers & Electromotors
Product Spotlights
Find similar icon
600V ROHS Insulated Aluminum Flat Enamelled Wire Electrical Conductive Solid IP20 for Transformers & Electromotors
US$ 3.97
500 - 4999 Kilograms
US$ 3.50
≥5000 Kilograms
Key Specifications
Get Latest Price
Type:
Insulated
Conductor Material:
Aluminum
Conductor Type:
Solid
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Class 180 Round Copper Clad Aluminum Enameled Wire for TransformersNegotiableMOQ: 500 Kilograms -
High Temperature Polyamideimide Enameled Aluminum Winding WireNegotiableMOQ: 500 Kilograms
-
Pew (QZL) 130°C Heat Resistant Enameled Aluminum WireNegotiableMOQ: 500 Kilograms
-
Copper Clad Aluminum (CCA) Enameled Wire for Electrical ApplicationsNegotiableMOQ: 500 Kilograms
-
Premium Enameled Aluminum Winding Wire Round/Flat Magnet WireNegotiableMOQ: 500 Kilograms
Type
Insulated
Conductor Material
Aluminum
Conductor Type
Solid
Model Number
EIW180
Brand Name
YONGDONG
Place of Origin
Shandong, China(Mainland)
Diameter:
AWG/SWG
Style:
Enameled Aluminum Wire
Shape:
Round
Heat-resisting class:
C class
Insulation Material:
polyester-imide
Production Range:
0.20mm-5.00mm
Certification:
ULE234565 ROHS REACH
Bobbin:
PT25 PT30 PT60 PT200 PT270
Standard
IEC NEMA GB JIS
Conductor
Aluminum
Product Details
Product Paramenters
Product Name |
QZ(G)-155 |
QZ-180 |
Q(ZY/XY)-200 |
Q(ZY/XY)-220 |
Thermal Class |
155, class F |
180, class H |
200, class C |
220, class N |
Coating Material |
PEW(G) |
EIW |
EI/AIW |
EI/AIW |
Cross Section Range (mm) |
0.20-5.00 |
0.20-5.00 |
0.20-5.00 |
0.20-5.00 |
Insulation Thickness (IEC) |
Grade 1 Grade 2 Grade 3 |
Grade 1 Grade 2 Grade 3 |
Grade 1 |
Grade 1 |
Standard |
GB/T6109.2 GB/T23312.4 IEC60317-3 |
GB/T6109.5 GB/T23312.5 IEC60317-8 NW30 |
GB/T6109.20 GB/T23312.7 IEC60317-13 NW35 |
GB/T6109.22 IEC60317-46 NW16 |
PT200 spool |
410*410*660 mm 65-75KG |
410*410*660 mm 65-75KG |
410*410*660 mm 65-75KG |
410*410*660 mm 65-75KG |
