Bently nevada 330103-00-03-10-02-05 Eddy current probe
The 330103-00-03-10-02-05 is a Bently Nevada 3300 XL series 8mm unarmored eddy current probe. It achieves non-contact measurement using the eddy current principle. Its core function is to accurately capture radial/axial displacement, vibration, key phase, and speed signals of rotating machinery shafts. It is compatible with the 3300 XL 8mm sensor system and is widely used in the condition monitoring and fault early warning of key rotating equipment in industries such as power and petrochemicals to ensure the safe and stable operation of equipment.
Core Parameters and Specifications
Item Parameter
Product Model 330103-00-03-10-02-05 (3300 XL 8mm Unarmored Probe)
Model Code Meaning 00 (Non-threaded length) -03 (Housing length 30mm) -10 (Cable length 1.0m) -02 (Miniature coaxial ClickLoc connector) -05 (Certification option)
Compatible Systems 3300 XL 8mm eddy current sensor system, compatible with 330180 series preamplifiers and 330854 series extension cables
Electrical Characteristics Output Sensitivity 7.87V/mm (200mV/mil), Linear Range 0.25-2.3mm, Frequency Response 0-10kHz, compatible with ferromagnetic metal target surface
Temperature Tolerance Probe operating temperature -51~177℃, unarmored cable suitable for general industrial environments
Structural Material Probe housing is AISI 303/304 stainless steel, PPS tip, unarmored cable suitable for standard operating conditions.
M10×1 metric thread mounting, compatible with standard mounting brackets, facilitating on-site fixing and calibration.
Certifications: Compliant with API 670 standards, suitable for industrial rotating machinery monitoring systems.
Email: xmxblynn@163.com
Phone: +86 18059884797
Core Functions
Non-contact Measurement: Based on the eddy current effect, it measures clearance changes without contact with the rotating shaft system, avoiding mechanical wear and measurement interference, and is suitable for high-speed rotating equipment.
Multi-parameter Monitoring: It can measure parameters such as shaft vibration, axial displacement, key phase, eccentricity, and rotational speed, providing comprehensive data support for equipment condition assessment.
Stable Signal Transmission: Unarmored cable adapts to normal operating conditions, ensuring signal integrity and meeting the monitoring needs of general industrial environments.
System Compatibility and Integration: Matches the 3300 XL 8mm sensor system, supports 3300/3500 monitoring frames, and simplifies data acquisition and analysis processes.
Long-term Reliable Operation: Stainless steel housing and high-temperature resistant materials adapt to a wide temperature range of -51~177℃, meeting the needs of long-term online monitoring.
Applications and Typical Scenarios
Power Energy: Monitoring shaft vibration and axial displacement of steam turbines, generators, and water pumps; used in conjunction with the 3500 system for fault diagnosis; compliant with API 670 standards.
Petrochemical Industry: Shaft condition monitoring of compressors, fans, and gearboxes, acquiring key phase and speed signals to ensure long-term operation and safety interlocks.
Metallurgical Heavy Industry: Vibration and displacement monitoring of heavy-duty equipment such as rolling mills and coal mills to prevent faults such as bearing wear and rotor imbalance.
General Industry: Condition monitoring of rotating machinery such as motors and centrifuges to facilitate predictive maintenance and reduce downtime risks.
Conventional Environmental Applications: Adaptable to non-high-temperature and non-intense mechanical damage conditions, ensuring signal integrity and measurement accuracy in equipment condition monitoring.
Email: xmxblynn@163.com
Phone: +86 18059884797
