High Security Anti-Climb Welded Razor Wire Mesh
Razor barbed wire, anti rust concertina razor barbed wire also known as blade barbed wire, anti rust concertina razor barbed wire is a kind of new safety net. The blade barbed rope has the advantages of beautiful appearance, economical and practical, good anti blocking effect, convenience in construction and other excellent characteristics, at present, anti rust concertina razor barbed wire has been widely used in many countries, industrial and mining enterprises, garden apartments, border posts, prisons, detention center, government buildings and other countries safety facilities.
Outside Diameter |
No. of Loops |
Standard Length per Coil |
Razor Type |
Notes |
450mm |
33 |
7M-8M |
CBT-60, 65 |
Single Coil |
500mm |
56 |
12M-13M |
CBT-60, 65 |
Single Coil |
700mm |
56 |
13M-14M |
CBT-60, 65 |
Single Coil |
960mm |
56 |
14M-15M |
CBT-60, 65 |
Single Coil |
450mm |
56 |
8M-9M (3clips) |
BTO-10, 12, 18, 22, 28, 30 |
Cross Type |
500mm |
56 |
9M-10M (3clips) |
BTO-10, 12, 18, 22, 28, 30 |
Cross Type |
600mm |
56 |
10M-11M (3clips) |
BTO-10, 12, 18, 22, 28, 30 |
Cross Type |
600mm |
56 |
8M-10M (5clips) |
BTO-10, 12, 18, 22, 28, 30 |
Cross Type |
700mm |
56 |
10M-12M (5clips) |
BTO-10, 12, 18, 22, 28, 30 |
Cross Type |
800mm |
56 |
11M-13M (5clips) |
BTO-10, 12, 18, 22, 28, 30 |
Cross Type |
900mm |
56 |
12M-14M (5clips) |
BTO-10, 12, 18, 22, 28, 30 |
Cross Type |
960mm |
56 |
13M-15M (5clips) |
BTO-10, 12, 18, 22, 28, 30 |
Cross Type |
980mm |
56 |
14M-16M (5clips) |
BTO-10, 12, 18, 22, 28, 30 |
Cross Type |
Application of concertina razor barbed wire
Razor Barbed Wire is widely used in airport , prison, government, bank, and also in living wall, personal house, villatic wall, window, autobahn, railway and border of the fence.
Packing of concertina razor barbed wire
compression rolls, water-proof paper inside, woven bag outside or in carton
Weave characteristics of concertina razor barbed wire
twist and weave, fastness ,beautiful; galvanizing after weaving, galvanizing before weaving. It is divided to electrical galvanized ,hot - dipped galvanized, plas-tic coating, stainless steel, etc.
Fetures of razor wire:
High reliability:Concertina Razor Wire also called Razor Wire.it the normal type of Razor wire you see around prisons and high security establishments. As an effective and economical security barrier, with its high security function, Concertina Razor Wire can prevent most of the intruders for it is hard and dangerous to broken.
Surface Treatment:Our concertina razor wire is widely used in wild fences, chain link fences and welded fences, and provides general safety. For example, wire mesh is usually installed on the top of a cattle fence to restrain the cattle. The concertina razor wire is very powerful and can threaten deliberate intrusion.
Advantages of concertina razor barbed wire
Razor barbed wire mesh is a new kind of protective fencing with such advantages as beautiful appearance,economical cost and practicality.
Welded razor mesh fence:
The razor wire can welded to mesh panel with a frame as the fence installed on the prison wall, the hole shape can be rectangle and diamond.
1>Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.
2>Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.
| Hole shape | Mesh width | Suited blade specifications |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
| Square hole, diamond | 1.2m ~ 2.4m | BTO-10.12.22.28.30 |
