Rotary Table Bearings ORT 180
Product Spotlights
ORT bearings has the high axial rigidity, high radial loading capacity, high stiffness and high accuracy. This series is used for the high precison numerical rotary table, index head, direct drive motor, vertical grinder and gear hobbing machine etc.
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Bearing Steel
Type:
No Gear
Feature:
High Speed
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
30 days
Related Products
Material
Bearing Steel
Type
No Gear
Feature
High Speed
Standard or Nonstandard
Standard
Sealing Gland
Sealed On Both Sides
Rolling-Element Number
Multiple-Column
Roller Type
Other, V-Groove Raceway
Customisation
available
Accuracy class
P5/P4/P2
Transport Package
Wooden Case
Specification
d:180 mm D:280 mm Weight:7.7 kg
Trademark
ONA
Origin
Luoyang,China
ORT rotary table bearings is included by a thrust race/radial race, a thrust gasket, two needle rollers with cage assembly and a set of centripetal cylindrical roller. There is the screw holes which is used for installed on the race and circle. ORT bearings has the high axial rigidity, high radial loading capacity, high stiffness and high accuracy. This series is used for the high precison numerical rotary table, index head, direct drive motor, vertical grinder and gear hobbing machine etc.
In addition, we have many other models that have not been listed.If you need any information, please contact us.
