Help CenterDT4C Cold Rolled Non-Oriented Silicon Steel Coil Low Iron Loss 0.35mm/0.5mm
Related Products
-
High Magnetic Permeability DT4C Cold Rolled Electrical Steel Coil 600mm WidthNegotiableMOQ: 1 Ton -
Electrical Pure Iron Cold Rolled Coil Cold Rolled 0.35mm ThicknessNegotiableMOQ: 1 Ton
-
Industrial Pure Iron Cold Rolled Coil High Magnetic Induction Electrical SteelNegotiableMOQ: 1 Ton
-
Cold Rolled DT4C Silicon Steel Coil for Transformer and Electric Motor ApplicationsNegotiableMOQ: 1 Ton
-
Electromagnetic Pure Iron Cold Rolled Coil DT4C for High Magnetic Permeability ApplicationsNegotiableMOQ: 1 Ton
Shanxi Jurun Technology Co., Ltd., a trusted manufacturer based in Taiyuan, China, proudly presents our DT4C Cold Rolled Non-Oriented Silicon Steel Coil – engineered for superior magnetic performance in demanding electrical applications. This advanced material delivers exceptional energy efficiency through minimized iron loss, making it an ideal solution for modern electromechanical systems. Our precision manufacturing ensures consistent quality across every coil, providing reliable material for high-performance motor and transformer production.
Key technical advantages include:
- Ultra-thin gauge options (0.35mm and 0.5mm) for reduced eddy current losses
- Optimized grain structure for enhanced magnetic flux density
- Controlled surface insulation resistance for improved lamination performance
- Customizable annealing processes to meet specific core loss requirements
Below are standard specifications for our DT4C series:
| Parameter | 0.35mm Specification | 0.50mm Specification |
|---|---|---|
| Typical Iron Loss (P1.5/50) | ≤ 4.0 W/kg | ≤ 4.8 W/kg |
| Magnetic Induction (B50) | ≥ 1.65 T | ≥ 1.67 T |
| Coil Width Range | 800-1250mm | 800-1250mm |
| Surface Coating | C3/C4/C5 available | C3/C4/C5 available |
Manufacturers benefit from significant operational advantages when using our silicon steel coils:
- Energy savings up to 15% in motor applications due to reduced hysteresis losses
- Improved torque characteristics in variable frequency drives
- Reduced annealing time during component manufacturing
- Compatibility with high-speed stamping processes
With our Shanxi-based production facilities, Jurun Technology maintains strict quality control throughout the manufacturing process – from melt composition analysis to final slitting operations. Our technical team provides comprehensive material selection guidance to ensure optimal performance for your specific application requirements. Backed by over 15 years of metallurgical expertise, we deliver material consistency that directly translates to improved manufacturing yield and end-product reliability.
Frequently Asked Questions:
Q1: What applications are suitable for 0.35mm thickness?
A: The 0.35mm grade is particularly effective in high-frequency applications (400Hz+) such as EV motors, precision servo motors, and high-efficiency generators where reduced eddy current losses are critical.
Q2: Can I get customized widths outside the standard range?
A: Yes, we offer custom slitting services for widths between 100mm to 1500mm. Minimum order quantities apply for non-standard dimensions.
Q3: What surface treatments are available?
A: We provide C3 (general purpose), C4 (high temperature resistant), and C5 (excellent punchability) insulation coatings. Technical datasheets for each coating are available upon request.
Q4: How does DT4C compare to conventional grades?
A: DT4C offers approximately 12-18% lower core losses compared to standard commercial grades, resulting in cooler operating temperatures and extended equipment lifespan.
Q5: What packaging options do you provide?
A: Standard packaging includes waterproof wrapping with steel strapping on wooden pallets. Special export packaging with corner protectors is available for overseas shipments.
Q6: Can you supply material with specific magnetic properties?
A: Our engineering team can adjust production parameters to achieve target magnetic characteristics. Please provide your technical requirements for evaluation.
Q7: What is your lead time for standard orders?
A: Typical lead time is 25-35 days for standard specifications. Expedited production may be available for urgent requirements.
Q8: Do you provide material certification?
A: Yes, each shipment includes a mill test certificate detailing chemical composition, magnetic properties, and mechanical characteristics according to international standards.
