Woodward 9905-972 Analog output module
The Woodward 9905-972 is a 6-channel 4-20mA analog output module from the Linknet series, suitable for distributed control and remote signal transmission. It is primarily used for actuator drives and I/O expansion in turbine/generator systems, currently mainly for spare parts replacement and maintenance of older systems.
Core Performance:
Output and Drive Capability: Includes 6 independent 4-20mA current output channels, each with a maximum load of 500Ω. Suitable for analog drive devices such as valve positioners and actuators, supporting linear/non-linear signal mapping to meet precise control requirements.
Supports 24V DC redundant power supply (18-32V DC, 7.9W), with short-circuit/overcurrent protection. Output maintains or reaches safe values in case of failure, ensuring system stability.
Communication and Compatibility: Compatible with the Linknet communication bus, seamlessly integrates with MicroNet/HC900 controllers, supports hot-swapping, and allows for maintenance without downtime, suitable for distributed I/O expansion scenarios.
Meets Class I Div 2 explosion-proof standards, temperature code T4A, maximum ambient temperature 55℃, resistant to vibration and electromagnetic interference, suitable for harsh industrial/marine environments.
Diagnostics and Safety: Integrated channel fault self-diagnosis (open circuit/short circuit/overload), real-time feedback of module and channel status for quick anomaly location.
Modular design, standard rack mounting, adaptable to industrial cabinet layouts, reducing maintenance costs.
Email: xmxblynn@163.com
Phone: +86 18059884797
Key Technical Parameters
Parameter Value
Model 9905-972 (Linknet 6-channel analog output module)
Output Channels 6 channels, 4-20mA current output, maximum load per channel 500Ω
Power Supply 18-32V DC (24V DC typical), 7.9W
Communication Linknet bus, supports hot-swapping and redundant communication
Explosion-proof and Temperature Protection Class I Div 2 (Groups A/B/C/D), Temperature Code T4A, Maximum Ambient Temperature 55℃
Protection Functions Short circuit, overcurrent protection, fault output hold/safe value
Status Discontinued, used for replacement of old Linknet system spare parts
Typical Applications Turbine control execution: valve positioners and servo valve drives for steam/gas turbines, achieving precise speed/load regulation, adapting to critical speed avoidance, valve limit and other control logic.
Power Generation System I/O Expansion: Actuator control and signal conversion for diesel/gas generator sets, supporting remote I/O expansion to meet distributed monitoring and control needs.
Industrial Process Drives: Analog control of pumps, fans, compressors, and other equipment in the petrochemical and metallurgical industries, ensuring stable process parameters.
Offshore Platforms and Ships: Remote signal transmission for offshore platform power plants and ship propulsion systems, adaptable to explosion-proof and high-vibration conditions, ensuring reliable equipment operation.
System Maintenance and Spare Parts: Compatible with existing Linknet/MicroNet systems, used for replacing faulty output modules, ensuring control accuracy and system compatibility.
