Bently Nevada 330106-05-30-50-02-00 Reverse-mounted Eddy Current ProbeUS$ 10000 - 15000MOQ: 1 Combo
Bently nevada 330180-50-00 Eddy current preamplifier
The 330180-50-00 is a 5-meter system length eddy current preamplifier from the Bently Nevada 3300 XL series. It is compatible with the 3300 XL 8mm probe and extension cable, providing signal conditioning and transmission for non-contact displacement, vibration, and speed measurement of rotating machinery. Its core applications are in industrial unit condition monitoring, fault warning, and safety protection, and it is suitable for harsh working conditions in power, petrochemical, and metallurgical industries. The following is a detailed introduction:
Core Parameters and Specifications
Item Parameter
Product Model 330180-50-00 (3300 XL Proximitor Preamplifier)
Compatible Systems Bentley 3300 XL Sensor System, 3500/3300 Monitoring Frame
System Length 5 meters (16.4 feet), compatible with 3300 XL 8mm probe and extension cable
Input Characteristics Receives signals from 3300 series eddy current probes, compatible with 5mm/8mm probes
Output Signal Linear voltage output (-1~-17V corresponding to 0.25~2.25mm displacement), sensitivity 7.87V/mm (200mV/mil)
Electrical Specifications Power Supply - 17.5~-26Vdc (without safety barrier) / -23~-26Vdc (with safety barrier), current ≤12mA, 50Ω impedance
Environmental Tolerance Operating Temperature - 35~85℃, aluminum housing, resistant to radio interference, suitable for industrial electromagnetic environments
Installation method: Panel mounting, terminal blocks with tool-less fastening, reliable wiring to prevent loosening
Certifications: CE, ATEX/IECEx hazardous area certification, compliant with API 670 standards
Email: xmxblynn@163.com
Phone: +86 18059884797
Core Functions
Signal Conditioning and Linear Conversion: Converts the probe's eddy current signal into a standard linear voltage output, matching the acquisition requirements of the monitoring system and ensuring measurement accuracy.
System Compatibility and Matching: Adapts to 5-meter sensor systems, compatible with the 3300 XL 8mm probe, supports hot-swappable 3500 frame, simplifying system integration.
Interference Resistance and Signal Stability: Highly resistant to radio interference design, terminals with tool-less fastening prevent loose wiring, ensuring stable signal transmission under harsh operating conditions.
Fault Diagnosis and Early Warning: Real-time output of displacement/vibration data, working with the monitoring system to achieve trend analysis, over-limit alarms, and interlocking protection, supporting predictive maintenance.
Hazardous Area Adaptation: Explosion-proof certified for Zone 1/2 hazardous areas, meeting the safety monitoring needs of industries such as petrochemicals and oil and gas.
Applications and Typical Scenarios
Power Unit Monitoring: Used for measuring shaft vibration and axial displacement of steam turbines, generators, and water pumps, working with the 3500 system to achieve overspeed protection and fault diagnosis.
Petrochemical Key Equipment: Monitors the shaft status of compressors, fans, and gearboxes, acquiring key phase and speed signals to ensure long-term operation and safety interlocks.
Metallurgy and Heavy Machinery: Adapted for heavy-duty equipment such as rolling mills and coal mills, monitoring shaft vibration and displacement to prevent bearing wear, rotor imbalance, and other faults.
Paper and Textile Industry: Monitors the vibration status of high-speed fans and motors, improving production line reliability and reducing unplanned downtime.
Hazardous Area Status Acquisition: ATEX/IECEx certified for status monitoring of rotating equipment in hazardous areas such as chemical and oil and gas plants, meeting explosion-proof safety requirements.
Email: xmxblynn@163.com
Phone: +86 18059884797
