Cantilever shelving Multilevel Storage System Cantilever Rack Factory Supplier
Cantilever shelving is a storage equipment designed specifically for storing long, irregular, and heavy materials, widely used in industries such as machinery manufacturing, building materials, furniture, and logistics. It achieves lateral material access through a combination structure of columns and cantilevers, and has the characteristics of structural stability, strong load-bearing capacity, and high space utilization.
1、 Basic structure
Cantilever shelves are mainly composed of the following parts:
Column: As the supporting body, it is usually welded with H-beam or cold-rolled C-shaped steel, which has high strength and compressive capacity.
Cantilever: horizontally extending from both sides of the column, used to carry materials, can be designed as single-sided or double-sided, with a length generally within 1.5 meters and a maximum length of 11 meters.
Connectors: including plug-in or bolted connection devices to ensure a stable connection between the cantilever and the column.
Base and Back Pulling System: The base is fixed to the ground with expansion bolts, and combined with the back pulling structure to enhance overall stability and prevent overturning.
Product Description
Cantilever Rack is the ideal solution for storing long or heavy items such as: Pipe, tubing or lumber. It is designed to manage loads of varying length and proportion.This type of racking allows you to use your warehouse space more efficiently - you do not need to waste horizontal space with awkward posts and columns obstructing storage areas. Items best suited to such a system include furniture, building materials, piping, rolls, appliances, and flooring.You can fit this racking system to your facility by adjusting the shelf height, ensuring that the maximum amount of vertical storage space is maintained. Moreover, the support arms can vary in depth and capacity depending on the type of load. Open rows allow not only secure load support but also easy access - safety, flexibility and selectivity are all maintained.
| Item No. | Cantilever Arm Racking |
| Brand Name | TS |
| Style | Single side cantilever and double side cantilever |
| Load | Light duty/ Medium duty/ Heavy duty |
| Characteristics | Easy handing,Flaexible,Steady,Safety and Economical |
| Certifications | CE |
| Usage | Warehouse /Storehouse/Depot/Depositary |
| Architecture material supermarket |
Our Service
. Factory price with high quality
. OEM /ODM are available.
. Fast delivery.
. ISO,CE certified, one stop solution service for your project.
. Perfect design Exquisite technology, strict management, sincere service.
FAQ
1,Q:Are you a factory or trading company?
A:We are a factory. We are specilize in all kindly of warehouse storage rack.
2,Q:Where is your factory located? How can I visit there?
A:Our factory is located in Nanjing City,China.You can fly to Nanjing air report directly. You are warmly welcome to visit us whenever you are available!
3,Q:What is the raw material of your products?
A:The raw material of steel code is Q235.Other steel is also available to clients' requirements.
4,Q:What is the term of payment?
A:TT,L/C,Western Union are available.
5,Q:What is the delivery times?
A:In general, within 15 days after deposit.
6,Q:May I know the status of my order?
A:Yes.We will send you information and photos at different production stage of your order.You will get the latest information in time.
7,Q:How could you guarantee the products quality?
A:We have professional engineer to check what size should be used to guarantee your load weight request.
8,Q:How could I install the racks?
A:We would provide detail install drawing to teach you how to install the racks.If needed,we also could provide free engineer to teach you installation.But related cost(Flight,living and eating etc.)should be in your charge.
email: shiyan-110@163.com
whatsapp: 0086 135 0624 5149
we can manufacture according to your requirement. so welcome your enquiry.
