High Precision Rotary Table Bearings ORT 100
Product Spotlights
ORT bearings has the high axial rigidity, high radial loading capacity, high stiffness and high accuracy. This series is used for the high precison numerical rotary table, index head, direct drive motor, vertical grinder and gear hobbing machine etc.
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Bearing Steel
Type:
No Gear
Feature:
Other, high rigidity
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
30 days
Related Products
-
High Precision Rotary Table Bearings ORT 50NegotiableMOQ: 5 Pieces -
High Precision Rotary Table Bearings ORT 80NegotiableMOQ: 5 Pieces
-
High Precision Rotary Table Bearings ORT 150NegotiableMOQ: 5 Pieces
-
High Precision Rotary Table Bearings ORT 120NegotiableMOQ: 5 Pieces
-
High Precision Rotary Table Bearings ORT 180NegotiableMOQ: 5 Pieces
Material
Bearing Steel
Type
No Gear
Feature
Other, high rigidity
Standard or Nonstandard
Nonstandard
Sealing Gland
Non-Seal
Rolling-Element Number
Multiple-Column
Roller Type
Straight Raceway
Customisation
available
Accuracy class
P5/P4/P2
Transport Package
Wooden Case
Specification
d:100 mm D:185 mm Weight:4.1 kg
Trademark
ONA
Origin
Luoyang,China
ORT rotary table bearings is included by a thrust race/radial race, a thrust gasket, two needle rollers with cage assembly and a set of centripetal cylindrical roller. There is the screw holes which is used for installed on the race and circle. ORT bearings has the high axial rigidity, high radial loading capacity, high stiffness and high accuracy. This series is used for the high precison numerical rotary table, index head, direct drive motor, vertical grinder and gear hobbing machine etc.
In addition, we have many other models that have not been listed.If you need any information, please contact us.
